150m Full Hydraulic Core Drilling Rig
Crawler-mounted hydraulic rig for exploration, water wells and engineering drilling
A full-hydraulic crawler-mounted core drilling rig for mineral exploration, geological studies, water well drilling and engineering projects. It combines a 92 kW diesel engine, wireline coring capability and adjustable drilling angles for field deployment.
Full Hydraulic
Crawler Mounted
Wireline Coring
Remote-Control Travel
Adjustable Drill Angle
Guide Price
R 2 428 000
Guide price excl. VAT & delivery — final quotation tailored to your specification.
Get your exact quote
150 m
Drilling Capacity (BTW, NTW & HTW)
92 kW
Rated Engine Power
1,400 N·m
Maximum Torque
1,400 rpm
Maximum Rotary Speed
800 m
Wireline Winch Rope Capacity
4.5 t
Machine Weight
Business Solution Overview
Versatile Project Use: This rig supports mineral exploration, geological studies, water well drilling and engineering work, helping contractors and drilling teams use one machine across multiple project types.
Productive Field Performance: The 92 kW engine, 1,400 N·m maximum torque and 1,400 rpm maximum rotary speed provide drilling power for demanding core drilling tasks.
Efficient Coring Workflow: An integrated wireline winch with 800 m rope capacity and a 2.0 m feed stroke supports practical coring operations and down-hole handling.
Remote-Site Mobility: Manual and remote-control crawler drive, combined with compact transport dimensions, supports movement and positioning on field projects.
Hydraulic Drilling Design: The full-hydraulic layout, dual-stage cooling system and crawler-mounted structure are designed for operation in demanding field conditions.
Why Choose 150m Full Hydraulic Core Drilling Rig?
Full Hydraulic Core Drilling
The rig uses a full-hydraulic system to support controlled drilling performance in demanding field conditions.
Crawler-Mounted Mobility
Manual and remote-control crawler drive supports machine movement and positioning on site and at remote project locations.
Adjustable Drilling Angle
The drill tower can be set between 45° and 90° to suit different drilling requirements.
Wireline Winch System
The integrated wireline winch has an 800 m rope capacity to support coring workflows and down-hole handling.
Yuchai Diesel Engine
A Yuchai four-cylinder diesel engine rated at 92 kW provides power for drilling operations.
Compact Transport Dimensions
Transport dimensions of 4.5 × 1.9 × 2.3 m support logistics planning and field deployment.
Technical Specifications
Model
QYD-150
Drilling Capacity (BTW)
150 m
Drilling Capacity (NTW)
150 m
Drilling Capacity (HTW)
150 m
Hydraulic Pressure
32 + 16 MPa
Engine
Yuchai Four-Cylinder Diesel Engine
Rated Engine Power
92 kW
Maximum Torque
1,400 N·m
Maximum Rotary Speed
1,400 rpm
Feed Stroke
2.0 m
Hoisting Force
240 kN
Propulsion Force
120 kN
Wireline Winch Rope Capacity
800 m
Wireline Winch Lifting Force
15 kN
Wireline Winch Speed
110 m/min
Drill Tower Height
6.1 m
Drilling Angle
45°–90°
Travel System
Manual & Remote-Control Crawler Drive
Transport Dimensions (L × W × H)
4.5 × 1.9 × 2.3 m
Machine Weight
4.5 t
Industries Served
Mining & Mineral Exploration
Geological Studies
Water Well Drilling
Engineering Projects
What's Included
150m Core Drilling Rig
Yuchai four-cylinder diesel engine
Integrated wireline winch system
Crawler travel system
Drill tower assembly
