Product Overview

Condense Milk Production Line

This is a small and medium-sized condensed milk production line with simple production process and convenient operation. The production process strictly follows the international standard manufacturing process, and the finished product meets the requirements of food hygiene conditions. The finished product does not need to be refrigerated for transportation and storage, and the product packaging form can be configured according to customer requirements.

Produce Procedure

Raw material milk→ Filtration → Preheating Ingredients → Homogenization → Sterilization → Concentration → Crystallization → Filling → Sealing → Finished Product

Technology Parameters

Raw milk refrigeration tank


Installation size: 1800*1200*1650mm Unit power: 3P 1 unitRefrigeration medium: R404ATotal power: 2.6KWMixer: 0.37KWMixer speed 36r/min

Filter

Material: SUS304Filter: 200 meshFilter area: 0.16㎑Pipeline typeMaterial: SUS304

Preheating batching tank


Installation size: about Ξ¦700*1200mmHeating power: 12KWWeight: about 150KGMixer power: 0.37KWMixer speed: 36r/minPlate thickness: 2mmInsulation layer thickness: 5CMMaterial: SUS304Structure: three layers

Homogenizer

Material: SUS316Maximum pressure 25(mpa)Rated pressure 0-20(MPa)Power: 2.2KWDimensions: 775*520*935mm

Sterilizer

Installation size: about Ξ¦700*1200mmHeating power: 12KWWeight: about 150KGMixer power: 0.37KWMixing speed: 36r/minPlate thickness: 2mmInsulation layer thickness: 5CMMaterial: SUS304Structure: three layers

Vacuum decompression concentrator

Tank capacity: 200LVacuum degree: -0.06~-0.09MpaConcentration temperature: 40-80℃Condensation area: 1.16mΒ²Heating area: 1 .06mΒ²Vacuum pump: 1.5kwGas consumption: 50kg/h or power 36KWWater consumption: 20L/minDimensions: 2600*950*3200mm

Cooling crystallization tank

Installation size: about Ξ¦700*1200mmHeating power: 12KWWeight: about 150KGMixer power: 0.37KWMixing speed: 36r/minBoard thickness: 2mmInsulation layer thickness: 5CMMaterial: SUS304Structure: three layers

Cold water tank

Installation size: 1800*1200*1650mm Unit power: 3P 1 setRefrigeration medium: R404ATotal power: 2.6KWMixer: 0.37KWMixer speed 36r/min

Plunger quantitative filling machine

Air pressure: 0.4-0.6mpaSpeed: 4-60 bottles/minAccuracy: Β±0.5%Hopper capacity: 30-50 litersGas consumption: β‰₯0.008m3/secDimensions: 450*450*1550mmWeight: 25-60kg

Sealing machine


Speed: 15-25 cans/minApplicable bottle type: diameter 40-130mm height 40-200mmPower supply: 0.37KW 220VWith a set of molds

One-piece type CIP cleaning

Dimensions: 2600*1800*1800mmOperation platform: 2000*600*750mmInsulation material: polyurethane foamHeating power: 36KWCleaning pump flow: 10T/hReturn pump flow: 15T/hCleaning tank 500L*3

Liquid pump

Parts in contact with materials are made of SUS304Power: 0.37KW

Paste pump

Parts in contact with materials are made of SUS304Power: 0.75KW

Control system

Distribution cabinet is made of 304 stainless steel, waterproof grade IP55Wires are domestic 3C certified brandsEquipped with phase successive protectors, and all motors need to be equipped with thermal protectors;The front end of the distribution box is equipped with an inspection window; all actuators must be independently controllable.

Pipeline and accessories

Including pipes, valves, quick-connect fittings, power cords, wire troughs and all other auxiliary installation parts required for equipment connection, etc.

PRODUCT SPECIFICATIONS

NoItemData
1ModelSR-CM500
2Raw materialFresh Liquid Milk
3CapacityCustomized
4Voltage380V or Customized
5Power72KW
6MaterialSUS304
