Hard Rock Mining
Self-Propelled Track-Mounted Mobile Screen & Rock Crusher Plant
Crush and screen on the move — one machine, one pass.
Track-mounted mobile crushing and screening plant with 90–130 t/h capacity, 53.5 kW total power and a 154 kW engine. Self-propelled on a hydraulic crawler undercarriage for mining, ore and gold crushing.
1-Year Warranty
Machinery Test Report Provided
Outgoing-Inspection Video
Free Replacement Parts
Online Technical Support
Guide Price
R 1 032 813.75
Guide price excl. VAT & delivery — final quotation tailored to your specification.
Get your exact quote
90–130 t/h
Capacity
154 kW
Engine Power
53.5 kW
Total Power
34,700 kg
Operating Weight
40 t
Crawler Load Capacity
15 × 13.2 × 5.6 m
Installed Dimensions
Business Solution Overview
Mobility That Cuts Material Haulage: Because the plant is self-propelled on a hydraulic crawler undercarriage, it can be moved to the material instead of hauling rock to a fixed crusher. That reduces load-and-haul cycles and keeps production running as the working face advances.
Crushing and Screening in One Pass: The integrated 3YK1860 screen and B1000/B650 belt conveyors mean rock is crushed and sized in a single machine. This removes the need for a separate screening unit and the additional handling that comes with it.
Throughput Suited to Production Mining: A capacity range of 90–130 t/h supports continuous feed at mining, ore crushing and gold mining sites, helping operations maintain output without depending on a permanent plant installation.
Low Operating Complexity: Simple controls and a single self-propelled chassis reduce the number of operators and support equipment required on site, which supports lower day-to-day operating cost.
Backed by Warranty and Technical Support: The unit ships with a 1-year warranty, a machinery test report, outgoing-inspection video, free replacement parts and online technical support — giving buyers documented pre-delivery verification and a support channel after commissioning.
Complete End-to-End Process
Track-Mounted Positioning
Crushing
3YK1860 Screening
B1000 / B650 Belt Conveying
Why Choose Self-Propelled Track-Mounted Mobile Scre?
Self-Propelled Crawler Mobility
A hydraulic crawler undercarriage with 40 t load capacity lets the plant move across rough ground and reposition without a prime mover.
Multi-Function Crush and Screen
Crushing and screening are combined in one machine, so rock is processed and sized in a single continuous flow.
Simple, Easy Operation
Straightforward controls keep the plant easy to operate, reducing the training burden on site crews.
PLC-Controlled Core Components
The core package includes PLC, motor, engine and bearings, supporting consistent control of the crushing and screening cycle.
Documented Pre-Delivery Testing
A machinery test report and outgoing-inspection video are provided, giving buyers verifiable evidence of the unit's condition before dispatch.
Warranty and Parts Support
Covered by a 1-year warranty with free replacement parts and online technical support for ongoing operation.
Technical Specifications
Type
Mobile Crusher
Capacity
90–130 t/h
Motor Type
AC Motor
Core Components
PLC, Motor, Engine, Bearing
Key Selling Points
Easy To Operate
Weight
34,700 kg
Application
Mining Crushing, Ore Crushing, Gold Mining
Brand Name
STM
HS Code
8474209000
Movable Type
Crawler Track-Mounted
Main Configuration
Screen, Belt Conveyor
Total Power
53.5 kW
Screen Model
3YK1860
Belt Conveyor
B1000, B650
Installed Dimensions (L×W×H)
15 × 13.2 × 5.6 m
Transport Dimensions (L×W×H)
15.5 × 3.3 × 4.2 m
Power Engine
154 kW
Hydraulic Crawler Undercarriage Load Capacity
40 t
Warranty
1 Year
Selling Units
Single Item
Industries Served
Mining & Mineral Processing
Gold & Precious Metal Processing
Ore Crushing
Aggregate & Quarry Production
What's Included
Self-propelled track-mounted mobile crusher plant
3YK1860 screen
B1000 and B650 belt conveyors
Hydraulic crawler undercarriage
154 kW power engine
Machinery test report
Outgoing-inspection video
1-year warranty
Free replacement parts
Online technical support
