Product Description

2JPB Series Electric Winches

The 2JPB Series Electric Winches are designed for high-performance material handling tasks, such as pulling heavy loads in construction, mining, and other industrial sectors. The winches feature dual wire ropes for better load distribution and smoother operation.

Model Overview:

Model	Main Wire Rope Min. Tension	Average Speed (Main Wire Rope)	Secondary Wire Rope Speed	Wire Rope Diameter	Drum Diameter	Rim Diameter	Wire Rope Size (Main Drum)	Wire Rope Size (Secondary Drum)	Electric Motor Power	Rotating Speed	Dimensions (LxWxH)	Weight
2JPB-7.5	8000N	1(±5%) m/s	1(±5%) m/s	9.3mm (main), 9.3mm (secondary)	205mm	350mm	45m	45m	7.5KW	1440r/min	1210x565x490mm	390kg
2JPB-15	14000N	1.1(±5%) m/s	1.5(±5%) m/s	12.5mm (main), 11mm (secondary)	225mm	435mm	80m	100m	15KW	1460r/min	1525x660x620mm	660kg
2JPB-22	20000N	1.2(±5%) m/s	1.5(±5%) m/s	14mm (main), 11mm (secondary)	280mm	510mm	80m	100m	22KW	1470r/min	1600x730x640mm	980kg
2JPB-30	27500N	1.2(±5%) m/s	1.6(±5%) m/s	15.5mm (main), 14mm (secondary)	280mm	510mm	80m	110m	30KW	1470r/min	1650x820x700mm	1155kg
2JPB-55	44000N	1.2(±5%) m/s	1.8(±5%) m/s	18.5mm (main), 16mm (secondary)	350mm	625mm	100m	130m	55KW	1470r/min	2070x1010x890mm	2125kg

Key Features:

Dual Wire Rope System: For efficient load distribution and enhanced stability.
Variable Speed: Allows for precise control of the winch speed based on load requirements.
Powerful Electric Motors: From 7.5KW to 55KW, providing reliable power for heavy-duty lifting and pulling tasks.
Durability: Built with robust materials, these winches are designed for long-lasting performance in demanding environments.
Multiple Models: Available in various sizes to accommodate different wire rope diameters and load capacities.

These winches are ideal for industries requiring high-performance hoisting and pulling operations, ensuring safe and efficient handling of heavy materials.

Frequently Asked Questions

What is the maximum load capacity of the 2JPB Series Electric Winches?

The load capacity varies by model, with the 2JPB-7.5 having a maximum capacity of 8000N, and the 2JPB-55 capable of handling up to 44000N.

What are the advantages of using dual wire ropes?

Dual wire ropes provide better load distribution, enhancing stability and ensuring smoother operation during heavy lifting tasks.

What is the average speed of the winches?

The average speed for the main wire rope varies by model, ranging from 1 m/s for the 2JPB-7.5 to 1.2 m/s for the 2JPB-30 and 2JPB-22.

Are these winches suitable for outdoor use?

Yes, the 2JPB Series Electric Winches are built with robust materials designed for durability in demanding environments, making them suitable for outdoor industrial applications.

What electric motor power do the winches have?

The winch motor power ranges from 7.5KW for the 2JPB-7.5 model to 55KW for the 2JPB-55 model, providing reliable power for heavy-duty tasks.

Can the winch speed be adjusted?

Yes, these winches feature variable speed control, allowing for precise adjustments based on load requirements.

What are the dimensions and weight of the winches?

Dimensions and weight vary by model. For example, the 2JPB-7.5 measures 1210x565x490mm and weighs 390kg, while the 2JPB-55 measures 2070x1010x890mm and weighs 2125kg.

What industries can benefit from using the 2JPB Series Electric Winches?

These winches are ideal for construction, mining, and other industrial sectors that require high-performance hoisting and pulling operations.

Is installation of the winches complicated?

Installation can vary depending on the specific model and application. It is recommended to follow the manufacturer's guidelines or consult a professional for installation.

What is the wire rope diameter for each model?

The main wire rope diameter varies by model, ranging from 9.3mm for the 2JPB-7.5 to 18.5mm for the 2JPB-55.

What is the rotating speed of the winch motor?

The rotating speed of the electric motors in these winches ranges from 1440 r/min to 1470 r/min depending on the model.

What should I do if I encounter a problem with the winch?

If you experience any issues, consult the user manual for troubleshooting tips or contact customer support for assistance.

Are replacement parts available for these winches?

Yes, replacement parts are typically available through authorized dealers or directly from the manufacturer.

What safety features do these winches have?

The winches are designed with robust materials for durability, and their variable speed control allows for safe operation under varying load conditions.

How can I determine which model is right for my application?

Consider the load requirements, wire rope diameter, and speed needs for your application. Each model has specific capacities and features suited for different tasks.
