Automatic 4 In 1 Pure Water Bottling Machine Production Line
Wash, fill and cap 6,000 bottles per hour in one compact line
A complete automatic 4-in-1 pure water bottling line that washes, fills and caps PET bottles at 6,000 BPH. Built from food-grade SUS304/316 stainless steel with PLC touch-screen control and a 2-year warranty.
2-Year Warranty
Free Spare Parts
Field Installation
Video Technical Support
Food-Grade Stainless Steel
Guide Price
R 802 933.70
Guide price excl. VAT & delivery — final quotation tailored to your specification.
Get your exact quote
6,000 BPH (500 ml)
Capacity
±2 mm
Filling Accuracy
SUS304 / SUS316
Material
PLC + Touch Screen
Control System
220V / 380V, 50Hz, 3P
Voltage
3,500 kg
Machine Weight
Business Solution Overview
One Machine, Three Functions: Washing, filling and capping are handled in a single 4-in-1 unit, which reduces the number of machines, transfer points and operators needed on the line. For a small or medium water factory this means a simpler layout and less labour tied up in bottle handling.
Throughput That Scales With Demand: At 6,000 bottles per hour for 500 ml PET bottles, the line can support a growing bottled-water business without an immediate second investment. The same output can be scheduled across shifts to match seasonal demand.
Food-Grade Build and Filling Accuracy: SUS304/316 stainless steel construction and sterile-water rinsing support clean, safe bottling, while ±2 mm filling accuracy helps keep fill levels consistent and reduce product giveaway.
Low Operating Complexity: PLC and touch-screen control, mechanical drive and normal-pressure filling keep day-to-day operation straightforward. Video technical support, online help and field installation are included to get the line running correctly from the start.
Backed for Two Years: The line ships with free spare parts and a 2-year warranty, giving buyers a supported start-up period rather than an unsupported machine purchase.
Complete End-to-End Process
Bottle Washing
Pure Water Filling
Capping
Why Choose Automatic 4 In 1 Pure Water Bottling Mac?
Fully Automatic 4-in-1 Design
Washing, filling and capping are performed in one machine, simplifying the line and reducing manual bottle handling between stages.
Accurate, Consistent Filling
Normal-pressure filling with ±2 mm precision helps maintain even fill levels across every bottle for a professional finished product.
Food-Grade Stainless Steel
SUS304/316 stainless steel construction supports hygiene, durability and long service life in a wet bottling environment.
PLC and Touch-Screen Control
A PLC with touch-screen interface makes the line easy to operate, monitor and adjust without specialist programming skills.
6,000 BPH Output
Runs at 6,000 bottles per hour on 500 ml PET bottles, giving small and medium water factories productive, repeatable output.
Sterile-Water Rinsing
Bottles are washed with sterile water at 0.3–0.7 MPa to help keep them clean and the finished water pure.
Technical Specifications
Capacity
6000 BPH (for 500ml bottles)
Filling Accuracy
±2mm
Voltage
220V, 380V, 50HZ 3P
Control System
PLC + Touch Screen
Material
SUS304/316 Stainless Steel
Washing Pressure
0.3 - 0.7 MPa
Washing Medium
Sterile water
Bottle Type
PET Plastic Bottles
Function
Washing, Filling, Capping
Machine Weight
3500 kg
Dimensions (L*W*H)
2500 x 2000 x 2300 mm
Processing Type
Normal Pressure Filling
Driven Type
Mechanical
Packaging Type
Bottles
Core Components
Motor, Pump, PLC, Gearbox
Warranty
2 Years
Industries Served
Pure Water Bottling Plants
Beverage Companies
Food Processing Facilities
Small & Medium Water Factories
What's Included
Automatic 4-in-1 washing, filling and capping machine
Free spare parts
Video technical support
Online support
Field installation
2-year warranty
