The Battery Lab Equipment Vacuum Mixing Machine is an advanced planetary mixer designed for high-precision mixing of slurry and powder-based materials. It’s particularly effective for the battery and electrode industry, providing exceptional mixing performance for chemical processing applications..
| Specification | |
| Voltage Input & Power | 24V DC input voltage 100-240 VAC IN, 24 VDC OUT power adapter is included |
| Rotary Speed | 0 - 600 rpm |
| Mixing Container | One 500ml Stainless steel vacuum sealed container is included Dual helical ribbon mixing blades are built on the lid of the container. |
| Vacuum Pump | Built-in single stage vacuum pump Vacuum Level: -0.08 ~ -0.09 MPa |
| Control Panel | 3.5" color touch screen control allows easy setting of parameters such as mixing speed, mixing time, vacuum on/off Mixing Time: 0 - 600 minute Mixing Speed: 0 - 600 RPM and 3 segments programmable Note: Max. mixing speed depends on slurry viscosity. Max.10000 mPa.s is allowed at 600 rpm. Lower speed will be required for more sticky slurry |
| Dimensions | 330*320*570mm |
| Net Weight | 35kg |
| Shipping Dimensions | 510*460*620mm |
| Gross Weight | 45kg |
| Compliance | CE Certified |
| Warranty | One year limited with lifetime technical support |
| Application Notes | For best result, please consider ordering a filter to remove larger particle in slurry. Recommend Model: MRX-GL-1 Please see the picture below to see the the quality of slurry after mixing. |
The Battery Lab Equipment Vacuum Mixing Machine is ideal for laboratories and small-scale production facilities requiring efficient slurry and powder mixing. Its high-performance features, durability, and automatic operation make it a reliable choice for research and production tasks.
| Item No. | Description | Quantity |
| MR-XJB-4 | Compact Dual-Shaft Planetary Vacuum Mixer | 1 |
| 500ML | 500ml stainless steel vacuum sealed container is included | 1 |
| Voltage Input & Power | 24V DC input voltage100-240 VAC IN, 24 VDC OUT power adapter is included |
|---|---|
| Rotary Speed | 0 - 600 rpm |
| Mixing Container | One 500ml Stainless steel vacuum sealed container is included Dual helical ribbon mixing blades are built on the lid of the container. |
| Vacuum Pump | Built-in single stage vacuum pump Vacuum Level: -0.08 ~ -0.09 MPa |
| Control Panel | 3.5" color touch screen control allows easy setting of parameters such as mixing speed, mixing time, vacuum on/off Mixing Time: 0 - 600 minute Mixing Speed: 0 - 600 RPM and 3 segments programmable Note: Max. mixing speed depends on slurry viscosity. Max.10000 mPa.s is allowed at 600 rpm. Lower speed will be required for more sticky slurry |
| Dimensions | 330*320*570mm |
| Net Weight | 35kg |
| Gross Weight | 45kg |
| Compliance | CE Certified |
| Warranty | One year limited with lifetime technical support |
| Application Notes | For best result, please consider ordering a filter to remove larger particle in slurry. Recommend Model: MRX-GL-1 Please see the picture below to see the the quality of slurry after mixing. |
| Efficient Mixing | Equipped with a planetary mixer, this machine ensures uniform mixing of slurry, powders, and chemicals, delivering consistent results. |
| Compact Design | With a 0.5L barrel volume and compact dimensions (330x320x570mm), this vacuum mixer is ideal for lab-scale operations where space is limited. |
| Powerful Motor | Powered by a 200W motor, it offers a spindle speed range of 1-1400 r.p.m., providing flexibility to accommodate different materials and applications. |
| High Slurry Viscosity | Capable of handling slurries with a maximum viscosity of 10,000 cp at 600 r.p.m., making it suitable for thick materials and complex mixtures. |
| Vacuum Operation | Designed for vacuum mixing, it ensures thorough blending without air pockets or contamination, improving the quality of slurry and chemical products. |
| Durable Construction | Made from SUS304 stainless steel, offering long-term durability and resistance to corrosion, ideal for chemical processing. |
| Automatic Operation | Features automatic operation for ease of use, minimizing manual labor and enhancing production efficiency. |
| Customizable Power and Voltage | Available in 220V and 110V voltage options to accommodate various power sources, with a low 24VDC input for safety. |
| Post-Sales Support | Comes with online support after the warranty period to ensure continued functionality and performance. |
| Certified Quality | CE certified, with a machinery test report and video outgoing inspection to guarantee reliability and safety. |
| OEM & ODM Services | Offers custom branding and design options to meet specific operational needs. |
| Power | 200W |
The machine is designed to efficiently mix slurry and powder-based materials, making it particularly suitable for the battery and electrode industry.
The vacuum mixing machine can handle slurries with a maximum viscosity of 10,000 cp at 600 r.p.m.
The dimensions of the machine are 330x320x570mm, and it has a net weight of 35kg.
Yes, the machine features automatic operation for ease of use, minimizing manual labor and enhancing production efficiency.
The machine is powered by a 200W motor, providing a spindle speed range of 1-1400 r.p.m.
Yes, it has a built-in single-stage vacuum pump that creates a vacuum level of -0.08 to -0.09 MPa for thorough blending.
The mixing container has a capacity of 500ml and is made from stainless steel with a vacuum-sealed design.
Yes, the machine is available in 220V and 110V voltage options, accommodating various power sources.
Yes, the machine comes with online support after the warranty period to ensure continued functionality and performance.
The machine is CE certified and comes with a machinery test report and video outgoing inspection to guarantee reliability and safety.
The machine comes with a one-year limited warranty, along with lifetime technical support.
It features a 3.5" color touch screen control, allowing easy setting of parameters such as mixing speed, mixing time, and vacuum on/off.
Yes, it is recommended to order a filter to remove larger particles in the slurry for best results.
The maximum mixing time is programmable up to 600 minutes.
Yes, it includes dual helical ribbon mixing blades built on the lid of the container.
