The Stainless Steel Crystallization Reactor is an essential piece of laboratory equipment for the crystallization process, specifically designed for the production of high-purity methanol crystals. Built with SUS304 stainless steel, this reactor offers exceptional durability and corrosion resistance, making it ideal for chemical processes requiring precise temperature control and vacuum conditions.
This Stainless Steel Crystallization Reactor is the perfect choice for researchers and laboratories engaged in chemical processing, offering reliable performance for methanol crystallization and other sensitive chemical processes.
The stainless steel crystallization reactor is an ideal equipment for crystallization, which combines the dual functions of the reactor and the filter. The stainless steel crystallization reaction kettle is connected with a vacuum filtration device, which is often used for the crystallization and filtration . It can realize constant high or low temperature inside the kettle body.
Product Display
Product Details
Product Parameters
| Stainless Steel Crystallization Reactor | |||
| Product Model | SCR-50 | SCR-100 | SCR-200 |
| Kettle Body Material | SUS304 | ||
| Frame Material | SUS304 | ||
| Pipe Material | SUS304 | ||
| Kettle Volume | 50L | 100L | 200L |
| Recovery Tank Volume | 20L | 40L | 80L |
| Collection Tank Volume | 50L | 80L | 150L |
| Interlayer | With 50mm thermal insulation layer | ||
| Mezzanine Import and Export | 1/2" | 3/4" | 1" |
| Condenser | 0.5m2 | 1m2 | 2m2 |
| Condenser Inlet and Outlet | 1/2" | 3/4" | 3/4" |
| Filter | 20L | 30L | 60L |
| Filtration Accuracy | 15-40um | ||
| The distance from the discharge port to the ground | 200-300mm | ||
| Kettle Reaction Temperature | -80~250℃ | ||
| Ultimate Vacuum | -0.098Mpa | ||
| Sealing Structure | Machinery Seal | ||
| Stirring Speed | Frequency 0-120rpm | ||
| Stirring Power | 0.5kw | 0.75kw | 1.1kw |
| Pressure | 220V/380V | ||
Application Scenario
| Kettle Body Material | SUS304 |
|---|---|
| Frame Material | SUS304 |
| Pipe Material | SUS304 |
| Interlayer | With 50mm thermal insulation layer |
| Filtration Accuracy | 15-40um |
| The distance from the discharge port to the ground | 200-300mm |
| Kettle Reaction Temperature | -80~250℃ |
| Ultimate Vacuum | -0.098Mpa |
| Sealing Structure | Machinery Seal |
| Stirring Speed | Frequency 0-120rpm |
| Pressure | 220V/380V |
| High-Quality Material | Constructed from SUS304 stainless steel, ensuring a long lifespan and resistance to corrosion, perfect for chemical reactions involving methanol or other reactive substances. |
| Variable Kettle Volume | Available in a range of kettle volumes from 50L to 200L, suitable for laboratory-scale crystallization experiments and small batch production. |
| Efficient Collection Tank | Includes a 50L to 150L collection tank to collect crystallized products effectively, ensuring a smooth and uninterrupted process. |
| Precise Temperature Control | The reactor can maintain a reaction temperature range of -80°C to 250°C, allowing for versatile processing conditions and precision control. |
| Thermal Insulation | Features a 50mm thermal insulation layer on the interlayer, ensuring energy efficiency and better control over internal temperatures. |
| Vacuum Conditions | Capable of achieving an ultimate vacuum of -0.098Mpa, essential for processes requiring low pressure environments. |
| Filtration System | Equipped with a filter for filtration accuracy between 15-40um, ensuring impurities are efficiently removed during the crystallization process. |
| Powerful Stirring | The stirring power ranges from 0.5kW to 1.1kW, facilitating effective mixing and ensuring the quality of the crystallization process. |
| Easy Operation | Designed for ease of use, the reactor comes with automatic controls, making it user-friendly for laboratory operators. |
| Safety & Reliability | Features safety mechanisms to prevent overpressure and ensure stable operation during high-temperature and vacuum processes. |
| After-Sales Support | Video outgoing inspection and machinery test reports are provided to guarantee performance. Additionally, technical support is available for ongoing assistance. |
The reactor is constructed from SUS304 stainless steel, ensuring durability, corrosion resistance, and suitability for chemical processes.
The reactor is available in kettle volumes ranging from 50L to 200L, allowing for various laboratory-scale crystallization experiments.
The reactor can maintain a reaction temperature range of -80°C to 250°C, providing versatility in processing conditions.
Yes, the reactor includes a collection tank with volumes ranging from 50L to 150L to effectively collect crystallized products.
The filtration system has an accuracy range of 15-40um, ensuring efficient removal of impurities during the crystallization process.
The reactor features safety mechanisms designed to prevent overpressure and ensure stable operation under high-temperature and vacuum conditions.
Yes, the reactor is designed for ease of use with automatic controls, making it user-friendly for laboratory operators.
After-sales support includes video outgoing inspection, machinery test reports, and technical support for ongoing assistance.
Yes, the reactor is suitable for various sensitive chemical processes beyond methanol crystallization.
The stirring power of the reactor ranges from 0.5kW to 1.1kW, facilitating effective mixing during the crystallization process.
The reactor can achieve an ultimate vacuum of -0.098Mpa, which is essential for processes requiring low-pressure environments.
The reactor features a 50mm thermal insulation layer on the interlayer, ensuring energy efficiency and better control over internal temperatures.
The distance from the discharge port to the ground is between 200-300mm, facilitating easy access for collection.
Yes, the reactor is available in different models, including SCR-50, SCR-100, and SCR-200, corresponding to different kettle volumes.
The stirring speed can be adjusted using frequency control, ranging from 0 to 120rpm for optimal mixing.
