Industrial Multifunction Coffee Premade Bag Rotary Doypack Stand Up Zipper Bag Filling Sealing Packing Machine
- Section : Machinery
- Category : Multi-Function Packaging Machines
- SKU : 1600688948007
PREMADE POUCH LOAD OPEN FILL SEAL MACHINE
The BIG/LARGE/HEAVY DUTY PREMADE POUCH LOAD OPEN FILL SEAL machine is an automated solution for handling premade pouches, including three-side seal bags, stand-up bags, ziplock bags, gusset bags, and more. It performs a fully automated cycle for bag pick-up, opening, filling, sealing, and outputting the finished product. This versatile machine is designed for food packaging, making it ideal for items like coffee, frozen foods, biscuits, cereals, nuts, powdered materials, candy, and more.
Key Features
- Versatile Pouch Types: Compatible with various preformed bags such as three-side seal, stand-up, ziplock, and gusset bags.
- Automated Process: Handles automatic bag pick-up, opening, filling, sealing, and finished product output.
- Wide Application: Suitable for packaging different types of food and non-food items.
- Precision & Reliability: Features PLC control and cylinder-driven operations for low error rates and easy maintenance.
- Adjustable Bag Magazine: Accommodates various bag sizes and shapes for flexible packaging requirements.
- Vacuum Function: Equipped with a vacuum pump for vacuum sealing capabilities.
- Electric Induction Components: Ensures smooth operation and accurate packing.
Product Packaging
The machine is designed to handle a wide range of products and pouch sizes, making it a flexible and efficient choice for high-volume packaging needs.
Product Parameters
| Model | GDD-1-300 | GDD-1-300L | GDD-1-300M |
|---|---|---|---|
| Power Voltage | AC 220/50 | AC 220/50 | AC 220/50 |
| Gas Source | 0.5 m³/min, 0.65 MPa | 0.5 m³/min, 0.65 MPa | 0.5 m³/min, 0.65 MPa |
| Electric Power | 500W | 500W | 500W |
| Packing Speed | 6-15 bags/min | 5-8 bags/min | 6-15 bags/min |
| Sealing Width | 10 mm | 10 mm | 10 mm |
| Temperature Range | 0-300°C | 0-300°C | 0-300°C |
| Bag Size | 100≤Width≤300, 100≤Length≤430 | 100≤Width≤300, 100≤Length≤430 | 80≤Width≤300, 100≤Length≤430 |
| Suitable Bag Type | Three side sealing, Doypack (no zipper) | Doypack (with zipper) | Accordion bag (M fold bag) |
| External Size (L×W×H) | 1827×676×1611 mm | 1827×676×1656 mm | 1827×676×1611 mm |
| Net Weight | 315 kg | 315 kg | 315 kg |
Applications
- Food Packaging: Ideal for items such as coffee, frozen food, biscuits, cereals, nuts, powdered materials, candy, and more.
- Non-Food Applications: Suitable for a range of other products needing similar packaging methods.
This machine offers high-efficiency and reliable performance, ensuring your packaging process is both effective and cost-efficient.
- Shipping Timeframes: All orders are processed within 2-5 business days (excluding weekends and holidays). After your order has been processed, the estimated delivery time is before 03 Feb, 2026, depending on customs, Please note that due to high demand, some items may experience longer shipping times, which will be communicated at order confirmation email.
- Order Processing Time: Please allow 2-5 business days for us to process your order before it is shipped . Orders placed after 16:00 on Fridays, or during weekends and public holidays, will begin processing on the next business day. Processing times may be extended during peak seasons or sales events.
- Manufacturing Time: Some products needs manufacturing time, the manufacturing process will take approximately 10-30 business days depending on the product. This timeframe may vary depending on the complexity of the product and current demand. but this will be communicated with you during order confirmation.
- Returns and Exchanges: We offer a 30-day return policy for most items. If you are not completely satisfied with your purchase, you may return it within 30 days of receipt for a refund or exchange. Items must be unused, in their original packaging, and accompanied by proof of purchase. Return shipping costs are the responsibility of the customer, unless the item was damaged or defective upon arrival.
1. What types of bags can the Industrial Multifunction Coffee Premade Bag Machine handle?
The machine is compatible with various types of premade bags, including three-side seal bags, stand-up bags, ziplock bags, and gusset bags.
2. What is the maximum bag size that can be used with this machine?
The machine can handle bags with a width of up to 300 mm and a length of up to 430 mm.
3. What is the packing speed of the machine?
The packing speed varies by model, with speeds ranging from 5 to 15 bags per minute, depending on the specific machine configuration.
4. Is the machine suitable for food packaging?
Yes, the machine is designed for food packaging and is ideal for products such as coffee, frozen foods, biscuits, cereals, nuts, powdered materials, and candy.
5. Does the machine have a vacuum sealing option?
Yes, the machine is equipped with a vacuum pump that allows for vacuum sealing capabilities.
6. What is the power consumption of the machine?
The machine operates on an electric power of 500W.
7. How does the machine ensure precision during operation?
The machine features PLC control and cylinder-driven operations, which contribute to low error rates and easy maintenance.
8. What is the temperature range for sealing?
The sealing temperature range for the machine is between 0 to 300°C.
9. What are the dimensions of the machine?
The external dimensions of the machine are 1827 mm in length, 676 mm in width, and 1611 or 1656 mm in height, depending on the model.
10. What is the net weight of the machine?
The net weight of the machine is 315 kg.
11. Can the machine be used for non-food applications?
Yes, the machine is suitable for a range of non-food products that require similar packaging methods.
12. What kind of maintenance does the machine require?
The machine is designed for easy maintenance, and regular checks on the vacuum system and sealing components are recommended to ensure optimal performance.
13. Is the machine easy to operate?
Yes, the machine features an automated process for bag pick-up, opening, filling, sealing, and outputting finished products, making it user-friendly.
14. What sources of gas does the machine require?
The machine requires a gas source of 0.5 m³/min at 0.65 MPa.
15. Can the machine accommodate different bag shapes?
Yes, the adjustable bag magazine allows for various bag sizes and shapes, providing flexibility in packaging requirements.
