Gold & Precious Metal Processing

Gold Mill Gold Processing Plant

Integrated CIL plant for gold extraction and recovery

A gold CIL processing plant designed for crushing, grinding, leaching, adsorption, tailings handling and gold-loaded carbon treatment. The process uses activated carbon adsorption and downstream desorption, electrolysis and melting to produce gold bars.

Integrated CIL Process 8 Leaching Tanks Closed-Circuit Crushing Closed-Circuit Grinding Water Recycling Flow
Guide Price R 3 731 633 Guide price excl. VAT & delivery — final quotation tailored to your specification. Get your exact quote
Gold Mill Gold Processing Plant
Gold CIL Process Type
<10 mm Crushed Feed Size
90% of 200 mesh Grinding Fineness
8 Sets Double Impeller Leaching Tanks
Liquor Recycling Water Circuit
Business Solution Overview
Integrated Gold Recovery Flow: This plant combines ore preparation, grinding, leaching, adsorption, tailings handling and final gold recovery in one process route. A complete flow helps streamline plant design and operational coordination.
Supports Efficient Gold Adsorption: Activated carbon is used to adsorb the gold cyanide complex from solution, enabling separation from slurry by screening. This established CIL approach is designed around practical recovery of gold-loaded carbon for downstream treatment.
Recycling-Oriented Water Circuit: Filter liquor is returned to a circulating water tank for recycling. This helps save lime and sodium cyanide, supporting more efficient reagent and water use in ongoing plant operation.
Structured Multi-Stage Processing: The line uses three-step one closed-circle crushing and two-step two closed-circle grinding flows. This staged arrangement supports controlled particle size reduction and classification before leaching.
Final Gold Production Capability: Gold-loaded carbon is treated through desorption and electrolysis to produce gold dust, followed by melting into gold bars. This gives processors a clear path from ore feed to final bullion output.
3D Sketch
Gold Mill Gold Processing Plant — labelled 3D render

AI-generated labelled 3D render — illustrative, not a manufacturing drawing.

Complete End-to-End Process
Raw Ore Crushing
Grinding And Classification
Leaching And Adsorption
Tail Water Treatment
Desorption, Electrolysis And Melting
Why Choose Gold Mill Gold Processing Plant?

Carbon-In-Leach Gold Recovery

The plant uses activated carbon to adsorb aurocyanide and other complex ions from solution. Coarse carbon can then be separated from slurry by screening using wire mesh.

Multi-Stage Crushing Circuit

Raw ore is processed through primary, secondary and tertiary crushing with screening in a three-step one closed-circle flow. This prepares material for downstream grinding.

Two-Stage Closed-Circuit Grinding

The process uses ball mills, a spiral classifier and a hydro cyclone in a two-step two closed-circle grinding arrangement. Oversize material is returned for re-grinding.

Eight-Tank Leaching And Adsorption

The slurry enters 8 sets of double impeller leaching tanks. Sodium cyanide is added to the first tank, while activated carbon is added from the second to the eighth tank.

Tail Water Recycling

Tailings are filtered by filter press, while filter liquor is sent to a circulating water tank for reuse. This helps reduce consumption of lime and sodium cyanide.

Final Gold Bar Production

Gold-loaded carbon is treated by desorption and electrolysis equipment in batches to produce gold dust. The gold dust is then melted in a furnace to form gold bars.

Technical Specifications
Product Name Gold Mill Gold Processing Plant
SKU 1600257323654
Process Type Gold CIL (Carbon In Leach) Processing Plant
Crushed Material Size Less than 10 mm
Grinding Fineness 90% of 200 mesh
Crushing Flow Three step one closed circle crushing flow chart
Grinding Flow Two steps two closed circle grinding flow chart
Leaching Tanks 8 sets of double impeller leaching tank
Leaching Reagent Addition Sodium cyanide added to the first tank
Activated Carbon Addition Added from the second to the eighth tank
Gold Recovery From Carbon Desorption and electrolysis equipment
Final Product Gold bar
Tailings Handling Filter press, belt conveyor and truck to yard
Water Circuit Filter liquor recycled to circulating water tank
Optional Modules
Desorption And Electrolysis Equipment
Gold Melting Furnace
Filter Press
Industries Served
Gold Processing Plants
Precious Metal Recovery
Mineral Processing Operations
What's Included
Crushing and screening flow
Grinding and classification flow
Leaching and adsorption section
Tail water treatment section
Gold-loaded carbon treatment flow
