Complete Set of CNC Lathe Machine Tools CK6150 Including Spindles, Chucks and Cutting Tools
Heavy-duty precision CNC turning with FANUC control and twin spindles
The CK6150 is a heavy-duty horizontal CNC lathe with FANUC control, twin spindles and up to 2000 mm workpiece length. It delivers ±0.005 mm positioning accuracy and repeatability for demanding metal-cutting production.
1-Year Warranty
Machinery Test Report Provided
Video Outgoing-Inspection Provided
FANUC Control System
Heavy-Duty Machining Capacity
Guide Price
R 503 715.18
Guide price excl. VAT & delivery — final quotation tailored to your specification.
Get your exact quote
2000 mm
Max. Workpiece Length
1000 kg
Max. Workpiece Weight
50–1800 rpm
Spindle Speed Range
±0.005 mm
Positioning Accuracy
FANUC
CNC Control System
12 / 8 / 6 / 4
Tool Post Stations
Business Solution Overview
High Return on Investment: A busy machine shop running the CK6150 across multiple shifts can recover its investment through consistent production of precision-turned parts, while the twin-spindle configuration and multiple tool post options help reduce cycle times and increase throughput.
Built for Heavy-Duty Production: With a 300 mm bed width, 1000 kg workpiece capacity and 2000 mm maximum turning length, this lathe is engineered for continuous industrial use, reducing the need for frequent replacement and lowering long-term cost of ownership.
Precision That Protects Your Reputation: Positioning accuracy and repeatability of ±0.005 mm allow manufacturers to meet tight tolerances consistently, reducing scrap rates and rework while supporting higher-value contracts.
FANUC Control for Reliable Automation: The industry-standard FANUC CNC control system simplifies programming, improves process repeatability and supports integration into existing production workflows, helping operators become productive quickly.
Complete Set, Ready to Work: Supplied with spindles, chucks and cutting tools, the CK6150 arrives as a complete machining package. A 1-year warranty, machinery test report and outgoing-inspection video provide added confidence in the purchase.
Why Choose Complete Set of CNC Lathe Machine Tools?
FANUC CNC Control
Industry-standard FANUC control system delivers reliable, repeatable machining and simplifies operator training and programming.
Twin Spindle Configuration
Two spindles enable efficient machining of complex parts, reducing handling and improving throughput on multi-operation components.
Heavy-Duty Construction
A 300 mm bed width and 2000 kg machine weight provide the rigidity needed for heavy cutting and long service life.
High Precision and Repeatability
Both positioning accuracy and repeatability are rated at ±0.005 mm, supporting tight-tolerance production and reduced scrap.
Flexible Tooling Options
Choose from 12, 8, 6 or 4 tool post stations to match the complexity of your parts and your production strategy.
Documented Quality Assurance
Each machine is supplied with a machinery test report and an outgoing-inspection video, giving buyers verifiable performance evidence before dispatch.
Technical Specifications
Type
Horizontal
Model Number
CK6150
CNC Control System
FANUC
Number of Axes
2
Number of Spindles
Twin
Tool Post Stations
12, 8, 6, 4
Max. Length of Workpiece (mm)
750, 1000, 1500, 2000
Max. Weight of Workpiece (kg)
1000
Travel (X Axis) (mm)
300
Travel (Z Axis) (mm)
2000
Positioning Accuracy (mm)
±0.005
Repeatability (X/Y/Z) (mm)
±0.005
Spindle Speed Range
50 - 1800
Spindle Nose
A2-8
Spindle Bore
82 / 105 / 130
Spindle Taper
MT6
Cutting Torque
573
Width of Bed (mm)
300
Machining Capacity
Heavy Duty
Voltage
380 V, 220 V
Dimension (L*W*H)
2500 x 1500 x 1690 mm
Weight
2000 kg
Warranty
1 Year
Machinery Test Report
Provided
Video Outgoing-Inspection
Provided
Year
Newly Built
Industries Served
Machine Shops & Jobbing
Metal Fabrication
General Manufacturing
Heavy Equipment Parts
Repair & Maintenance Workshops
What's Included
CNC lathe machine CK6150
Spindles
Chucks
Cutting tools
FANUC CNC control system
Machinery test report
Outgoing-inspection video
1-year warranty
