Industrial Wind Turbine Spare Parts Hydraulic Yaw Brake System for Wind Generator

The Industrial Wind Turbine Spare Parts Hydraulic Yaw Brake System is a strong and reliable part for wind generators. It helps the turbine turn safely and stay in the right position. This yaw brake works with high pressure to hold the turbine steady. It is built to handle tough weather and heavy use. The AS-2-90/01-HP model is a smart choice for keeping your wind generator working well.

This hydraulic yaw brake system is easy to trust. It gives strong clamping force and braking force. That means the turbine will not move when it should not. The brake pads are thick and can wear down over time, but you can check them easily. The system works in very cold and very hot places. This makes it a great part for many wind power sites.

Specifications

Attribute	Details
Accessories Type	Wind Turbine Yaw Brake
Model Number	AS-2-90/01-HP
Maximum Clamping Force (Fc)	Fc = 267 kN
Maximum Braking Force (Fb)	Fb = 213 kN
Maximum Working Pressure	210 bar
Piston Diameter	90 mm
Piston Area	A = 63.6 cm²
Pad Thickness	16 mm
Maximum Wear Allowance	8 mm
Pad Dimensions	2 x 104 mm
Weight	78 kg
Temperature Range	-40 to 70

Key Features

Strong clamping force of 267 kN keeps the turbine steady.
High braking force of 213 kN stops movement quickly.
Works at high pressure up to 210 bar for reliable power.
Large piston area of 63.6 cm² gives even force.
Thick brake pads of 16 mm last a long time.
Works in very cold and hot weather from -40 to 70 degrees.
Heavy-duty build weighs 78 kg for strong performance.

Applications

Use in wind turbines to hold the nacelle in place.
Works for yaw control systems in large wind generators.
Helps during maintenance when the turbine must stay still.
Good for onshore and offshore wind power installations.
Fits as a spare part for existing wind generator systems.

This Industrial Wind Turbine Spare Parts Hydraulic Yaw Brake System is a dependable part. It helps your wind generator work safely and last longer. Choose this yaw brake for strong performance and easy maintenance. It is a smart part for any wind power setup.
