CNC Stone Router
This CNC Router is designed for precision and durability in various machining applications. It offers a large working area, efficient spindle performance, and high-accuracy positioning, making it ideal for a range of industries, including woodwork, signage, and metal machining.
Standard Specifications:
| Item | Specification |
|---|---|
| X,Y,Z Working Area | 13002500500mm |
| Operating System | Taiwan Syntec, Ncstuodio, or DSP Control System |
| Spindle Power | Water or air cooling spindle |
| X,Y,Z Traveling Positioning Accuracy | 0.03/2000mm |
| Table Surface | Vacuum Table + Integrated T-slot Table Clamping System |
| X,Y,Z Rail and Transmission | X,Y axis gear transmission, Z axis Taiwan TBI Ball Screw |
| Spindle Speed | 6000-24000 RPM |
| Drive Motors | Stepper or Servo Drive System |
| Working Voltage | AC380v (220v)/50HZ/3 Phase |
| Command Language | G Code |
| Running Environment | Temperature: 0℃~45℃, Relative Humidity: 30%~75% |
This CNC Router is built with precision in mind, featuring advanced systems for accurate movements and reliable performance. The integrated vacuum and T-slot tables provide flexibility in clamping different materials, ensuring smooth operation in various working environments. The spindle speed and drive motor options allow for both high-speed and heavy-duty applications.
| No. | Item | Standard Specifications |
| 1 | X,Y,Z Working Area | 1300*2500*500mm|4*8ft (1530/2030/2040/2060) |
| 2 | Operating System | Taiwan Syntec or Ncstuodio or DSP control system |
| 3 | Spindle Power | Water or air cooling spindle |
| 4 | X,Y,Z Traveling Positioning Accuracy | 0.03/2000mm |
| 5 | Table Surface | Vacuum table+Intergrated T-solt table clamping System |
| 6 | X,Y,Z Rail and Trasmission | X Y axis gear transmission, Z axis TaiwanTBI Ball Screw |
| 7 | Spindle Speed | 6000-24000RPM |
| 8 | Drive Motors | Stepper or Servo Drive System |
| 9 | Working Voltage | AC380v(220v)/50HZ/3 phase |
| 10 | Command Language | G Code |
| 12 | Running Environment | Temperature: 0℃~45℃ Relative Humidity: 30%~75% |
