10000 Liters 10m3 LPG Skid Cooking Gas Filling Station
- Section : Machinery
- Category : Gasoline Generators
- SKU : 1600576978179
10000 Liters 10m3 LPG Skid Cooking Gas Filling Station
The 10000 Liters 10m3 LPG Skid Cooking Gas Filling Station is designed for safe and efficient storage and filling of liquefied petroleum gas (LPG). This portable filling station is specially designed for the Nigerian market and offers an excellent solution for industries that require a reliable and secure LPG storage system.
Key Features:
- High-Quality Material: Made with Q345R material, ensuring durability and reliability under high-pressure conditions.
- Max Working Pressure: The station operates at a maximum working pressure of 1.6 MPa, designed to safely handle high-pressure LPG storage.
- Designed Pressure: Engineered for a designed pressure of 1.77 MPa, meeting industrial standards for LPG filling stations.
- Portable Design: The skid-mounted design allows for easy transport and installation, making it suitable for various industrial applications.
- Application: Ideal for industrial LPG storage and filling, providing a safe and efficient solution for cooking gas supply.
- Core Components: Includes a PLC and pressure vessel, ensuring reliable and automated operation for gas filling.
- Warranty: Comes with a 1-year warranty, ensuring long-term reliability and peace of mind.
- Long Service Life: Designed to offer a long service life with minimal maintenance requirements.
- After-Sales Support: Free spare parts and excellent after-sales support to ensure optimal performance throughout its lifetime.
- Certification: Certified with ISO9001, guaranteeing adherence to quality management standards.
- Dimensions: Customized dimensions to meet specific customer needs, ensuring suitability for various installation environments.
Product Info Gallery
LPG STORAGE TANK
LPG vessels is made of special material Q345R alloy steel. As a professional China LPG Vessels manufacturer in China,we have the aptitude to design and manufacture different type of pressure vessel, manufacturing prooessing of LPG Vessels is complex and strict.
LPG Skid Station.
The structure of LPG Skid-mounted Station is divided into four parts, the tank, skid section, LPG dispenser, EX electronic control box. LPG skid section consists of a storage tank, pipe section and two pumps, one pump forms unloading system, another forms filling system.
Product Parameters
| Model(m3) | Design pressure(MPa) | Cylinder size (Dia*length*thickness)mm | Dimensions (Dia/height/length) mm | Material | Total netweight(Kg) |
| 5 | 1.77MPa | DN1200*4000*10 | 1800*1800*6000 | Q345R | 3200kg |
| 10 | 1.77MPa | DN1200*4400*10 | 2000*2000*6000 | Q345R | 3500kg |
| 15 | 1.77MPa | DN1600*5250*12 | 2300*2000*7000 | Q345R | 5200kg |
| 20 | 1.77MPa | DN1800*5800*12 | 2500*2000*1000 | Q345R | 3800kg |
| 25 | 1.77MPa | DN2200*7100*12 | 2600*2200*1200 | Q345R | 7000kg |
| 30 | 1.77MPa | DN2000*5500*12 | 2450*2000*7500 | Q345R | 7500kg |
Advantage
1) linear type structure is simple, easy installation and maintenance.
2) Design and reasonable operation is simple and convenient
3) can be centralized control, safe and reliable
4) low daily evaporation rate, less loss.
