Stainless Steel 20L Chemical Jacketed Reactor
Stainless Steel 20L Chemical Jacketed Reactor
Stainless Steel 20L Chemical Jacketed Reactor

R391,399

0 Customer Reviews

Add To Wishlist Share to Social

Stainless Steel 20L Chemical Jacketed Reactor



The Stainless Steel 20L Chemical Jacketed Reactor is a versatile and reliable solution for laboratory and small-scale industrial processes. Ideal for blending, mixing, and homogenizing liquids, it is designed to handle viscous fluids, chemicals, and food products with precision and safety..



Key Features



  • High-Performance Mixing: Equipped with a top mechanical agitator and a homogenizer for efficient blending and emulsification.
  • Premium Materials: Built with SS304/316 stainless steel for durability, corrosion resistance, and compatibility with various applications.
  • Adjustable Speed: Features a spindle speed range of 1–2900 rpm for versatile processing requirements.
  • Efficient Heating: Supports electric or steam heating with a maximum temperature of ≤150°C for optimal control.
  • Robust Construction: Includes explosion-proof motor, pressure vessel, and reliable core components for safe operation.
  • Compact Design: Dimensions of L890xW890xH1550mm make it space-efficient and suitable for laboratory use.
  • Customizable Options: Dimensions and other features can be tailored to specific requirements.
  • Wide Applications: Suitable for chemicals, food processing, shampoo production, and other viscous fluid applications.
  • Certified Safety and Quality: Machinery test reports and video inspections provided to ensure reliable performance.



StructureVertical, ellipse top or flat top, support by legs or lifting lugs. Single wall, or with jacket, or with insulation.
MaterialMaterial adopts S31603, or S304
Jacket TypeFull jacket, internal coil, external semi-coil, dimple jacket.lab reactor
InsulationAdopts aluminum silicate or polyurethane, thickness 50 mm or 75 mm.
Surface FinishingMechanical polishing, internal mirror polishing Ra 0.45; External matte, Ra 0.8
Heating MethodSteam heating, electric heating, thermal oil/hot water heating
Agitation SystemAdopt top center-entry agitator or side-entry agitator.
Agitator type: frame, anchor, paddle, turbine, spiral, screw, magnetic stirring.
Agitation speed: 10~120rpm, fixed speed or frequency speed.
Motor power: 0.55kw, 1.1kw, 1.5kw, 2.2kw, 3kw, 5.5kw, 7.5kw, etc.
AccessoriesManhole, CIP spraying ball, thermometer, piezometer, air filter, sight glass, light, counter flange.
StandardAll according to GMP requirements and GB150.1~4-2011 Design, Fabrication, Inspection and Acceptance.
ODM/ODMCan be customized according to customers requirement and product process.



Size Information

Volume （L）

Core Dia.

(mm)

Jacket Cover

dia (mm)

Motorpower

(KW)

Working pressure (MPa)Speed RPMVacuum (MPa)Working temperature (℃)
304005000.6-1.1homoeothermy51-35< - 0.090~100
505006000.6-1.1homoeothermy51-35< - 0.090~100
1005506501.1-1.5homoeothermy51-35< - 0.090~100
1506007002.2homoeothermy51-35< - 0.090~100
2006507502.2homoeothermy51-35< - 0.090~100
30020501103homoeothermy51-35< - 0.090~100
50090010004homoeothermy51-35< - 0.090~100
800110012005homoeothermy51-35< - 0.090~100
1000120013006homoeothermy51-35< - 0.090~100
15001300614004homoeothermy51-35< - 0.090~100
2000140015004homoeothermy51-35< - 0.090~100
2500140015007.5homoeothermy51-35< - 0.090~100
4000150016007.5homoeothermy51-35< - 0.090~100
80002000210015homoeothermy51-35< - 0.090~100
320003000210037homoeothermy51-35< - 0.090~100



The Stainless Steel 20L Chemical Jacketed Reactor combines high safety standards with exceptional functionality, making it an essential tool for precision mixing in laboratories and small-scale production settings.
