The New 330B Double Column Fully Automatic Metal Cutting Bandsaw is an industrial horizontal band saw designed for efficient and precise cutting of metal materials. With a maximum round cutting capacity of 330 mm and a square cutting capacity of 330 × 330 mm, the machin...
Select a product option to continue.
Explore funding with Afrimart's partners. Subject to provider approval.
The New 330B Double Column Fully Automatic Metal Cutting Bandsaw is an industrial horizontal band saw designed for efficient and precise cutting of metal materials. With a maximum round cutting capacity of 330 mm and a square cutting capacity of 330 × 330 mm, the machine is suitable for a wide range of metal-cutting applications.
The machine features hydraulic workpiece clamping and hydraulic blade tensioning, together with carbide and bearing blade guides to support stable cutting performance. Its adjustable blade speed of 20–80 m/min allows the cutting process to be adapted to different materials and applications.
| Specification | Details |
|---|---|
| Model | New 330B |
| Machine Type | Double Column Fully Automatic Metal Cutting Bandsaw |
| Cutting Orientation | Horizontal |
| Maximum Round Cutting Capacity | 330 mm |
| Maximum Square Cutting Capacity | 330 × 330 mm |
| Blade Speed | 20–80 m/min |
| Blade Size | 34 × 1.1 × 4,115 mm |
| Blade Guides | Carbide and bearing blade guides |
| Blade Tension | Hydraulic |
| Blade Motor | 4 kW |
| Hydraulic Motor | 0.75 kW |
| Coolant Motor | 0.135 kW |
| Multiple Feed | 500 mm × 10 times |
| Work Vice | Hydraulic |
| Machine Dimensions | 2,350 × 2,220 × 1,500 mm |
| Control System | NC control |
| Transmission/Speed Control | Inverter |
Hydraulic Workpiece Clamping
The hydraulic work vice securely holds the material during the cutting process, helping maintain stability throughout operation.
Hydraulic Blade Tensioning
Hydraulic blade tensioning provides controlled blade tension during operation.
Adjustable Cutting Speed
The blade operates across a speed range of 20–80 m/min, allowing the machine to accommodate different cutting requirements.
Automatic Chip Removal
An automatic chip conveyor is included to assist with removing chips generated during cutting and maintaining a cleaner working area.
The machine is supplied with:
Blade cleaning brush
Working light
Two roller tables, approximately 600 mm each
One bi-metal saw blade
Tool set with toolbox
NC control
Bundle cutting device
Inverter
Automatic chip conveyor
The 330B is suitable for industrial metal-cutting applications involving:
Steel profiles
Metal bars
Tubing and pipes
Structural metal
Fabrication materials
General industrial metal stock
Product Summary:
The New 330B Double Column Fully Automatic Metal Cutting Bandsaw combines a 330 mm cutting capacity, hydraulic clamping and blade tensioning, adjustable blade speed, NC control and automatic chip removal to provide an integrated solution for industrial metal-cutting operations.
| Model | New 330B |
|---|---|
| Machine Type | Double Column Fully Automatic Metal Cutting Bandsaw |
| Cutting Orientation | Horizontal |
| Maximum Round Cutting Capacity | 330 mm |
| Maximum Square Cutting Capacity | 330 × 330 mm |
| Blade Speed | 20–80 m/min |
| Blade Size | 34 × 1.1 × 4,115 mm |
| Blade Guides | Carbide and bearing blade guides |
| Blade Tension | Hydraulic |
| Blade Motor | 4 kW |
| Hydraulic Motor | 0.75 kW |
| Coolant Motor | 0.135 kW |
| Multiple Feed | 500 mm × 10 times |
| Work Vice | Hydraulic |
| Machine Dimensions | 2,350 × 2,220 × 1,500 mm |
| Control System | NC control |
| Transmission/Speed Control | Inverter |
The machine is designed to cut various metal materials, making it suitable for industries such as electromechanical, metallurgy, automotive, bridge construction, and shipbuilding.
The maximum sawing size for round materials is Ø330 mm, and for square materials, it is 330 x 330 mm.
The Automatic band saw machine 330B Double operates at a cutting speed that is 50% faster compared to traditional saws.
Bimetallic saw blades offer longer life and superior cutting capabilities, making them more efficient and cost-effective in the long run.
Yes, the machine is designed to be easy to operate, making it suitable for both experienced and new operators.
The main motor power of the machine is 4 kW with a 4-pole configuration.
The cutting speed of the band saw blade is adjustable at 25, 45, 64, and 80 m/min.
The machine enhances machining accuracy by 50%, ensuring clean and precise cuts, which is critical for quality production.
The overall equipment lifespan is extended by 50% compared to traditional saws, making it a durable investment.
Yes, the Automatic band saw machine 330B Double operates with minimal noise, providing a more comfortable working environment.
The hydraulic motor power is rated at 0.75 kW.
The machine is an energy-efficient solution that replaces traditional circular and bow saws, thus reducing overall energy consumption.
The machine offers adjustable cutting speeds and feed speeds, allowing it to handle a variety of cutting needs across different materials.
The single feed cylinder stroke length is 500 mm.
The machine is built for durability with long-lasting saw blades and minimal maintenance requirements, making it easier to maintain over time.
