The cold heading machine is a vital component in the fastener industry, working in tandem with automatic wire rolling machines to manufacture a wide range of fasteners. Here's a breakdown of its functionality and the types of products it can produce:
1. **Purpose and Safety**: The primary function of the cold heading machine is to shape metal wires, such as carbon steel, stainless steel, aluminum, and copper, into various fastener components. It employs appropriate molds and exerts pressure on the wire to form the desired head type and stem diameter. Safety measures are in place to ensure safe operation during the manufacturing process.
2. **Automated Process**: The machine utilizes a crankshaft and connecting rod mechanism to automate the forming process. Once the metal wire is fed into the machine and the required size is determined, the slider is driven by the crankshaft to shear and extrude the wire into the mold, creating the desired fastener shape.
3. **Versatile Production**: The cold heading machine is capable of producing a diverse array of fastener types, including Truss Head, Countersunk Head, Set Screw, Wood Screw, Chipboard Screw, Self-Tapping Screw, Flat Head Hex Head, Pan Head, Hexagon Head, Socket Head, Button Head, and more. Additionally, it can manufacture various other fastener-related components such as nuts, bolts, washers, motorcycle link pins, oil plug screws, hex socket lockup nuts, square nuts, weld nuts, cap nuts, blind nuts, chain rollers, expansion anchors, and bicycle and motorcycle-shaped spare parts.
4. **Support and Assistance**: The manufacturer provides support and assistance to customers throughout the production process. They can offer guidance on product selection, customization options, and ongoing support to ensure the efficient operation of the cold heading machine and the production of high-quality fasteners.
In summary, the cold heading machine plays a crucial role in the fastener industry by enabling the efficient and precise production of a wide range of fasteners and related components. Its versatility, automated operation, and safety features make it an indispensable tool for manufacturers in this sector.
Product Paramenters
Model
RSH3-20
RSH4-40
RSH4-30G
RSH5-30G
Max. Blank Diameter (mm)
3
4
4
5
Max. Blank Length (mm)
20
40
30
30
Max. Cut off Length (mm)
30
48
48
55
Stroke (mm)
37
68
68
82
Output (Pcs/Min)
150-200
150-180
180-200
160-180
Main Die Diameter (mm)
Φ20X35
Φ30X60
Φ30X50
Φ34.5X56
Punch Die Diameter (1st) (mm)
Φ18X50
Φ25X65
Φ25X65
Φ35X75
Punch Die Diameter (2nd) (mm)
Φ18X50
Φ25X65
Φ25X65
Φ31X75
Cut off Die Diameter (mm)
Φ13X25
Φ15X30
Φ15X30
Φ19X35
Cutter Size (mm)
6X25X42
10X32X72
10X32X72
10X35X72
Main Motor Power (KW)
1.5HP/1.1KW
4.0HP/3.0KW
4.0HP/3.0KW
4.0HP/3.0KW
Machine Size (L*W*H) (m)
1.40X0.75X0.90
