Multi Purpose Hydraulic DTH Drilling Rig for Water Boreholes, Oil Wells & Geotechnical Work
Deep drilling power for water, oil and geotechnical projects
The FD580 is a diesel-powered rotary drilling rig with a 75KW engine, capable of drilling up to 50 metres deep with a 90–160mm diameter. Built for water boreholes, oil wells and geotechnical work, it combines mobility with reliable performance.
1-Year Warranty
Free Replacement Parts
Online Technical Support
Machinery Test Report Provided
Video Outgoing-Inspection Provided
Guide Price
R 495 750.60
Guide price excl. VAT & delivery — final quotation tailored to your specification.
Get your exact quote
Max. 50m
Drilling Depth
90–160mm
Drilling Diameter
75KW
Diesel Engine Power
7200 KG
Weight
4500–6000Nm
Rotating Torque
Yes
Mobility
Business Solution Overview
High Return on Investment: A single rig can serve multiple revenue streams — water borehole drilling, oil well exploration and geotechnical contracts — allowing contractors to keep the machine productive across different projects and seasons.
Versatile Multi-Purpose Capability: One machine covers three major drilling applications, reducing the need to invest in separate equipment for water, oil and geotechnical work, which lowers capital expenditure and simplifies fleet management.
Reliable Diesel Power: The 75KW diesel engine provides consistent power for deep drilling, while the 220V electrical system supports on-site auxiliary needs. This setup is ideal for locations where grid power is unreliable.
Low Maintenance with Warranty Support: A 1-year warranty and free replacement parts reduce downtime risk and after-sales costs. Online technical support ensures your team can resolve issues quickly without waiting for on-site visits.
Competitive Pricing for African Market: Sourced directly from verified Chinese manufacturers, the FD580 offers a cost-effective alternative to premium Western rigs, helping African buyers maximise value without compromising on core drilling capability.
Why Choose Multi Purpose Hydraulic DTH Drilling Rig?
Powerful 75KW Diesel Engine
Delivers strong, reliable drilling power for deep boreholes and tough geotechnical formations.
Deep Drilling Capability
Reaches depths up to 50 metres with a diameter range of 90–160mm, suitable for water and oil wells.
High Torque Rotary Head
4500–6000Nm of rotating torque ensures efficient penetration in rock and compacted soil.
Mobile and Easy to Move
Designed for mobility, allowing quick relocation between sites and remote project areas.
Warranty and Support
Comes with a 1-year warranty, free replacement parts and online technical support for peace of mind.
Multi-Purpose Application
One rig handles water boreholes, oil wells and geotechnical drilling, maximising utilisation.
Technical Specifications
Model
FD580
Type
Rotary Drilling Rig
Usage
Rock Drilling Rig
Drilling Depth
Max. 50m
Drilling Diameter
90–160mm
Recommended Caliber
90–160mm
Power Type
Diesel
Voltage
220V
Diesel Engine Power
75KW
Working Pressure
1.7–3.3Mpa
Drill Pipe Length
3M
Swing Speed
35–75
Tower Travel
3.6M
Rotating Torque
4500–6000Nm
Core Components
Pressure Vessel, Pump, Engine
Weight
7200 KG
Gross Rig Weight
7.2T
Dimensions (L*W*H)
6400*2350*2600mm
Mobility
Yes
Brand Name
FEIDA
Industries Served
Water Borehole Drilling
Oil Well Drilling
Geotechnical Engineering
Rock Drilling
Construction & Infrastructure
What's Included
Multi Purpose Hydraulic DTH Drilling Rig (Model FD580)
1-Year Warranty
Free Replacement Parts
Online Technical Support
Machinery Test Report
Video Outgoing-Inspection
