Product Description

Machine Structure

Working principle:

the sand rolls under the drive of the impeller and grinds each other to remove the impurities covering the surface of the sand, at the same time, water is added to form a strong water flow, and impurities and foreign objects with small specific gravity are taken away in time, and are discharged from the washing tank at the overflow port to complete the cleaning function.

Product Parameters

Model	Impeller Specification Outer diameter×width	Impeller Speed (r/min)	Maximum Feed Size (mm)	Capacity (t/h)	Motor Power (kw)	Overall Size length×width ×height (mm)
XGN-XS2610	Φ2600×1000	1.178	≤10	20-50	5.5	3255×1982×2690
XGN-XS2816	Φ2800×1600	1.177	≤10	30-60	11	3540×3000×2880
XGN-XS3016	Φ3000×1600	1.179	≤10	50-120	15	3845×3000×3080
XGN-XS3220	Φ3200×2000	1.18	≤10	70-160	15	4100×3560×3300
XGN-XS3230	Φ3200×3000	1.18	≤10	180-220	18.5	4100×3560×3300
XGN-XS3620	Φ3600×2000	1.18	≤10	100-180	18.5	4600×3560×3700

Frequently Asked Questions

What is the capacity of the 50tph silica bluestone sand washing machine?

The machine has a capacity ranging from 50 to 220 tons per hour, depending on the specific model you choose.

How does the sand washing machine work?

The machine operates by having the sand roll under the drive of the impeller, where it grinds against itself to remove impurities. Water is added to create a strong flow that carries away impurities and foreign objects.

What are the different models available?

The available models include XGN-XS2610, XGN-XS2816, XGN-XS3016, XGN-XS3220, XGN-XS3230, and XGN-XS3620, each with varying specifications.

What is the maximum feed size for the machine?

The maximum feed size varies by model, with sizes ranging from 10mm to 180mm.

What is the motor power for the various models?

Motor power varies by model, with options between 5.5 kW and 22 kW.

What is the overall size of the sand washing machine?

The overall size differs by model. For instance, the XGN-XS2610 measures 2550×1982×2690 mm, while the XGN-XS3620 measures 4600×3560×3700 mm.

Can this machine be used for other types of materials?

While designed primarily for silica bluestone, the machine can be adapted for washing other types of sand and aggregates.

Is the sand washing machine easy to operate?

Yes, the machine is designed for ease of operation, featuring user-friendly controls and minimal maintenance requirements.

What maintenance is required for the sand washing machine?

Regular maintenance includes checking the impeller, cleaning the overflow port, and ensuring the motor and electrical components are in good condition.

What are the benefits of using a sand washing machine?

Using a sand washing machine helps to remove impurities, improves the quality of the sand, increases production efficiency, and reduces the need for manual washing.

How long does it take to set up the machine?

Setup time can vary, but typically ranges from a few hours to a couple of days, depending on site conditions and installation requirements.

Does the machine come with a warranty?

Yes, the machine typically comes with a warranty; details may vary based on the manufacturer or supplier.

What is the impeller speed of the machine?

The impeller speed ranges from 1.177 to 1.179 revolutions per minute depending on the model.

Where can I purchase the sand washing machine?

You can purchase the machine through authorized distributors, online industrial equipment retailers, or directly from the manufacturer.

What is the expected lifespan of the machine?

With proper maintenance, the sand washing machine can have a lifespan of several years, often exceeding a decade.
