Introducing the Automatic Horizontal Fire Tube Boiler (Model: Wilford), designed to meet the steam production needs of various industries. This robust boiler is engineered for efficiency and reliability, making it an essential asset for your operations.
High Steam Production: Capable of producing a maximum of 20 tons of steam per hour, ensuring you have the capacity needed for your industrial processes.
Versatile Application: Ideal for use in industries such as food, hotels, washing, and more, providing reliable steam for diverse applications.
Efficient Structure: The fire tube design enhances heat transfer and efficiency, making it a cost-effective solution for steam generation.
Automatic Operation: Features an automatic control system that simplifies operation and ensures optimal performance with minimal manual intervention.
Flexible Power Source: Supports multiple fuel types, including oil, gas, and LPG, allowing for flexibility based on your facility’s requirements.
Durable Material: Constructed from high-quality boiler steel, ensuring longevity and reliability even under demanding conditions.
New Condition: This boiler is brand new and ready for installation, providing you with a fresh start for your steam production needs.
In conclusion, the Automatic Horizontal Fire Tube Boiler (Model: Wilford) is an efficient and versatile solution for your industrial steam needs. With its high steam production capacity, automatic operation, and durable construction, it’s designed to enhance productivity and reliability in your operations. Invest in this boiler today to elevate your steam production capabilities!
Technical parameters
| Type | WNS0.5-0.7-Y.Q | WNS1-1.0-Y.Q | WNS2-1.0-Y.Q | WNS3-1.0-Y.Q | WNS4-1.25-Y.Q | WNS6-1.25-Y.Q | WNS8-1.25-Y.Q | WNS10-1.25-Y.Q | WNS12-1.25-Y.Q | WNS15-1.25-Y.Q | WNS20-1.25-Y.Q | ||
| Project | Unit | ||||||||||||
| Rated evaporation | t/h | 0.5 | 1 | 2 | 3 | 4 | 6 | 8 | 10 | 12 | 15 | 20 | |
| Rated working pressure | MPa | 0.7 | 1.0 | 1.0 | 1.0 | 1.25 | 1.25 | 1.25 | 1.25 | 1.25 | 1.25 | 1.25 | |
| Saturated steam temperature | 170 | 184 | 184 | 184 | 193 | 193 | 193 | 193 | 193 | 193 | 193 | ||
| Fuel consumption | Light diesel oil | kg/h | 32.5 | 65 | 130 | 195 | 260 | 390 | 520 | 650 | 780 | 975 | 1300 |
| Natural gas | Nm3/h | 35 | 70 | 140 | 210 | 280 | 420 | 560 | 700 | 840 | 1050 | 1400 | |
| Liquefied gas | Nm3/h | 15 | 30 | 60 | 90 | 120 | 180 | 240 | 300 | 360 | 450 | 600 | |
| Pipeline gas | Nm3/h | 85 | 170 | 340 | 510 | 680 | 1020 | 1360 | 1700 | 2040 | 2550 | 3400 | |
| Infill caliber | DN | 25 | 25 | 40 | 40 | 50 | 50 | 65 | 65 | 65 | 65 | 80 | |
| Main valve caliber | DN | 40 | 65 | 80 | 80 | 100 | 125 | 150 | 150 | 200 | 200 | 250 | |
| Safety valve caliber | DN | 40 | 50 | 40×2 | 40×2 | 50×2 | 40/80 | 40/80 | 50/80 | 50/80 | 80/80 | 80/80 | |
| Sewage valve caliber | DN | 40 | 40 | 50 | 50 | 50 | 65 | 65 | 65 | 65 | 65 | 65 | |
| Overall size | Length | mm | 3500 | 3900 | 4300 | 4500 | 5000 | 7730 | 8430 | 8900 | 9200 | 9800 | 12500 |
| Width | mm | 2000 | 2500 | 2700 | 2850 | 3000 | 3490 | 3690 | 3890 | 4120 | 4500 | 4750 | |
| Hight | mm | 2150 | 2300 | 2500 | 2980 | 3200 | 3560 | 3800 | 4250 | 4430 | 4800 | 5120 | |
| Weight | kg | 3300 | 4600 | 7100 | 9200 | 11000 | 19200 | 21600 | 24500 | 30100 | 36500 | 49500 | |
