Farm Plough With Disc/furrow plough with tractor/farm plough equipment
Product Description
Good passability and penetration ,complete inversion and coverage.Small draft resistance, easy operation and adjustment all these satisfy the agricultural requirements of fine cultivation.
If you are interested in our product , kindly send your enquiry to me.I will give you more details.
Specification
Four wheel tractor mounted disc plough specification is as following :
You can choose the matched model according to your tractor horse power.
| Item | Unit | 1LYQ-220 | 1LYQ-320 | 1LY-325 | 1LY-425 | 1LY-525 |
| Workingwidth | mm | 400 | 600 | 750 | 1000 | 1250 |
| Working depth | mm | 200 | 200 | 250 | 250 | 250 |
| Dia. of disc | mm | 500 | 500 | 650 | 650 | 650 |
| No. of disc | pcs | 2 | 3 | 3 | 4 | 5 |
| Matched power | hp | 18~20 | 25~30 | 50~55 | 60~80 | 80~100 |
| Weight | kg | 160 | 190 | 410 | 470 | 530 |
Product picture show
1LYQ-220 light duty disc plow with 2pcs blade :
1LYQ-320 light duty disc plow with 3pcs blade :
1LYQ-420 light duty disc plow with 4pcs blade :
- Shipping Timeframes: All orders are processed within 2-5 business days (excluding weekends and holidays). After your order has been processed, the estimated delivery time is before 03 Feb, 2026, depending on customs, Please note that due to high demand, some items may experience longer shipping times, which will be communicated at order confirmation email.
- Order Processing Time: Please allow 2-5 business days for us to process your order before it is shipped . Orders placed after 16:00 on Fridays, or during weekends and public holidays, will begin processing on the next business day. Processing times may be extended during peak seasons or sales events.
- Manufacturing Time: Some products needs manufacturing time, the manufacturing process will take approximately 10-30 business days depending on the product. This timeframe may vary depending on the complexity of the product and current demand. but this will be communicated with you during order confirmation.
- Returns and Exchanges: We offer a 30-day return policy for most items. If you are not completely satisfied with your purchase, you may return it within 30 days of receipt for a refund or exchange. Items must be unused, in their original packaging, and accompanied by proof of purchase. Return shipping costs are the responsibility of the customer, unless the item was damaged or defective upon arrival.
1. What is the Farm Plough with tractor and what is it used for?
The Farm Plough with tractor is a tractor-mounted disc/furrow plough designed for primary and fine cultivation. It provides good penetration and passability, complete inversion and coverage of soil, and is used to turn, aerate and prepare seedbeds.
2. What models and working widths are available?
Available models include 1LYQ-220, 1LYQ-320, 1LY-325, 1LY-425 and 1LY-525. Their working widths are approximately 400 mm, 600 mm, 750 mm, 1000 mm and 1250 mm respectively.
3. What are the working depths and disc diameters for each model?
Working depths are 200 mm for the 400 and 600 mm models, and 250 mm for 750–1250 mm models. Disc diameters are 500 mm for the 400 and 600 mm models and 650 mm for the 750–1250 mm models.
4. How many discs does each model have?
The 400 mm model (1LYQ-220) has 2 discs, the 600 mm model (1LYQ-320) has 3 discs, the 750 mm model (1LY-325) has 3 discs, the 1000 mm model (1LY-425) has 4 discs and the 1250 mm model (1LY-525) has 5 discs.
5. What tractor horsepower is required for each model?
Recommended matched power ranges are: 18–20 hp for the 400 mm model, 25–30 hp for the 600 mm model, 50–55 hp for the 750 mm model, 60–80 hp for the 1000 mm model and 80–100 hp for the 1250 mm model.
6. What are the weights of the different models?
Approximate weights are: 160 kg (400 mm), 190 kg (600 mm), 410 kg (750 mm), 470 kg (1000 mm) and 530 kg (1250 mm).
7. How is the plough mounted to a tractor and which tractors are compatible?
The unit is a tractor-mounted disc plough intended for four-wheel tractors. Compatibility depends on tractor horsepower and hitch type—please provide your tractor model and hitch specification when enquiring so we can confirm fitment.
8. How do I adjust working depth and angle?
Depth and angle are adjusted via the plough's depth control and disc tilt/spacing mechanisms. Specific adjustment methods vary by model; the operator manual or seller can provide step-by-step guidance for setting depth and disc angles for best inversion and minimum draft.
9. What maintenance is required?
Regular maintenance includes checking and greasing bearings, inspecting and replacing worn or bent discs, tightening bolts, removing debris, and keeping moving parts lubricated. Sharpen or replace discs if cutting performance decreases.
10. What materials are the discs and frame made from?
The discs are made from heat-treated/hardened steel for durability and wear resistance, and the frame is constructed from high-strength steel. For detailed material specifications, request manufacturer data.
11. Can this plough handle rocky or heavy clay soils?
The plough is designed for good passability and penetration; however, extremely rocky fields or very heavy clay may increase wear and risk damage. For such conditions, discuss reinforced options, larger disc diameters or different tillage tools with the supplier.
12. Are spare parts and replacement discs available?
Yes—replacement discs, bearings and wear parts are normally available. When ordering, provide your model number so the supplier can quote compatible spare parts and part numbers.
13. What safety precautions should I take when using this plough?
Ensure the plough is securely mounted, match tractor horsepower to the plough, keep bystanders clear, operate at safe speeds, avoid stones and stumps, use proper PPE, and follow tractor and implement manufacturer safety instructions.
14. How can I get price, delivery time and warranty information?
Please send an enquiry with your desired model, quantity and delivery location. The seller will provide a quotation including price, lead time, shipping costs and warranty terms.
15. How do I place an order or request more technical details?
Contact the supplier via the enquiry channel (email or phone) with your tractor model, required plough model and any custom requirements. The supplier will provide full technical sheets, pictures, payment options and lead times.
