Gold & Precious Metal Processing
Portable Alluvial Gold Trommel Washing Plant
Mobile gold recovery plant for alluvial washing and screening
A compact mobile gold trommel plant designed for land-based alluvial gold washing and screening. It combines portability, reliable operation, easy maintenance and model options up to 200 t/h productivity.
Portable Land-Based Design
Reliable Operation
Easy Maintenance
Large Handling Capacity
Exported To African Markets
Guide Price
R 1 063 285
Guide price excl. VAT & delivery — final quotation tailored to your specification.
Get your exact quote
200 t/h
Maximum Productivity
1800 × 5000 mm
Largest Trommel Type
150 kW
Motor Power
11500 × 2250 mm
Largest Plant Dimensions
5-200 t/h
Productivity Range
Business Solution Overview
Built for Mobile Gold Operations: The plant is designed to be moved on land, making it suitable for operations that need flexible deployment across changing alluvial sites. Its compact structure and light weight support easier relocation than fixed installations.
Scalable Throughput Options: With trommel models ranging from 5 t/h to 200 t/h, buyers can select a plant size aligned to current production targets and expand capacity as project requirements grow.
Operational Simplicity: Simple operation, reliable running and easy maintenance help reduce day-to-day complexity on site. This is valuable for mining businesses that need practical equipment for continuous field use.
Continuous Screening Performance: The optional comb-shaped cleaning mechanism helps keep the sieve body clear during operation, supporting uninterrupted screening and more consistent plant performance over the working cycle.
Proven Export Experience: The product description states exports to Sudan, Tanzania, Ghana and other markets, indicating experience supplying gold processing equipment into African mining environments.
3D Sketch
AI-generated labelled 3D blueprint sketch — illustrative, not a manufacturing drawing.
Complete End-to-End Process
Feed Material Into Trommel
Rotate Screening Cylinder
Separate Material By Size
Clean Sieve During Operation
Discharge Fine Material
Why Choose Portable Alluvial Gold Trommel Washing P?
Mobile Plant Configuration
Designed to be moved on land, this trommel plant supports flexible deployment for alluvial gold projects that operate across multiple working areas.
Inclined Screening Cylinder
The main screening cylinder is composed of several circular meshes and installed at an incline to support top-to-bottom material separation.
Variable-Speed Drive System
A variable-speed deceleration system rotates the screening cylinder at a controlled speed for stable screening performance.
Sealed Outer Guard
The outside of the trommel is sealed by a guard to help prevent environmental pollution during operation.
Optional Cleaning Mechanism
A comb-shaped cleaning mechanism can be provided to clean the sieve body during screening without interrupting the process.
Simple Maintenance and Operation
The plant is described as easy to operate and maintain, helping mining teams manage daily use more efficiently in field conditions.
Technical Specifications
SKU
62443874548
Plant Type
Mobile Gold Trommel
Model GTS10 Trommel Type
800 × 1500 mm
Model GTS10 Productivity
5-10 t/h
Model GTS10 Motor Power
1 kW
Model GTS10 Dimensions
2500 × 1000 mm
Model GTS10 Sluice Box Size
2000 × 500 mm
Model GTS30 Trommel Type
1200 × 2500 mm
Model GTS30 Productivity
30 t/h
Model GTS30 Motor Power
35 kW
Model GTS30 Dimensions
5000 × 1400 mm
Model GTS30 Sluice Box Size
3000 × 1000 mm
Model GTS50 Trommel Type
1500 × 3000 mm
Model GTS50 Productivity
50 t/h
Model GTS50 Motor Power
50 kW
Model GTS50 Dimensions
6500 × 1800 mm
Model GTS50 Sluice Box Size
4500 × 1000 mm
Model GTS100 Trommel Type
1500 × 4500 mm
Model GTS100 Productivity
100 t/h
Model GTS100 Motor Power
100 kW
Model GTS100 Dimensions
8300 × 2200 mm
Model GTS100 Sluice Box Size
6000 × 1000 mm
Model GTS150 Trommel Type
1600 × 4800 mm
Model GTS150 Productivity
150 t/h
Model GTS150 Motor Power
120 kW
Model GTS150 Dimensions
9200 × 2200 mm
Model GTS150 Sluice Box Size
2 × (6000 × 1000 mm)
Model GTS200 Trommel Type
1800 × 5000 mm
Model GTS200 Productivity
200 t/h
Model GTS200 Motor Power
150 kW
Optional Modules
Centrifugal Concentrator SLT 30 - 5 t/h
Centrifugal Concentrator SLT 40 - 10 t/h
Centrifugal Concentrator SLT 60 - 20 t/h
Centrifugal Concentrator SLT 80 - 35 t/h
Centrifugal Concentrator SLT 100 - 75 t/h
Industries Served
Alluvial Gold Mining
Gold Washing Plants
Gold Screening Operations
Mobile Mineral Processing Sites
What's Included
Mobile gold trommel wash plant
Screening cylinder
Sluice box
Variable-speed deceleration system
Sealing guard