1.80X0.85X1.15
1.80X0.85X1.15
1.80X1.00X1.25
Approx Weight (Kgs)
650
1200
1300
2000
Model
RSH5-50G
RSH5-60
RSH5-80
RSH5-100
Max. Blank Diameter (mm)
5
5
5
5
Max. Blank Length (mm)
50
60
80
100
Max. Cut off Length (mm)
75
80
95
120
Stroke (mm)
92
92
110
130
Output (Pcs/Min)
160-180
120-140
90-110
80-100
Main Die Diameter (mm)
Φ34.5X68
Φ34.5X80
Φ34.5X100
Φ35X120
Punch Die Diameter (1st) (mm)
Φ35X75
Φ31X75
Φ31X75
Φ30X80
Punch Die Diameter (2nd) (mm)
Φ31X75
Φ31X75
Φ31X75
Φ30X80
Cut off Die Diameter (mm)
Φ19X35
Φ19X35
Φ19X35
Φ20X35
Cutter Size (mm)
10X35X72
10X35X72
10X35X72
10X35X72
Main Motor Power (KW)
4.0HP/3.0KW
4.0HP/3.0KW
4.0HP/3.0KW
4.0HP/3.0KW
Machine Size (L*W*H) (m)
1.80X1.00X1.25
2.30X1.08X1.25
2.40X1.15X1.25
2.50X1.15X1.35
Approx Weight (Kgs)
2100
1800
1850
2200
Model
RSH5-150
RSH6-70
RSH6-90
RSH6-120
Max. Blank Diameter (mm)
5
6
6
6
Max. Blank Length (mm)
150
70
90
120
Max. Cut off Length (mm)
168
110
110
140
Stroke (mm)
190
90
120
150
Output (Pcs/Min)
60-80
90-100
80-90
70-80
Main Die Diameter (mm)
Φ40X180
50X120
Φ50X120
Φ50X150
Punch Die Diameter (1st) (mm)
Φ35X100
35X120
Φ35X120
Φ35X120
Punch Die Diameter (2nd) (mm)
Φ35X100
35X120
Φ35X120
Φ35X120
Cut off Die Diameter (mm)
Φ20X35
24X40
Φ24X40
Φ24X40
Cutter Size (mm)
10X35X72
12X35X77
12X35X77
12X35X77
Main Motor Power (KW)
4.0HP/3.0KW
7.5HP/5.5KW
7.5HP/5.5KW
7.5HP/5.5KW
Machine Size (L*W*H) (m)
2.60X1.15X1.35
2.50X1.40X1.60
2.70X1.40X1.60
2.80X1.40X1.60
Approx Weight (Kgs)
3000
3300
3300
3600
Model
RSH6-150
RSH6-170
RSH6-200
RSH6-250
Max. Blank Diameter (mm)
6
6
6
6
Max. Blank Length (mm)
150
170
200
250
Max. Cut off Length (mm)
170
190
220
270
Stroke (mm)
190
230
240
310
Output (Pcs/Min)
60-70
50-60
40-50
30-45
Main Die Diameter (mm)
Φ50X180
Φ50X220
Φ50X240
Φ50X285
Punch Die Diameter (1st) (mm)
Φ35X160
Φ35X120
Φ35X120
Φ35X140
Punch Die Diameter (2nd) (mm)
Φ35X160
Φ35X130
Φ35X130
Φ35X130
Cut off Die Diameter (mm)
Φ24X55
Φ24X55
Φ24X60
Φ24X60
Cutter Size (mm)
12X35X77
12X35X77
12X35X77
12X35X77
Main Motor Power (KW)
7.5HP/5.5KW
7.5HP/5.5KW
7.5HP/5.5KW
7.5HP/5.5KW
Machine Size (L*W*H) (m)
3.00X1.40X1.60
3.20X1.40X1.60
3.65X1.40X1.45
3.70X1.50X1.70
Approx Weight (Kgs)
4200
4200
4900
5400
Model
RSH8-90
RSH8-120
RSH8-150
RSH8-200
Max. Blank Diameter (mm)
8
8
8
8
Max. Blank Length (mm)
90
120
150
200
Max. Cut off Length (mm)
120
140
180
220
Stroke (mm)
130
156
190
250
Output (Pcs/Min)
80-90
60-80
60-70
40-50
Main Die Diameter (mm)
Φ60X120
Φ60X160
Φ60X190
Φ60X240
Punch Die Diameter (1st) (mm)
Φ40X120
Φ40X120
Φ40X120
Φ40X150
Punch Die Diameter (2nd) (mm)
Φ40X120
Φ40X120
Φ40X120
Φ40X150
Cut off Die Diameter (mm)
Φ28X45
Φ28X45
Φ28X45
Φ28X60
Cutter Size (mm)
12X42X90
12X42X90
12X42X90
12X42X90
Main Motor Power (KW)
10HP/7.5KW
10HP/7.5KW
10HP/7.5KW
10HP/7.5KW
Machine Size (L*W*H) (m)
3.60X1.60X1.80
3.75X1.60X1.80
