RLD800 Geological Core Drilling Rig Machine
RLD800 Geological Core Drilling Rig Machine
RLD800 Geological Core Drilling Rig Machine
RLD800 Geological Core Drilling Rig Machine

0 Customer Reviews

Add To Wishlist Add To Compare Share to Social

Product Description

II. Characteristics

Full hydraulic core drilling rig is a new type of drilling rig developed by our company on the basis of referring to the advanced technology of similar drilling rigs at home and abroad. It is mainly suitable for the drilling of solid mineral deposits, and can also be used for engineering geology, shallow oil, natural gas, groundwater drilling, and can also be used for engineering drilling such as tunnel ventilation, drainage, and dam grouting. The drilling rig is driven by full hydraulic pressure, the rotation of the power head is driven by an axial plunger pump and an inclined-axis plunger motor, two mechanical gears plus stepless speed regulation, and an advanced structure. The power head adopts an oil cylinder chain double-speed feeding mechanism, which is stable and reliable in movement, and has a lateral translation mechanism of the power head. The mast adopts an oil cylinder to lift and fall to slide as a whole, and can drill holes within the range of 0-90°. The hydraulic system adopts load sensitive control, with high working efficiency and large torque. The drilling rig is equipped with hydraulic trojan grippers, hydraulic leveling legs, retractable mast and other devices to facilitate the rapid positioning of the drilling rig. Equipped with wireless remote control crawler, it is suitable for various terrains and controls the crawling of the drilling rig within a safe distance to prevent sudden danger.

ModelRLD600RLD800RLD1000
Drilling CapacityBTW (m)65012001400
NTW (m)60010001200
HTW (m)3008001000
PQ (m)200600800
Hydraulic SystemsRated Pressure Mpa32+1632+1632+16
Cooling MethodAir cooling + Water coolingAir cooling + Water coolingAir cooling + Water cooling
Engine ParameterModelYuchai 4 CylinderYuchai 6 CylinderYuchai 6 Cylinder
Rated Speed Kw9292129
Rated Speed rpm220022002300
Power Head parametersMaximum Torque N.m140018002600
Maximum speed rpm140014001400
Stroke / m223.5
Lifting Force kN240300360
Thrust kN120150180
Parameters of Rope Coring WinchWire Rope Length Capacity m80010001200
Lifting Force kN152024
Lifting Speed m/min110110110
Wire Rope Diameter/mm556
Mast ParametersHeight/m6.16.17.9
Drilling Angle°45-9045-9035-90
Slip Stroke mm8008001200
Gripper ParametersBQ/NQ/HQ/PQ130mm130mm
Track ParametersMaximum climbing angle°202020
Maximum Walking Speed km/h222
Package SizeL*W*H mm4500*1900*26504500*2100*28005600*2200*3000
Weight（t）4.567.3
