XIlin 1ton 1.2ton 1.5ton Electric Rider Straddle Stacker With Straddle Legs And Adjustable Forks
XIlin 1ton 1.2ton 1.5ton Electric Rider Straddle Stacker With Straddle Legs And Adjustable Forks
XIlin 1ton 1.2ton 1.5ton Electric Rider Straddle Stacker With Straddle Legs And Adjustable Forks
XIlin 1ton 1.2ton 1.5ton Electric Rider Straddle Stacker With Straddle Legs And Adjustable Forks
XIlin 1ton 1.2ton 1.5ton Electric Rider Straddle Stacker With Straddle Legs And Adjustable Forks
XIlin 1ton 1.2ton 1.5ton Electric Rider Straddle Stacker With Straddle Legs And Adjustable Forks

R184,399

0 Customer Reviews

Add To Wishlist Share to Social

Electric Rider Straddle Stacker

The Xilin Electric Rider Straddle Stacker is a versatile and efficient material handling equipment, designed for stacking and transporting loads in tight spaces. With a range of load capacities from 1 ton to 1.5 tons, this electric rider stacker provides powerful, low-maintenance performance with advanced safety features. The straddle legs and adjustable forks make it adaptable for various applications, including warehousing, logistics, and manufacturing.

Key Features & Benefits:

Safety and Productivity:

  • AC Motor Technology: Eliminates the need for carbon brush replacements, reducing maintenance costs and downtime.
  • Multi-function Display: Features a Battery Discharge Indicator (BDI) and hour meter for easy monitoring of operational status.
  • Low-Noise Operation: Equipped with a damping cushion to reduce noise during operation, ensuring a quieter working environment.
  • Auto Deceleration: Ensures smooth and safe stopping, especially when moving at high speeds or on inclines.
  • Overload Protection: Built-in pressure relief valve protects the stacker from overloads, ensuring greater reliability and safety.
  • Braking System: Effective braking when the handle is in both upright and horizontal positions, enhancing safety.
  • Turtle Mode: Low-speed switch for safer handling in confined spaces.
  • Stepless Speed Control: Allows for precise speed adjustment based on operational needs.

Optimum Structural Design:

  • Low Center of Gravity: Ensures stable operation, reducing the risk of tipping during use.
  • Vertical Driving Wheel: Provides convenient maintenance access and a small turning radius for maneuverability in tight spaces.
  • Durable Motor Structure: Water-proof and dust-proof design extends the life of the motor and brake system, reducing wear and tear.
  • Interchangeable Mast and Frame: The mast and frame are designed to be separable and interchangeable, enhancing serviceability.

Technical Specifications:

SpecificationCTDK10-IIICTDK12-IIICTDK15-III
Load Capacity (kg)100012001500
Load Centre Distance (mm)600600600
Fork Height (Lowered) (mm)707070
Front Tyre Size (mm)Φ250x70Φ250x70Φ250x70
Rear Tyre Size (mm)Φ98x82Φ98x82Φ98x82
Height, Mast Closed (mm)2145/18952145/18952145/1895
Free Lift (mm)~~~
Max. Lift Height (mm)1600/25002500/30003000/3300
Height, Mast Extended (mm)2145/31453145/36453645/3995
Overall Length (mm)197519752055
Overall Width (mm)1182-15821182-15821182-1582
Fork Dimensions (mm)35x100x107035x100x107035x100x1070
Width Overall Forks (mm)200-800200-800200-800
Aisle Width for Pallets 800x1200 (mm)249024902570
Turning Radius (mm)162516251705
Travel Speed (laden/unladen) (km/h)7/7.17/7.17/7.1
Lift Speed (laden/unladen) (m/s)0.11/0.170.1/0.160.09/0.16
Lower Speed (laden/unladen) (m/s)0.15/0.160.15/0.160.15/0.16
Battery Voltage/Capacity (V/Ah)24/12024/12024/200
Battery Weight (kg)9090160
Battery Dimensions (mm)753x178x240753x178x240800x254x320
Weight (with battery) (kg)650/700/730/750660/710/740/760780/830/840/850

Advantages:

  • Efficient and Reliable: The AC motor and overload protection provide long-term reliability with minimal maintenance.
  • Space-Saving Design: The small turning radius and compact design allow for effective operation in narrow aisles, maximizing space utilization.
  • High Productivity: With its stepless speed control and turtle mode, the stacker offers optimal performance in various environments, from large warehouses to tight spaces.
  • Durable and Low Maintenance: Water-proof and dust-proof components ensure the stacker withstands harsh environments and provides long-term service.
