SPM Vertical and Horizontal Drilling Tapping Machine
Four power heads, eight stations — precision drilling and tapping at scale
A special purpose machine built for high-volume drilling and tapping of brass, copper and aluminium alloy components. Four power heads and an eight-station turntable deliver consistent, repeatable output for precision casting production.
1-Year Warranty
Free Replacement Parts
Online Technical Support
Machinery Test Report Provided
Outgoing Inspection Video
Guide Price
R 619 688.25
Guide price excl. VAT & delivery — final quotation tailored to your specification.
Get your exact quote
4 Power Heads
Spindle Configuration
8 Stations
Turntable
100 mm
Max. Drilling Diameter
100–5000 RPM
Spindle Speed
4 kW
Motor Power
2,500 kg
Machine Weight
Business Solution Overview
High Return on Investment: A four-head, eight-station configuration processes multiple components per cycle, so a single machine can replace several standalone drilling and tapping operations and shorten the time between raw casting and finished part.
Built for Precision Casting Production: The machine is purpose-designed for drilling and tapping brass, copper and aluminium alloy workpieces — the exact materials and tasks that dominate precision casting workshops.
Flexible Control Platform: Buyers can specify Fanuc, Siemens, Syntec or GSK980 control systems, making it easier to match the machine to existing programming skills and spare-part networks on site.
Low Downtime, Supported Uptime: A one-year warranty, free replacement parts and online technical support reduce the risk and cost of unplanned stoppages during production ramp-up.
Verified Before Dispatch: A machinery test report and outgoing inspection video are provided, giving buyers documented evidence of performance before the machine leaves the factory.
Complete End-to-End Process
Load Workpiece onto Turntable
Index Through 8 Stations
Vertical & Horizontal Drilling
Tapping Operation
Unload Finished Part
Why Choose SPM Vertical and Horizontal Drilling Tap?
Four Power Heads
Four independent power heads allow multiple drilling and tapping operations to run in one cycle, cutting handling time and improving repeatability.
Eight-Station Turntable
The eight-station rotary table indexes workpieces between operations, supporting continuous production with minimal operator intervention.
Touch-Screen Control
A touch-screen operation menu simplifies setup and day-to-day control, reducing the training burden on machine operators.
Multi-Material Capability
Suitable for brass, copper, aluminium alloy and similar materials, making it a versatile asset for mixed-material casting workshops.
Choice of Control Systems
Available with Fanuc, Siemens, Syntec or GSK980 control, so the machine can align with the controls and skills already present in your plant.
Documented Pre-Shipment Testing
A machinery test report and outgoing inspection video are supplied, giving buyers confidence in the machine's condition before dispatch.
Technical Specifications
Brand Name
DELIN MACHINERY
Model Number
DL-ZSB4950*4
Machine Type
Special Purpose Machine
Function
Drilling & Milling
Max. Drilling Dia.
100 mm
Drilling Speed
1000 r/min
Spindle Speed
100–5000 RPM
Range of Spindle Speed
10–20000 r.p.m
Power
4 kW
Machine Total Power
2–5 kW
Voltage
380V 50Hz
Weight
2500 kg
Dimensions (L×W×H)
2900 × 2300 × 1750 mm
Power Head Number
4
Number of Turntable Stations
8
Control System
Fanuc / Siemens / Syntec / GSK980
CNC or Not
Normal
Core Components
Bearing, Pump, Gear, Motor, Gearbox, PLC, Pressure Vessel, Engine, Other
Processing Material
Brass, copper, aluminium alloy, etc.
Usage
Drilling and tapping workpiece
Industries Served
Precision Casting
Metal Component Manufacturing
Brass & Copper Fabrication
Aluminium Alloy Parts Production
General Engineering Workshops
What's Included
SPM Vertical and Horizontal Drilling Tapping Machine
Touch-screen operation menu
Machinery test report
Outgoing inspection video
One-year warranty
Free replacement parts
Online technical support
