The maximum horizontal conveying distance of the 14m Mini Concrete Boom Pump is 500 meters.
The weight of the 14m Mini Concrete Boom Pump is 9500 kg.
The maximum theoretical concrete output of the pump is 40m³/h.
The pump uses diesel power.
The maximum placing height of the pump is 15.4 meters.
Yes, its compact design makes it perfect for urban areas with limited access.
The dimensions of the pump are 7500 mm in length, 2200 mm in width, and 2600 mm in height.
The maximum vertical conveying distance of the pump is 110 meters.
The pump comes with a warranty period of 1 year.
Yes, the robust design of the pump allows it to be used in various weather conditions.
The outlet diameter of the pump is 150 mm.
The core component of this pump is its motor, which drives the fully hydraulic system for smooth operation.
The feeding height of the hopper is 1500 mm.
Yes, the 14m Mini Concrete Boom Pump is great for both residential and commercial applications.
The maximum concrete pumping pressure is 10 MPa.
