2T Steel Tilting Induction Melting Furnace for Iron Smelting
Industrial induction furnace for efficient scrap metal melting and refining
A 2-ton tilting induction melting furnace designed for iron electric smelting and scrap metal refining. Built for efficient operation, stable tilting performance, and reliable control in industrial metal melting applications.
2T Tilting Furnace
Microcomputer Control
T2 Copper Coil
Double-Layer Mica Insulation
Industrial Scrap Metal Melting
Guide Price
R 450 000
Guide price excl. VAT & delivery — final quotation tailored to your specification.
Get your exact quote
2T
Capacity
1500 kW
MF Power
3ph, 660V
Input Voltage
2500V
MF Voltage
800 Hz
MF Frequency
Business Solution Overview
Efficient Scrap Metal Utilisation: The furnace is designed to melt and refine a range of scrap metal inputs, including scrap auto parts, steel bars, screws, and iron leftovers. This supports better material recovery and helps operations turn metal waste into usable output.
Energy-Efficient Operation: The product description highlights high performance and energy efficiency, making it suitable for industrial users seeking dependable melting capability with improved operating efficiency.
Built for Industrial Reliability: A thick aluminium alloy furnace shell, T2 standard copper tube induction coil, and double-layer mica insulation contribute to long-term durability, operational stability, and safer performance in demanding production settings.
Simplified Operator Control: The microcomputer-based control board with one-key zero-pressure start helps simplify operation. Separate insulation design for the water pressure meters also makes monitoring more intuitive for operators.
Stable Tilting Performance: The three-stage turbine speed tilting reducer is designed for stable rotation and enhanced self-locking performance, supporting controlled furnace tilting during industrial melting and pouring processes.
Complete End-to-End Process
Load Scrap Metal
Induction Melting
Refine Metal
Tilt for Pouring
Why Choose 2T Steel Tilting Induction Melting Furna?
Thick Aluminium Alloy Furnace Body
The furnace body uses a thick aluminium alloy shell to minimise magnetic leakage while maintaining the structural strength required for industrial operation.
T2 Standard Copper Tube Coil
The induction coil is made from thick T2 standard copper tube to maximise performance and support long service life under demanding melting conditions.
Microcomputer-Based Control
A microcomputer control board enables one-key zero-pressure start, helping simplify operation and improve ease of use on the shop floor.
Water Pressure Monitoring Design
Separate insulation for the water pressure meters provides easier and more intuitive monitoring during furnace operation.
Double-Layer Mica Insulation
The capacitor uses double-layer mica insulation treatment to improve safety and stability, including protection in case of accidental water exposure.
Three-Stage Tilting Reducer
The furnace tilting reducer features a three-stage turbine speed system for stable rotation and enhanced self-locking performance during tilting.
Technical Specifications
Product Type
Steel Tilting Induction Melting Furnace
Application
Iron electric smelting and metal melting
Capacity
2T
MF Power
1500 kW
Input Voltage
3ph, 660V
MF Voltage
2500V
MF Frequency
800Hz
Furnace Body
Thick aluminium alloy shell
Induction Coil
Thick T2 standard copper tube
Control System
Microcomputer-based control board
Start Function
One-key zero-pressure start
Water Pressure Meter Design
Separate insulation design
Capacitor Insulation
Double-layer mica insulation treatment
Tilting Reducer
Three-stage turbine speed system
Industries Served
Metal Smelting
Foundries
Scrap Metal Recycling
Metallurgical Plants
What's Included
2T tilting induction melting furnace
Microcomputer-based control board
Water pressure monitoring design
Three-stage turbine speed tilting reducer
