Metal Forging Machinery: Air Hammer, Power Forging & Cold Heading Machines
These Cold Heading Machines are designed for efficient metal forging, particularly for heading, punching, and forming processes in various industries. Below are the specifications for different models:
HRS-15A Semi-Tubular Heading Machine
- Max Cut-Off Diameter: 5mm
- Max Cut-Off Length: 70mm
- Main Slide Stroke: 102mm
- Output: 70-100 pcs/min
- Die Diameter: 34.5mm
- Cut-Off Die Diameter: 19mm
- Punch Die (1st): 31mm
- Punch Die (2nd): 31mm
- Main Motor Power: 3HP
- Dimensions (LxWxH): 2.4m x 0.95m x 1.15m
- Net Weight: 1700kg
- Gross Weight: 1760kg
HRS-5A Semi-Tubular Heading Machine
- Max Cut-Off Diameter: 3mm
- Max Cut-Off Length: 22mm
- Main Slide Stroke: 38mm
- Output: 100-120 pcs/min
- Die Diameter: 20mm
- Cut-Off Die Diameter: 13.5mm
- Punch Die (1st): 18mm
- Punch Die (2nd): 18mm
- Main Motor Power: 1.1HP
- Dimensions (LxWxH): 164cm x 78cm x 85cm
- Net Weight: 620kg
- Gross Weight: 650kg
HRS-5 (Model HS-5)
- Max Blank Diameter: 3mm
- Max Blank Length: 27mm
- Stroke: 38mm
- Output Speed: 100-120 pcs/min
- Die Diameter: 20mm
- Cut-Off Die Diameter: 13.5mm
- Punch Die (1st & 2nd): 18mm
- Main Motor Power: 1HP
- Oil Pump Power: 1/4HP
- Net Weight: 500kg
HRS-10 (Model HS-10)
- Max Blank Diameter: 4mm
- Max Blank Length: 40mm
- Stroke: 64mm
- Output Speed: 120-180 pcs/min
- Die Diameter: 34.5mm
- Cut-Off Die Diameter: 15mm
- Punch Die (1st): 24mm
- Punch Die (2nd): 20mm
- Main Motor Power: 2HP
- Oil Pump Power: 1/4HP
- Net Weight: 1100kg
HRS-15 (Model HS-15)
- Max Blank Diameter: 6mm
- Max Blank Length: 65mm
- Stroke: 92mm
- Output Speed: 130-160 pcs/min
- Die Diameter: 34.5mm
- Cut-Off Die Diameter: 19mm
- Punch Die (1st & 2nd): 31mm
- Main Motor Power: 3HP
- Oil Pump Power: 1/4HP
- Net Weight: 1600kg
HRS-25 (Model M8-120)
- Max Blank Diameter: 8mm
- Max Blank Length: 120mm
- Die Diameter: 54mm
- Punch Die (1st & 2nd): 38mm
- Main Motor Power: 7HP
- Output Speed: 80-100 pcs/min
- Stroke: 154mm
These machines are highly efficient for cold heading, forging, and metal forming. They offer a range of options for different production needs and metal materials, with high output speeds, precision, and durability.
semi-tubular heading machine-15A
5mm
A. Description of goods:
| Model | HRS-15A |
| Max.cut off dia | 5mm |
| Max.cut-off length | 70mm |
| Main slide Stroke | 102mm |
| Outpout | 70-100 |
| Die dia | 34.5mm |
| Cut off die dia | 19mm |
| Punch die (1st) | 31mm |
| Punch die (2nd) | 31mm |
| Main motor power | 3HP |
| LxWxH(m) | 2.4x0.95x1.15 |
| Net weight | 1700kg |
| Gross weight | 1760kg |
semi-tubular heading machine-5A
A. Description of goods:
| Model | HRS-5A |
| Max.cut off dia | 3mm |
| Max.cut-off length | 22mm |
| Main slide Stroke | 38mm |
| Outpout | 100-120 |
| Die dia | 20mm |
| Cut off die dia | 13.5mm |
| Punch die (1st) | 18mm |
| Punch die (2nd) | 18mm |
| Main motor power | 1.1HP |
| LxWxH(cm) | 164x78x85 |
| Net weight | 620kg |
| Gross weight | 650kg |
A:HRS-5
| Model:HS-5 | Specification |
| Max. Blank Dia..(mm) | 3mm |
| Max. Blank Length (mm) | 27mm |
| Stroke (mm) | 38mm |
| Output Speed (pcs/min) | 100-120pcs/min |
| Die dia. | 20mm |
| Cut-off die dia. | 13.5mm |
| Punch Die 1st | 18mm |
| Punch Die 2nd | 18mm |
| Main motor power | 1HP |
| Oil pump power | 1/4HP |
| Net Weight | 500kgs |
B HRS-10
| Model:HS-10 | Specification |
| Max. Blank Dia..(mm) | 4mm |
| Max. Blank Length (mm) | 40mm |
| Stroke (mm) | 64mm |
| Output Speed (pcs/min) | 120-180pcs/min |
| Die dia. | 34.5mm |
| Cut-off die dia. | 15mm |
| Punch Die 1st | 24mm |
| Punch Die 2nd | 20mm |
| Main motor power | 2HP |
| Oil pump power | 1/4HP |
| Net Weight | 1100kgs |
C HRS-15
| Model:HS-15 | Specification |
| Max. Blank Dia..(mm) | 6mm |
| Max. Blank Length (mm) | 65mm |
| Stroke (mm) | 92mm |
| Output Speed (pcs/min) | 130-160pcs/min |
| Die dia. | 34.5mm |
| Cut-off die dia. | 19mm |
| Punch Die 1st | 31mm |
| Punch Die 2nd | 31mm |
| Main motor power | 3HP |
| Oil pump power | 1/4HP |
| Net Weight | 1600kgs |
HEADING MACHINE
SH-25B
HRS-25:
| Model:M8-120 | Specification |
| Max. Blank Dia.(mm) | 8 |
| Max. Blank Length(mm) | 120 |
| Die Dia. | 54 |
| Punch Die(1st&2nd) | 38 |
| Main motor | 7HP. |
| Output Speed (pcs/min) | 80-100 |
| Stroke mm | 154 |
