200L Milk homogeniser small milk homogenizer machine
- Section : Machinery
- Category : Other Food Processing Machinery
- SKU : 1600663584982
High pressure homogenizer is a special equipment for homogenizing, refining and high pressure transportation of liquid materials. The equipment is widely used in food, dairy, beverage, pharmaceutical, fine chemical and biotechnology, scientific research and technology development and other fields. The homogenizer is mainly used for sample preparation in biotechnology and medical fields, enzyme treatment in food industry, and decentralized organization in pharmaceutical industry, cosmetics industry, paint industry, petrochemical industry and other fields. This device USES stainless steel system, effective separation barrier and contained microorganisms on the surface of the sample homogeneous samples, samples in a sterile homogeneous bag, after contact with the instrument USES soft homogeneous, no pollution, no damage, no heat, no sample sterilization treatment, do not need cleaning utensils, meet the requirements of rapid, accurate and repeatable.The equipment is composed of frame, transmission box, pump body, pressure gauge and homogenizer Such parts. The machine is vertically positioned, the motor is installed inside the frame, the transmission box is installed on the frame, and the pump body is connected with the transmission box. The motor drives the gearbox shaft bending shaft through the belt, and the linkage slider drives the plunger for reciprocating motion. The plunger in the pump body for pumping pressure movement, through the combination valve control feed liquid pressure formation. When THE MACHINE IS USED AS homogenIZER, THE homogenIZER AND THE feed press SHOULD be assembled in the homogenizer, and the feed liquid can be fully homogenized and refined through the function of the homogenizer valve. When the machine is used as a high pressure pump, it should be equipped with high pressure overflow device, the liquid supply through the pump body pressure at the outlet, when the pressure exceeds the set range, the overflow valve automatically open, forming internal discharge, when the pressure is lower than the set value, the overflow valve automatically close, so that the liquid supply can be safely transported within the set pressure range.
High pressure homogenizer technical features: The whole machine is covered by stainless steel shell, with smooth and delicate appearance, safety and health. Using HELICAL GEAR LOW speed TRANSMISSION, LOW noise, stable operation, reliable performance, the transmission part adopts SPLASH-type and unique oil delivery mode, to ensure the lubrication needs of each part Double - sided seating design doubles the service life. The homogeneous valve, one-way valve and plunger are made of alloy steel, which has the characteristics of wear resistance, impact resistance and long service life.
| Type | Flow L/H | Maximum pressure | Rating pressure | Motor power | Dimensions mm |
| HF-0.2/25 | 200L |
25Mpa |
20Mpa | 2.2kw | 755x520x935 |
| HF-0.3/25 | 300L | 3kw | 755x520x935 | ||
| HF-0.5/25 | 500L | 4kw | 1010x620x980 | ||
| HF-0.8/25 | 800L | 5.5kw | 1020x680x1100 | ||
| HF-1/25 | 1000L | 7.5kw | 1100x680x1100 | ||
| HF-1.5/25 | 1500L | 11kw | 1100x770x1100 | ||
| HF-2/25 | 2000L | 15kw | 1400x850x1200 | ||
| HF-2.5/25 | 2500L | 18.5kw | 1400x850x1200 | ||
| HF-3/25 | 3000L | 22kw | 1400x1000x1300 | ||
| HF-4/25 | 4000L | 30kw | 1600x1100x1400 | ||
| HF-5/25 | 5000L | 37kw | 1600x1200x1600 | ||
| HF-6/25 | 6000L | 45kw | 1700x1300x1400 | ||
| HF-8/25 | 8000L | 55kw | 1700x1300x1400 | ||
| HF-10/25 | 10000L | 75kw | 2800x1300x1400 | ||
| HF-12/25 | 12000L | 90kw | 2800x1500x1400 |
- Shipping Timeframes: All orders are processed within 2-5 business days (excluding weekends and holidays). After your order has been processed, the estimated delivery time is before 03 Feb, 2026, depending on customs, Please note that due to high demand, some items may experience longer shipping times, which will be communicated at order confirmation email.
- Order Processing Time: Please allow 2-5 business days for us to process your order before it is shipped . Orders placed after 16:00 on Fridays, or during weekends and public holidays, will begin processing on the next business day. Processing times may be extended during peak seasons or sales events.
- Manufacturing Time: Some products needs manufacturing time, the manufacturing process will take approximately 10-30 business days depending on the product. This timeframe may vary depending on the complexity of the product and current demand. but this will be communicated with you during order confirmation.
- Returns and Exchanges: We offer a 30-day return policy for most items. If you are not completely satisfied with your purchase, you may return it within 30 days of receipt for a refund or exchange. Items must be unused, in their original packaging, and accompanied by proof of purchase. Return shipping costs are the responsibility of the customer, unless the item was damaged or defective upon arrival.
1. What is a milk homogenizer and how does it work?
A milk homogenizer is a high-pressure device used to homogenize, refine, and transport liquid materials. It works by forcing liquid through a homogenizer valve, breaking down fat molecules to ensure uniformity in the product.
2. What materials can this homogenizer process?
This homogenizer can process a variety of liquids including milk, dairy products, beverages, pharmaceuticals, fine chemicals, and samples for biotechnological applications.
3. What are the benefits of using a high-pressure homogenizer?
Benefits include improved product consistency, enhanced stability, better texture and flavor in food products, and efficient processing in pharmaceuticals and cosmetics.
4. Is the homogenizer easy to clean?
Yes, the homogenizer is designed to minimize contamination and does not require extensive cleaning utensils. It operates in a sterile environment, ensuring that samples remain uncontaminated.
5. What is the maximum pressure rating for this homogenizer?
The maximum pressure rating varies by model. For instance, the HF-0.3/25 model has a maximum pressure of 25Mpa, while others can go up to 100Mpa.
6. What kind of motor power does the machine require?
Motor power varies depending on the model. The HF-0.3/25 model requires a 3kw motor, while larger models like the HF-10/25 require up to 75kw.
7. What are the dimensions of the 300L model?
The dimensions of the HF-0.3/25 model are 755mm x 520mm x 935mm.
8. Is the machine suitable for small-scale operations?
Yes, this small milk homogenizer is designed for use in small to medium-scale operations, making it ideal for small dairy farms or artisanal food production.
9. Does the machine require special installation?
While specific installation requirements may vary, it is generally recommended to set up the machine on a stable, level surface and ensure proper ventilation for the motor.
10. What type of maintenance does the homogenizer require?
Routine maintenance includes checking the lubrication, inspecting the homogenizer valve, and ensuring that the machine remains clean. Regular checks will help extend the lifespan of the machine.
11. Can the homogenizer be used for other applications besides milk?
Yes, it can be used in various industries including pharmaceuticals, cosmetics, and fine chemicals, making it a versatile tool for different liquid processing needs.
12. What safety features does the homogenizer have?
The machine is designed with safety in mind, including an overflow valve that automatically opens to prevent excessive pressure and a stainless steel shell for durability and hygiene.
13. What is the noise level during operation?
The homogenizer operates at low noise levels due to its helical gear low-speed transmission, making it suitable for environments where noise reduction is important.
14. Is training provided for using the homogenizer?
Training may be available through the manufacturer or distributor. It is recommended to familiarize yourself with the operation manual and safety guidelines before use.
15. What is the warranty period for the homogenizer?
The warranty period can vary by manufacturer and model. It is advisable to check with the supplier for specific warranty details.
