48 Spindles High Speed Braided Rope Making Machine 4 Spindles Leather Cord Braiding Machine

SKU: 1601020868238
Category: Industrial Machinery

Main Feature

Price per item

R130,299.00

Quantity

Contact Support

Asset Finance Available

Explore funding with Afrimart's partners. Subject to provider approval.

Check Funding Options

Section:: Machinery
Category:: Industrial Machinery
SKU:: 1601020868238

Sold by Afrimart Online

Afrimart Online

Welcome to Afrimart Online, the premier destination offering an extensive range of products and streamlined services tailored to optimize your cross-border import procurement process. Our comprehensive platform serves as...

B21, China Town Mall, Midrand

011 805 0386

View Store

Plan your purchase

Delivery & Shipping

Estimated delivery

06 Jan, 2027

Delivery timing is confirmed with your order.

1-year warranty

Included with this product

View Shipping Policy

Shop with Confidence

Shipping
Information Returns
Policy Product
Support

Product Description

Main Feature

Application：

* Shielding for wire and cable products
* Sanitary hose (Plumbing hose) product
* Teflon hose
* Low pressure hose and high pressure hose
* Irony steam hose
* Refrigerating fluid charge hose
* Hydraulic hose

Braiding Material :

* Stainless steel wire (0.10-0.35mm)
* Nylon wire
* Alumium wire (0.15-0.30mm)
* Carbon steel
* Polyester yarn
* Cotton yarn
* Aramid fiber

Technical Features：

* Core centralizing unit
* Individual carrier tension control
* Operating speeds:
* 16 Carrier 55 rpm 24 Carrier 50 rpm

36 Carrier 36 rpm 48 Carrier 20 rpm

* Gear driven take-off for accurate control
* Braid patterns (2 over 2, and 1 over 1)
* Inverter motor drive for controlled acceleration and deceleration
* Adjustable traverse mechanism to accommodate reel variation
* Digital production counter

Options：

* Empty bobbin detector
* Central lubrication system (recommended)
* Enhanced Sound Enclosure
* Keel lubricator (recommended)
* Advance display, variable speed
* Longitudinal tape applicator
* Motor driven capstan(speed reducer capstan )
* Single deck( Double Deck) Braiding System

Specification

	GLT 16L-114B	GLT 24L-114B	GLT 36L-114B	GLT 48L-114B
Motor power	0.75kw	1.1kw	1.5kw	2.2kw
Voltage	3 Phase 380V Customized	3 Phase 380V Customized	3 Phase 380V Customized	3 Phase 380V Customized
Spindle RPM	55RPM	45RPM	36RPM	20RPM
Traction RPM	5.26-26RPM	4.26-18.5RPM	2.13-10.8RPM	0.13-0.58RPM
Take Up Reel	Attachment	Attachment	Charge for take up reel	Charge for take up reel
Hose Diameter	≤16mm	≤24mm	≤36mm	≤48mm
Traction Gear	200	200	800	800
Spindle NO	16 Spindle	24Spindle	36Spindle	48Spindle
Weight	280kg	305kg	680kg	480kg
Bobbin Size	Out edge 56× Inner edge 22×High170mm Cubage:354cm3
Apply	Change spindle can braiding wire and yarn
Dimenson	6205001580mm	8907201680mm	110010001780mm	150013002100mm

production line

Technical Specifications

Technical specifications for 48 Spindles High Speed Braided Rope Making Machine 4 Spindles Leather Cord Braiding Machine
Bobbin Size	Out edge 56× Inner edge 22×High170mm Cubage:354cm3
Apply	Change spindle can braiding wire and yarn

Frequently Asked Questions

What materials can be used with the 48 Spindles High Speed Braided Rope Making Machine?

The machine can handle various materials including stainless steel wire, nylon wire, aluminum wire, carbon steel, polyester yarn, cotton yarn, and aramid fiber.

What is the maximum hose diameter that this machine can braid?

The machine can braid hoses with a maximum diameter of up to 48mm.

What are the operating speeds for the different spindle configurations?

For 16 spindles, the speed is 55 RPM; for 24 spindles, it's 50 RPM; for 36 spindles, it's 36 RPM; and for 48 spindles, it's 20 RPM.

Can this machine be customized for different voltage requirements?

Yes, the machine can be customized for different voltage requirements, specifically available in 3 Phase 380V.

What are the dimensions of the machine?

The dimensions vary by spindle configuration: 620*500*1580mm for 16 spindles, 890*720*1680mm for 24 spindles, 1100*1000*1780mm for 36 spindles, and 1500*1300*2100mm for 48 spindles.

Does the machine include any safety features?

Yes, options include an empty bobbin detector and a central lubrication system to ensure safe and efficient operation.

What type of braiding patterns can be produced?

The machine can produce braiding patterns of 2 over 2 and 1 over 1.

Is there a digital counter available for production tracking?

Yes, the machine is equipped with a digital production counter, allowing for easy tracking of production output.

What is the weight of the machine?

The weight of the machine varies by spindle configuration: 280 kg for 16 spindles, 305 kg for 24 spindles, 680 kg for 36 spindles, and 480 kg for 48 spindles.

Can the machine accommodate different reel sizes?

Yes, the adjustable traverse mechanism allows the machine to accommodate variations in reel sizes.

Is there an option for noise reduction?

Yes, an enhanced sound enclosure is available as an option to reduce noise during operation.

What is the motor power for the 48 spindle configuration?

The motor power for the 48 spindle configuration is 2.2 kW.

Is the machine suitable for high-pressure hose production?

Yes, this machine is suitable for producing both low pressure and high pressure hoses.

What is the purpose of the gear driven take-off feature?

The gear driven take-off feature provides accurate control over the braiding process.

Can different types of yarn be braided using this machine?

Yes, the machine can braid various types of yarn including cotton, polyester, and aramid fiber.
