Automatic Flat Wire U-Type Clamp Spring Clip Making Machine

The Automatic Flat Wire U-Type Clamp Spring Clip Making Machine is an advanced solution designed for high-volume production of stainless steel hose clamps and other spring clips. Perfect for manufacturing plants and construction works, this machine combines high productivity, advanced technology, and durable construction to ensure consistent and reliable performance.

Key Features:

High Productivity: With a production capacity of 16 meters per minute, this machine ensures fast and efficient manufacturing, making it ideal for large-scale operations.

Advanced Forming Stations: Featuring 8 forming stations, the machine offers precise and uniform shaping of wire, resulting in high-quality hose clamps and spring clips.

Durable Build: Weighing 5000 kg, this machine is built to withstand the rigors of continuous operation, ensuring long-lasting reliability even in demanding environments.

Efficient Gear-Driven System: The gear-driven mechanism guarantees smooth operation, while the high-strength guide pillar gantry horizontal frame ensures stability and accuracy during the forming process.

Powerful Motor: Equipped with a 37KW servo motor, the machine provides consistent power for uninterrupted production. The motor drives the system efficiently, reducing energy consumption while maintaining high output.

Material and Construction: The machine is built with top-quality materials, including Cr12 rollers with a hardness of HRC58-60° for durability, and 42CrMo shafts with quenching and tempering for added strength.

Versatile Application: This machine is perfect for making hose clamps and spring clips, with applications in building material shops, manufacturing plants, and construction works.

PLC Control: The machine is equipped with a PLC system that ensures precise control over the entire production process, making it easy to operate and maintain.

Customizable: The diameter of shafts (Dia. 60mm) and the station pitch (250mm) provide flexibility, allowing the machine to handle various sizes and configurations of wire material.

The Automatic Flat Wire U-Type Clamp Spring Clip Making Machine is the ideal solution for businesses looking to increase production efficiency and maintain high-quality output in manufacturing hose clamps and spring clips.

Product Info Gallery

Our Band Clamp Roll Forming Making Machine Advantages:

1. High Speed, High Capacity and Stable Performance
2. Just need one time to formed instead of use punching machines, shear machines and other machines
3. Save time, save cost
4. Improve production efficiency and clamping rings quality
5. The pass stations are easy to disassemble, install and maintai
6. The lubrication system for segment forming will be self-contained within the machine. The excess lubrication from the forming process will be re-circulated, filtered and re-used.

TECHNICAL FLOW PROCESS

Automatic Band Clamp Roll Forming Making Machine Working Process:

Technical Configuration:

No	Items	Technical Parameters
1	De-coiler and Straightening Combine Device	Width of Strip	30-100mm；
		Thickness of Strip	≤3.5mm；
		Inner Diameter of Coil	ф480-520 mm(according to customer’s requirements)；
		Outer Diameter of Coil	φ1300mm；Loading Weight:≤2T
		Expand Way	Manual
		Power	De-coiler no power
		Width of Strip	30-100mm；
		Thickness of Strip	≤2mm；
		Motor Power	3 KW (straightening power)
		Speed	Max16m/min
		Roller Arrangement	7 rollers
		Arrange mode	4-Point Independent
2	Roll Forming and Cutting Device	Forming Stations	8 Stations
		Type of Driven	Gear
		Forming Rack:	High strength guide pillar gantry horizontal frame. The slider rollers are adjusted by digital display.
		Station Pitch	250mm
		Max. Feeding Width of Coil	100mm
		Max. Thickness of Material	3.5mm
		Diameter of Shafts	Φ60mm ,42CrMo (quenching and tempering)
		Material of Roller	Cr12,Hardness: HRC58-60°
		Main Driven Motor	37KW (Servo Motor)
		Bending and Cutting Devices	1 set

Main Devices Of Roll Forming Machines

No	Items	Model	Qty	Remark
1	De-coiler and Straightening Combine Device	LS-300F	1 set
2	Roll Forming Device		1 set
3	Guarding Cover		1 set
4	Control System		1 set

DETAIL IMAGES

Product Application Of Our Band Clamp Roll Forming Machine:

This kind of roll forming machine uses stainless steel as raw material, through decoiler, straightening, roll forming and cutter processes, it can produce all kinds of clamping rings.

Frequency converter controls motor speed, PLC system automatically controls length and quantity, realizes continuous automatic production, and is an ideal equipment in cold roll forming industry.

Special Gear Boxes Device

We optimized it and added a gearbox. The gears are in the gearbox to ensure sufficient lubrication, higher transmission accuracy and lower noise. The length accuracy we can achieve now can be guaranteed within 0.5mm.

Shipping Timeframes: All orders are processed within 2-5 business days (excluding weekends and holidays). After your order has been processed, the estimated delivery time is before 15 Dec, 2026, depending on customs, Please note that due to high demand, some items may experience longer shipping times, which will be communicated at order confirmation email.
Order Processing Time: Please allow 2-5 business days for us to process your order before it is shipped . Orders placed after 16:00 on Fridays, or during weekends and public holidays, will begin processing on the next business day. Processing times may be extended during peak seasons or sales events.
Manufacturing Time: Some products needs manufacturing time, the manufacturing process will take approximately 10-30 business days depending on the product. This timeframe may vary depending on the complexity of the product and current demand. but this will be communicated with you during order confirmation.
Returns and Exchanges: We offer a 30-day return policy for most items. If you are not completely satisfied with your purchase, you may return it within 30 days of receipt for a refund or exchange. Items must be unused, in their original packaging, and accompanied by proof of purchase. Return shipping costs are the responsibility of the customer, unless the item was damaged or defective upon arrival.

1. What is the production capacity of the Automatic Flat Wire U-Type Clamp Spring Clip Making Machine?

The machine has a production capacity of 16 meters per minute, making it suitable for high-volume production.

2. How many forming stations does this machine have?

The machine features 8 forming stations for precise and uniform shaping of wire.

3. What type of materials can be processed with this machine?

The machine can process stainless steel and other materials suitable for making hose clamps and spring clips.

4. What is the weight of the machine?

The Automatic Flat Wire U-Type Clamp Spring Clip Making Machine weighs approximately 5000 kg.

5. What motor power does this machine use?

It is equipped with a powerful 37KW servo motor that ensures consistent power for uninterrupted production.

6. Is the machine easy to operate?

Yes, the machine is equipped with a PLC control system that ensures precise control over the production process, making it user-friendly.

7. Can the machine handle different sizes of wire material?

Yes, the diameter of shafts (Dia. 60mm) and the station pitch (250mm) provide flexibility for various wire sizes and configurations.

8. What is the lubrication system like in this machine?

The lubrication system is self-contained, with excess lubrication from the forming process being recirculated, filtered, and reused.

9. Where can this machine be used?

It is ideal for manufacturing plants, construction works, and building material shops for producing hose clamps and spring clips.

10. What is the material used for rollers in the machine?

The rollers are made of Cr12 with a hardness of HRC58-60° for enhanced durability.

11. How does the gear-driven system benefit the operation of the machine?

The gear-driven mechanism guarantees smooth operation while ensuring stability and accuracy during the forming process.

12. What safety features does the machine have?

The machine is equipped with a guarding cover and a robust design to ensure safe operation during production.

13. How easy is it to maintain the machine?

The machine is designed for easy maintenance, with disassembly and installation of pass stations being straightforward.

14. What kind of clips can this machine produce?

The machine is designed for producing stainless steel hose clamps and other types of spring clips.

15. Does this machine require a specific power supply?

The machine operates on a specific power supply that meets the requirements of the 37KW servo motor; please refer to the technical specifications for details.
