ZDC1500 Wireline Core Drilling Rig — Crawler Hydraulic Geological Rig
Deep 1500 m wireline coring on a rugged crawler platform
The ZDC1500 is a diesel-powered crawler hydraulic core drilling rig capable of reaching depths up to 1500 m with a 108 mm drilling diameter. It includes a BW250-3 mud pump and supports OEM customisation for geological, coal and water well programmes.
1 Year Warranty
Test Report Provided
Video Outgoing-Inspection
OEM Customisation Available
Guide Price
R 1 382 687.77
Guide price excl. VAT & delivery — final quotation tailored to your specification.
Get your exact quote
Max. 1500 m
Drilling Depth
108 mm
Drilling Diameter
Crawler
Mobility
BW250-3
Mud Pump
9000 kg
Weight
Diesel
Power Type
Business Solution Overview
Deep Coring Capability in One Rig: A maximum drilling depth of 1500 m and 108 mm coring diameter allow a single crawler rig to handle deep geological programmes that would otherwise require multiple setups or larger, less mobile equipment.
Lower Mobilisation Costs on Rough Terrain: The crawler undercarriage moves the rig across uneven exploration ground without dedicated haulage for every hole, reducing the time and cost of repositioning between drill sites.
Engine Choice Backed by Local Parts Networks: Diesel engine options from Cummins, Yuchai, Weichai and Quanchai let buyers select a powerplant with established service and spares support in their region, helping to minimise downtime.
Documented Quality and Warranty Cover: Every unit is supplied with a test report and video outgoing-inspection, and is covered by a one-year warranty — giving procurement teams verifiable evidence of condition before the rig is deployed.
OEM Customisation for Project-Specific Needs: OEM customisation is available, allowing the rig to be configured around a contractor's drilling programme rather than forcing the programme to fit a standard machine.
Why Choose ZDC1500 Wireline Core Drilling Rig — Cra?
Crawler Mobility on Rough Ground
Strong crawler tracks let the rig move across uneven exploration terrain, cutting the time spent repositioning between holes.
Smooth Hydraulic Drilling
The hydraulic system delivers smooth and powerful drilling, supporting consistent core recovery at depth.
Integrated BW250-3 Mud Pump
A built-in mud pump cleans the hole during drilling, helping maintain sample quality and drilling efficiency.
Choice of Diesel Engines
Cummins, Yuchai, Weichai and Quanchai engine options allow buyers to match the rig to locally supported powerplants.
Heavy-Duty Steel Frame
A robust steel structure is built to withstand the demands of continuous deep-hole coring programmes.
Simple Controls
Straightforward controls make the rig easy to operate, reducing training time for drilling crews.
Technical Specifications
Type
Core Drilling Rig
Drilling Depth
Max. 1500 m
Drilling Diameter
108 mm
Power Type
Diesel
Engine Options
Cummins, Yuchai, Weichai, Quanchai
Mud Pump Model
BW250-3
Mobility
Crawler
Weight
9000 kg
Dimensions (L × W × H)
3800 × 2200 × 8500 mm
Core Components
Motor, Pump, Gear, Bearing, Engine, Gearbox
Warranty
1 Year
Test Report
Provided
Video Outgoing-Inspection
Provided
Optional Modules
OEM Customisation
Industries Served
Coal Exploration & Mining
Geological Surveys
Water Well Drilling
Foundation Drilling
Environmental & Groundwater Testing
Mineral Resource Evaluation
What's Included
ZDC1500 Wireline Core Drilling Rig
BW250-3 Mud Pump
Test Report
Video Outgoing-Inspection Documentation
1 Year Warranty
