1300*2500 mm atc wood carving cnc cabinet machine
- Section : Machinery
- Category : Woodworking Machinery
- SKU : 1601197228668
Wood Carving CNC Cabinet Machine
The 1300x2500 mm ATC Wood Carving CNC Cabinet Machine is a versatile and high-performance CNC router designed for various woodworking and manufacturing applications. This machine features an ATC (Automatic Tool Change) system, making it suitable for high-volume production. The KND controller system, servo drive and motor, and vacuum table enhance its precision and efficiency. The Taiwan Square rail and servo motors contribute to its superior performance, ensuring smooth and accurate carving and cutting.
Key Features:
- Industrial LED Design: A modern and aesthetically pleasing design with industrial-grade LED lighting.
- KND Control System: Reliable and user-friendly control for precise operation.
- Servo Driver and Motor: Ensures high performance with greater speed and stability.
- Taiwan Square Rail: High-quality, durable guide rail for smooth operation and increased precision.
- Vacuum Table: Powerful suction to hold materials securely, making it easier to carve even smaller pieces.
- High-Precision Spindle: 9.0kW ATC CHINA HQD air-cooling spindle ensures fast tool changes and precise cuts.
- Machine Accuracy: ±0.05mm for highly accurate results.
Technical Parameters:
| Description | Parameter |
|---|---|
| X Y Z Axis Working Area | 1300mm * 2500mm * 200mm |
| Guide Rail | TBI Square Rail |
| Spindle | 9.0kW ATC CHINA HQD Air Cooling Spindle |
| Transmission Way | Helical Gear Rack for XY Axis, Ball Screw for Z Axis |
| Machine Accuracy | ±0.05mm |
| Control System | Beijing KND Servo Motor (Made in China) |
| Machine Table | Vacuum Table |
| Driving System | Servo Drive and Motor |
Applications:
- Wood Furniture Industry: Used for carving wave plates, fine patterns, antique furniture, wooden doors, screens, craft sash, composite gates, cupboard doors, interior doors, sofa legs, and headboards.
- Advertising Industry: Suitable for creating advertising signs, acrylic engraving and cutting, crystal word making, blaster molding, and more.
- Die Industry: Ideal for sculpting molds from materials like copper, aluminum, iron, and other metals, as well as non-metallic materials like artificial marble, PVC pipe, wooden planks, and plastic sheeting.
This CNC router provides exceptional versatility and precision for a variety of woodworking, advertising, and die industries, and it is ideal for high-accuracy and high-volume production.
- Shipping Timeframes: All orders are processed within 2-5 business days (excluding weekends and holidays). After your order has been processed, the estimated delivery time is before 03 Feb, 2026, depending on customs, Please note that due to high demand, some items may experience longer shipping times, which will be communicated at order confirmation email.
- Order Processing Time: Please allow 2-5 business days for us to process your order before it is shipped . Orders placed after 16:00 on Fridays, or during weekends and public holidays, will begin processing on the next business day. Processing times may be extended during peak seasons or sales events.
- Manufacturing Time: Some products needs manufacturing time, the manufacturing process will take approximately 10-30 business days depending on the product. This timeframe may vary depending on the complexity of the product and current demand. but this will be communicated with you during order confirmation.
- Returns and Exchanges: We offer a 30-day return policy for most items. If you are not completely satisfied with your purchase, you may return it within 30 days of receipt for a refund or exchange. Items must be unused, in their original packaging, and accompanied by proof of purchase. Return shipping costs are the responsibility of the customer, unless the item was damaged or defective upon arrival.
1. What is the working area of the 1300*2500 mm ATC wood carving CNC cabinet machine?
The working area of this machine is 1300 mm in the X axis, 2500 mm in the Y axis, and 200 mm in the Z axis.
2. What type of control system does this CNC machine use?
This machine uses the Beijing KND control system, which is reliable and user-friendly for precise operations.
3. What are the main applications of this CNC router?
This CNC router is suitable for various applications including woodworking for furniture, advertising sign creation, and die industry sculpting.
4. What features enhance the precision of this CNC machine?
Key features that enhance precision include the high-precision spindle, Taiwan square rail, and servo drive and motor.
5. What is the accuracy of the machine?
The machine provides a high accuracy of ±0.05 mm, ensuring highly precise results in carving and cutting.
6. How does the Automatic Tool Change (ATC) system work?
The ATC system allows for quick and automated tool changes, significantly improving efficiency during high-volume production.
7. What type of spindle is used in this CNC machine?
It features a 9.0 kW ATC CHINA HQD air-cooling spindle, which ensures fast tool changes and precise cuts.
8. Is this machine suitable for high-volume production?
Yes, the machine is designed for high-volume production, making it ideal for businesses that require efficient and consistent output.
9. What materials can be processed with this CNC router?
This CNC router can process various materials including wood, acrylic, metal (copper, aluminum, iron), and non-metallic materials like PVC pipe and plastic sheeting.
10. What kind of vacuum table feature does this machine have?
The vacuum table provides powerful suction to securely hold materials in place, facilitating easier carving even for smaller pieces.
11. What is the driving system used in this CNC machine?
This machine uses a servo drive and motor system, which provides high performance with greater speed and stability.
12. What type of guide rail is used in the CNC machine?
It utilizes a TBI square rail, which is high-quality and durable, ensuring smooth operation and increased precision.
13. Can this machine be used for creating advertising signs?
Yes, it is suitable for creating advertising signs, including acrylic engraving and cutting.
14. What is the machine's transmission method?
The transmission method includes helical gear rack for the XY axis and ball screw for the Z axis, enhancing precision and performance.
15. Is the machine easy to operate for beginners?
Yes, the KND control system is designed to be user-friendly, making it accessible for beginners while still suitable for experienced operators.
