Industrial Natural Npg Lpg Fuel Gas Burner For Boiler Spare Parts
Product Categories Show
1. Gas-fired burner.
2. One/Two-stage working.
3. Air-gas mixing at blast-pipe.
4. Ability to obtain optimal combustion values by regulating combustion air and blast-pipe.
5. Maintenance facilitated by the fact that the atomisation unit can be removed without having to remove the burner from the boiler.
6. Single stage manual flow adjustment.
7. Two stage Minimum and maximum air flow regulation for first and second stage by means of electric servomotor with pause closure of gate to prevent any heat dispersion to flue.
8. One flange and one insulating seal for boiler fastening.
9. Combustion air intake with air flow adjustment device.
10.Sliding boiler coupling flange to adapt to head protrusion of the various types of boilers.
11.Monophase electric motor to run fan.
12.Flame presence check by ionisation electrode.
13.Electrical plant protection rating IP40.
Various Models Of Machines For Your Choice
Specifications
Fuel gas burner
model | Calorific value(kcal) per hour | Highest Thermal output （kw） | Steam boiler model（t/h） |
moter power(kw) |
Valve group |
Screen |
Detection method |
damper |
program |
| ZXOQM-0.3 | 50k | 70 | 0.2 | - | DN15 | - | Ion needle | without | Siemens Control Box |
| ZXOQM-0.5-D | 100k | 140 | 0.2 | - | DN15 | - | without | ||
| ZXOQM-0.5-D | 200k | 240 | 0.3 | 0.37 | DN20 | small screen | have | small red box | |
| ZXOQM-0.5-S | 200k | 240 | 0.3 | 0.37 | DN20 | small screen | have | ||
| ZXOQM-1-D | 300k | 350 | 0.3 | 0.525 | DN25 | - | without | Siemens Control Box | |
| ZXOQM-1-S | 300k | 350 | 0.5 | 0.525 | DN25 | small screen | have | Ordinary gas without accompanying combustion | |
| ZXOQM-2-S | 400k | 500 | 0.7 | 0.75 | DN40 | 5 inch | electronic eye | ||
| ZXOQM-2.5 | 500k | 500 | 0.8 | 0.75 | |||||
| ZXOQM-3-S | 600k | 700 | 1 | 1.5 | |||||
| ZXOQM-3.5-S | 900k | 1050 | 0.5 | 1.5 | |||||
| ZXOQM-4-S | 1200k | 1400 | 2 | 3 | DN50 | Double detection | Ordinary gas with accompanying combustion | ||
| ZXOQM-4.5-S | 1800k | 2100 | 3 | 3 | DN50 | ||||
| ZXOQM-5-S | 2400k | 2800 | 4 | 7.5 | DN65 | 7 inch | |||
| ZXOQM-6-S | 3600k | 4200 | 6 | 9 | DN80 | ||||
| ZXOQM-7-S | 6000k | 7000 | 10 | 15 | DN100 | ||||
| ZXOQM-8-S | 9000k | 10500 | 12 | 22 | DN125 | ||||
| ZXOQM-9-S | 12000k | 14000 | 20 | 37 | DN150 |
Leading companies in the industry,Has more than 10 national patents,National High-Tech Enterprise,China's well-known brands and key recommended projects for the Belt and Road Initiative.
Dimensions Of Each Type Of Machine
For more models and sizes, please contact supplier or chat now
Product Features
Specification details are not available in this product description. Contact our team for more information.
This burner is designed to operate on methane, propane, and butane fuel gases.
The burner has a highest thermal output of 70 kW.
This burner operates at 220V and 50Hz.
Yes, this burner comes with a control box for easy operation and regulation.
Yes, it features a combustion air intake with an air flow adjustment device for optimal combustion.
Maintenance is facilitated by the removable atomisation unit, which can be accessed without removing the burner from the boiler.
The burner includes a flame presence check via an ionisation electrode and has an electrical plant protection rating of IP40.
The burner is designed for both one-stage and two-stage working, allowing for flexible operation.
Flame detection is achieved using an ion needle or an electronic eye, depending on the model.
The burner includes a flange and an insulating seal for secure fastening to the boiler.
The burner uses a monophase electric motor to run the fan.
Yes, it has a sliding boiler coupling flange to adapt to the head protrusion of various boiler types.
The steam boiler model capacity varies by the burner model; please refer to the specifications for details.
For more models and sizes, please contact the supplier directly or use the chat function available.
This burner is a product of a National High-Tech Enterprise and is recognized as a well-known brand in China.
