3D CNC Optical Coordinate Portable CMM Measurement Low Cost Coordinate Measuring Machine
The 3D CNC Optical Coordinate Portable CMM Measurement Machine is designed for accuracy and convenience. This low-cost coordinate measuring machine is perfect for various industries. It helps you measure points, lines, and shapes with high precision. Whether you are in...
Select a product option to continue.
Asset Finance Available
Check Funding Options
Explore funding with Afrimart's partners. Subject to provider approval.
Product Description
3D CNC Optical Coordinate Portable CMM Measurement Low Cost Coordinate Measuring Machine
The 3D CNC Optical Coordinate Portable CMM Measurement Machine is designed for accuracy and convenience. This low-cost coordinate measuring machine is perfect for various industries. It helps you measure points, lines, and shapes with high precision. Whether you are in manufacturing or electronics, this machine is your reliable measurement partner.
Specifications
| Attribute | Details |
|---|---|
| Model Number | ZL-1505 |
| Measurement Accuracy (X,Y) | 3.0 + L/200 (μm) |
| Measurement Accuracy (Z) | 5.0 + L/200 (μm) |
| X,Y Axle Run Speed | 0-400 mm/s (selection) |
| Z Axle Run Speed | 0-100 mm/s (selection) |
| Repeated Accuracy | 0.003 mm |
| Warranty | 2 years |
| Operation Mode | Software |
| Grating Ruler Resolution | 0.5 μm |
| Camera | SBK-HC536 1/2 inch 700 color high definition |
Key Features
High precision with a measurement accuracy of 3.0 + L/200 (μm).
Fast operation with selectable speeds up to 400 mm/s.
Lightweight and portable design for easy transport and use.
Compatible with advanced software for detailed measurement reporting.
2-year warranty for peace of mind.
Applications
Measuring components in electronics and machinery.
Quality control in manufacturing processes.
Inspection of molds and fittings in the automotive industry.
Precision measurement in medical equipment production.
Used in the production of circuit boards and LCD screens.
Frequently Asked Questions
What industries can benefit from the 3D CNC Optical Coordinate Portable CMM?
The 3D CNC Optical Coordinate Portable CMM is ideal for various industries including manufacturing, electronics, automotive, and medical equipment production.
What is the measurement accuracy of this machine?
The measurement accuracy is 3.0 + L/200 (μm) for the X and Y axes, and 5.0 + L/200 (μm) for the Z axis.
How fast can the machine operate?
The machine has a selectable run speed of up to 400 mm/s for the X and Y axes and up to 100 mm/s for the Z axis.
What is the repeated accuracy of the machine?
The repeated accuracy of the 3D CNC Optical Coordinate Portable CMM is 0.003 mm.
Is the machine easy to transport?
Yes, the machine has a lightweight and portable design, making it easy to transport and use in different locations.
What type of software is compatible with this machine?
The machine is compatible with advanced software that allows for detailed measurement reporting and analysis.
What kind of warranty does the product come with?
The product comes with a 2-year warranty, providing peace of mind for users.
Can the machine be used for quality control in manufacturing?
Yes, it is particularly useful for quality control processes in manufacturing to ensure precision and accuracy.
How does this machine perform in medical equipment production?
The machine provides precision measurement essential for the high standards required in medical equipment production.
Is there a specific application for inspecting molds and fittings?
Yes, the machine is effective for inspecting molds and fittings in the automotive industry, ensuring they meet specifications.
What is the grating ruler resolution of this machine?
The grating ruler resolution of the 3D CNC Optical Coordinate Portable CMM is 0.5 μm.
Can this machine measure complex shapes?
Yes, the machine is designed to measure points, lines, and complex shapes with high precision.
What features make this machine cost-effective?
The combination of high precision, advanced capabilities, and low cost compared to traditional CMMs makes it a cost-effective solution.
Is training required to operate the machine?
While basic operation is user-friendly, training on the associated software and machine features is recommended for optimal use.
What types of components can be measured with this machine?
It can measure a variety of components, including those used in electronics, machinery, circuit boards, and LCD screens.
Technical Specifications
No approved technical specifications are available yet. Please refer to the product description or contact our team.
