Backpack portable diamond core drill rig rock drill for Geological exploration portable rock drilling machine

SKU: 62369625951
Category: Mining Machinery

Product Description

R143,266

Quantity

Contact Support

Asset Finance Available

Explore funding with Afrimart's partners. Subject to provider approval.

Check Funding Options

Section:: Machinery
Category:: Mining Machinery
SKU:: 62369625951

Sold by Afrimart Online

Afrimart Online

Welcome to Afrimart Online, the premier destination offering an extensive range of products and streamlined services tailored to optimize your cross-border import procurement process. Our comprehensive platform serves as...

B21, China Town Mall, Midrand

011 805 0386

View Store

Delivery & Shipping

Estimated delivery

20 Dec, 2026

Delivery timing is confirmed with your order.

Learn more about our Shipping Policy

Shop with Confidence

Shipping
Information Returns
Policy Product
Support

Product Description

* HW-B30 is a kind of small portable sampling drilling equipment which is mainly suitable for mountain, transportation and energy. The machine can replace the traditional manual excavation, tank probe ,take samples and so on. It not only more efficient, but also reduces vegetation damage and protects the environment. It is an indispensable technical means in shallow geological exploration, such as regional geological mapping, geophysical exploration sampling, ancient geomagnetic sampling, and geological disaster prevention.
* Application fields: geophysical exploration sampling, regional geological mapping, mining vein exploration, mineral exploration, geotechnical engineering testing, various drilling

Product Parameters

Specification of the portable sampling drilling rig
model	HW-B30
borehole diameter (mm）	φ40—φ108mm
Drill hole depth (m)	30m（diameter 40mm)
application of rock types	Soil, medium hard（10grade）
rotation speed	2200r/min
Water consumption (L/H)	14.4L/H
power (cc)	173cc
rod rotation speed (r/min)	0-800
（1）Drill pipe diameter (mm)	φ32
（2）drill pipe length (mm)	720mm（including connector）
（3）Drill pipe material	Titanium alloys
（4）drill pipe weight (kg)	1.1kg
hydraulic motor
（1） Power	7.5hp
The host weight (kg)	23 kg

Details Images

Features of our backpack mining drilling machine:
1.Easy to carry ------------ A set of 3m standard Hengwang backpack rigs weighs only 25kg;
2.Flexible operation ------------ Easy to disassemble and easy to install, fast coring;
3.Efficient and durable ------------Special material diamond drill bit, fast drilling speed and long service life.

Application

Application fields of sampling drilling rig: geophysical exploration sampling, regional geological mapping, mining vein exploration, mineral exploration,geotechnical engineering testing, various drilling

Frequently Asked Questions

What is the maximum borehole diameter that the HW-B30 can drill?

The HW-B30 can drill boreholes with a diameter ranging from 40mm to 108mm.

How deep can the HW-B30 drill?

The maximum drilling depth of the HW-B30 is 30 meters.

What types of rock can the HW-B30 drill through?

The HW-B30 is suitable for drilling in soil and medium hard rock (up to 10 grade).

What is the weight of the HW-B30 drill rig?

The host weight of the HW-B30 is 23 kg.

How fast does the drill rotate?

The rotation speed of the drill can reach up to 2200 RPM.

What is the water consumption rate of the HW-B30?

The HW-B30 has a water consumption rate of 14.4 liters per hour.

What materials are the drill pipes made from?

The drill pipes are made from titanium alloys.

Is the HW-B30 portable?

Yes, the HW-B30 is designed to be portable and easy to carry, weighing only 25 kg for the backpack rig.

Can the HW-B30 be used for geological disaster prevention?

Yes, the HW-B30 can be used as a technical means in geological disaster prevention efforts.

What applications is the HW-B30 suitable for?

The HW-B30 is suitable for geophysical exploration sampling, regional geological mapping, mining vein exploration, and geotechnical engineering testing.

How easy is it to assemble and disassemble the HW-B30?

The HW-B30 is designed for flexible operation, making it easy to disassemble and assemble for quick coring.

What kind of drill bit does the HW-B30 use?

The HW-B30 uses a special material diamond drill bit for fast drilling speed and long service life.

What is the power output of the hydraulic motor?

The hydraulic motor of the HW-B30 has a power output of 7.5 horsepower.

What is the rod rotation speed of the HW-B30?

The rod rotation speed of the HW-B30 ranges from 0 to 800 RPM.

Is the HW-B30 environmentally friendly?

Yes, the HW-B30 reduces vegetation damage and is designed to protect the environment during drilling operations.