3.90X1.60X1.80
4.15X1.60X1.85
Approx Weight (Kgs)
4800
4900
6200
6500
Model
RSH8-250
RSH8-300
RSH10-120
RSH10-150
Max. Blank Diameter (mm)
8
8
10
10
Max. Blank Length (mm)
250
300
120
150
Max. Cut off Length (mm)
270
330
140
180
Stroke (mm)
290
365
150
210
Output (Pcs/Min)
30-45
25-35
50-60
45-55
Main Die Diameter (mm)
Φ60X290
Φ60X360
Φ80X160
Φ80X190
Punch Die Diameter (1st) (mm)
Φ40X150
Φ40X180
Φ55X150
Φ55X150
Punch Die Diameter (2nd) (mm)
Φ40X150
Φ40X180
Φ55X150
Φ55X150
Cut off Die Diameter (mm)
Φ28X60
Φ28X60
Φ40X50
Φ40X50
Cutter Size (mm)
12X42X90
12X42X90
16X55X115
16X55X115
Main Motor Power (KW)
10HP/7.5KW
10HP/7.5KW
15HP/11KW
15HP/11KW
Machine Size (L*W*H) (m)
4.30X1.60X1.90
4.30X1.60X1.90
4.80X1.80X1.70
3.90X1.80X1.70
Approx Weight (Kgs)
7800
8500
8450
8800
Model
RSH10-220
RSH10-260
RSH10-300
RSH12-70
Max. Blank Diameter (mm)
10
10
10
12
Max. Blank Length (mm)
220
260
300
70
Max. Cut off Length (mm)
240
280
320
90
Stroke (mm)
260
300
350
120
Output (Pcs/Min)
40-50
30-40
25-35
60-70
Main Die Diameter (mm)
Φ80X260
Φ80X290
Φ80X360
Φ80X120
Punch Die Diameter (1st) (mm)
Φ55X150
Φ55X150
Φ55X180
Φ55X120
Punch Die Diameter (2nd) (mm)
Φ55X150
Φ55X150
Φ55X180
Φ55X120
Cut off Die Diameter (mm)
Φ40X50
Φ40X60
Φ40X50
Φ35X45
Cutter Size (mm)
16X55X115
16X55X115
16X55X115
16X50X125
Main Motor Power (KW)
15HP/11KW
15HP/11KW
15HP/11KW
20HP/15KW
Machine Size (L*W*H) (m)
5.00X1.80X1.70
5.15X1.80X1.70
5.50X1.80X2.00
4.50X2.00X1.32
Approx Weight (Kgs)
9100
10200
11800
8700
Model
RSH12-150
RSH12-200
RSH12-250
RSH12-300
Max. Blank Diameter (mm)
12
12
12
12
Max. Blank Length (mm)
150
200
250
300
Max. Cut off Length (mm)
170
220
270
320
Stroke (mm)
190
250
300
330
Output (Pcs/Min)
40-50
30-40
30-40
25-35
Main Die Diameter (mm)
Φ80X200
Φ88X260
Φ88X330
Φ88X360
Punch Die Diameter (1st) (mm)
Φ60X180
Φ60X180
Φ60X180
Φ60X180
Punch Die Diameter (2nd) (mm)
Φ60X180
Φ60X180
Φ60X180
Φ60X180
Cut off Die Diameter (mm)
Φ45X60
Φ45X60
Φ45X60
Φ45X60
Cutter Size (mm)
18X60X125
18X60X125
18X60X125
18X60X125
Main Motor Power (KW)
25HP/18.5KW
25HP/18.5KW
25HP/18.5KW
25HP/18.5KW
Machine Size (L*W*H) (m)
5.20X1.90X1.80
5.20X1.90X1.80
5.20X1.90X1.80
5.20X1.90X1.80
Approx Weight (Kgs)
14000
14300
15000
15850
Model
RSH12-450
RSH16-180
RSH16-450
Max. Blank Diameter (mm)
12
16
16
Max. Blank Length (mm)
450
180
450
Max. Cut off Length (mm)
480
210
480
Stroke (mm)
550
240
550
Output (Pcs/Min)
25-35
35-40
25-35
Main Die Diameter (mm)
Φ90X540
Φ98X220
Φ98X540
Punch Die Diameter (1st) (mm)
Φ60X270
Φ65X180
Φ60X270
Punch Die Diameter (2nd) (mm)
Φ60X270
Φ65X180
Φ60X270
Cut off Die Diameter (mm)
Φ45X60
Φ60X80
Φ60X80
Cutter Size (mm)
18X60X125
20X60X125
20X70X125
Main Motor Power (KW)
25HP/22KW
25HP/22KW
25HP/22KW
Machine Size (L*W*H) (m)
6.50X2.25X2.10
4.40X2.10X1.95
6.50X2.25X2.10
Approx Weight (Kgs)
20800
20800
21000
