Automatic CNC Welded 3-6mm Wire Mesh Panel Welding Machine Maker Machine

SKU: 1600682382488
Category: CNC industrial Machinery

3-6 roll mesh welding machine

Price per item

R1,885,999.00

Quantity

Contact Support

Asset Finance Available

Explore funding with Afrimart's partners. Subject to provider approval.

Check Funding Options

Book a consultation

Section:: Machinery
Category:: CNC industrial Machinery
SKU:: 1600682382488

Sold by Afrimart Online

Afrimart Online

Welcome to Afrimart Online, the premier destination offering an extensive range of products and streamlined services tailored to optimize your cross-border import procurement process. Our comprehensive platform serves as...

B21, China Town Mall, Midrand

011 805 0386

View Store

Plan your purchase

Delivery & Shipping

Estimated delivery

09 Jan, 2027

Delivery timing is confirmed with your order.

1-year warranty

Included with this product

View Shipping Policy

Shop with Confidence

Shipping
Information Returns
Policy Product
Support

Product Description

3-6 roll mesh welding machine

Roll mesh welding machine

Roll mesh welding line,also called automatic welded mesh machine,welded wire mesh roll machine,used to make road mesh,reinforcing mesh,construction mesh etc.

Model	DP-FP-2500BN	Wire diameter	2.5-6mm
Line wire pitch	50-300mm	Cross wire pitch	Min.50mm
Welding width	Max.2500mm	Roll length	Max.100mm
Welding speed	Max.75 times/min	Welding torch	48pcs
Welding transformer	150kva*6pcs	Mesh type	roll mesh and panel

Our electric control cabinets all use world famous brand electronic components.
Taiwan brand reducer, Japan brand PLC control system and servomotor, Franch brand and Sweden brand switch...

1. the line wire feeding from wire coils automatically, through the straight wheels device, make the line wire more straight and finished mesh will be more smooth;
2. cross wire need be pre-straight& cutting and then feeding from hopper automatically;
3. our welding electrodes used 20mm diameter pure copper, durable;
4. the welding transformer use water cooling system, protect machine can running well in hot area or long time working;
5. the main motor (5.5kw) and helical gear reducer connect the main axis directly, big transmission torque;
6. Cable carrier is imported from Germany, the best one all over the world, protect machine wire, not hung down;

Technical Specifications

Technical specifications for Automatic CNC Welded 3-6mm Wire Mesh Panel Welding Machine Maker Machine
Power	5.5 kW

Frequently Asked Questions

What is the model name of this machine?

The model is DP-FP-2500BN.

What types of mesh can this machine produce?

It produces roll welded mesh and mesh panels used for road mesh, reinforcing mesh and general construction mesh.

What wire diameters does the machine support?

Supported wire diameters for both line and cross wires range from 2.5 mm to 6 mm.

What are the maximum welding width and roll length specifications?

Maximum welding width is 2500 mm. The specification lists a maximum roll length of 100 mm.

What mesh pitches (spacing) can the machine handle?

Line wire pitch can be set between 50 mm and 300 mm. Minimum cross wire pitch is 50 mm.

What is the welding speed or production capacity?

Maximum welding frequency is 75 welds (times) per minute. Actual production output depends on mesh dimensions and layout.

How many welding torches and what welding power does it use?

The machine is equipped with 48 welding torches and uses six 150 kVA welding transformers (150 kVA × 6).

What cooling method is used for the welding transformers?

The welding transformers use a water-cooling system to maintain stable operation during long runs or in hot environments.

What are the key electrical and control components?

The electric control cabinet uses internationally known components: a Japan-brand PLC and servomotors, a Taiwan-brand reducer, and French- and Swedish-brand switches and control devices.

How does the machine ensure straight feeding of line and cross wires?

Line wires feed automatically from coils through straightening wheels for improved straightness. Cross wires are pre-straightened, cut, and automatically fed from a hopper.

What materials are used for welding electrodes and why?

Welding electrodes are 20 mm diameter pure copper, chosen for durability and reliable conductivity for consistent weld quality.

What are the main drive and transmission features?

The main motor is 5.5 kW directly coupled to a helical gear reducer for high transmission torque and stable mechanical drive.

What safety and cable management features are included?

The machine uses an imported cable carrier (from Germany) to protect wiring and prevent cables from hanging or being damaged during operation.

What are the site power and utility requirements?

The welding system uses six 150 kVA transformers (totaling 900 kVA), so a suitable three-phase high-power supply and proper electrical infrastructure are required. Exact mains specification and protections should be confirmed with the manufacturer based on local supply.

Is installation, commissioning and operator training provided?

Installation, commissioning and operator training are normally provided or available from the manufacturer/supplier. Confirm scope, travel, and costs with your sales contact when ordering.
