GOLDCNC CAK6150 Series CNC Lathe – Precision And Performance For Medium Duty Machining

GOLDCNC CAK6150 Series CNC Lathe – Precision And Performance For Medium Duty Machining

The GOLDCNC CAK6150 Series CNC Lathe is designed for medium-duty machining applications, offering exceptional precision and performance. With a wide range of spindle speeds, high accuracy, and a robust design, this CNC lathe is ideal for businesses looking to enhance their productivity while ensuring top-notch quality. Whether you're working with small or large workpieces, the GOLDCNC CAK6150 provides reliable and efficient machining capabilities.

Key Features:

Spindle Speed Range (0 - 8000 rpm): The GOLDCNC CAK6150 Series features an impressive spindle speed range of 0 to 8000 rpm, making it versatile for a variety of turning operations. This wide range ensures optimal cutting performance for both fine and heavy-duty tasks.

Powerful CNC Control System (FANUC/GSK980TDc/i): The lathe is equipped with either the FANUC or GSK980TDc/i CNC control system, ensuring precise and responsive operation. These advanced control systems allow for easy programming, improved accuracy, and better automation during machining tasks.

High Precision (Positioning Accuracy: 0.01 mm): With a positioning accuracy of 0.01 mm and repeatability of ±0.006 mm, the GOLDCNC CAK6150 ensures high levels of precision in every machining operation, making it suitable for industries that require tight tolerances.

Maximum Workpiece Weight (300 kg): The lathe is capable of handling workpieces up to 300 kg, providing flexibility for both small and large components. Its robust design can easily accommodate heavier materials and parts without compromising performance.

Travel (X Axis: 210 mm, Z Axis: 850 mm): The GOLDCNC CAK6150 features a travel range of 210 mm on the X axis and 850 mm on the Z axis, offering ample workspace for a variety of part sizes and machining operations.

Tool Post Stations (6 or 4): The lathe includes either 6 or 4 tool post stations, allowing for efficient tool changes and multiple machining operations without interruption. This feature boosts productivity and minimizes downtime during large runs.

Spindle Bore and Taper (C6, D8): The lathe features a spindle bore size of C6 or D8, providing stable support for larger tools and components, ensuring smooth cutting and turning performance.

Chuck Size (C6 or D8): The lathe comes with a chuck size of C6 or D8, suitable for a wide range of workpieces. The chuck's solid grip ensures secure mounting of parts for accurate machining.

Tailstock Features (MT5 Taper, 150 mm Travel): The tailstock of the GOLDCNC CAK6150 is equipped with an MT5 taper and 150 mm of travel, allowing for additional support when machining long workpieces or when performing drilling operations.

X/Z Rapid Traverse (4/6 m/min): The lathe is designed with rapid traverse speeds of 4 m/min (X axis) and 6 m/min (Z axis), ensuring quick movement and positioning of the cutting tool for enhanced productivity.

Flexible Workpiece Length (750 mm - 3000 mm): The GOLDCNC CAK6150 offers various models with workpiece lengths ranging from 750 mm to 3000 mm, providing flexibility for different sizes and machining requirements.

Dimensions (2550 mm x 1550 mm x 1700 mm): The lathe's overall dimensions of 2550 mm x 1550 mm x 1700 mm make it suitable for a variety of workshop environments while still providing ample space for machining larger workpieces.

Warranty and Support: The GOLDCNC CAK6150 Series is backed by a 1-year warranty, offering peace of mind for users. Additionally, online and video technical support are available to assist with setup, operation, and troubleshooting.

The GOLDCNC CAK6150 Series CNC Lathe is an excellent choice for businesses looking for high-precision machining with the flexibility to handle medium-duty tasks. With a powerful control system, high spindle speeds, and precision accuracy, this lathe is designed to deliver reliable, efficient results.
