PID control stainless steel biodiesel machine reactor
Introduction
This serious product is a kind of PID control stainless steel biodiesel processor machine reactor with features of magnetic seal (static seal), no leakage, smooth run, low noise and easy operation, which is widely used for various chemical reaction in laboratory, under high pressure, high vacuum and high temperature condition. And Sometimes can be equipped with condensers for vapor escape and distillation process.
Application: Laboratory research, lab test and reaction under high pressure, high vacuum and high temperature condition,hydrogenation, catalyst testing, crystallization, synthesis, etc.
Product Feature
Floor stands or moveable cart type.
Laboratory autoclaves with 500 ml to 5 liters volume.
Max pressure: 300 bar; Max temperature up to 500 ℃.
Low to high torque magnetic couplings: static seal with no leakage
Available material:SS304, SS316, Titanium, Nickel, Hastelloy B/C, Monel, Zirconium, Inconel.
Smooth run, low noise and easy operation.
Monitor and control: Temperature, pressure, motor speed, operation time, etc.
Safety Device (Blasting Disc) on Security Blasting Port.
Customized according to customers requirement.
Standard Specification
Model No.
GSH-0.5
GSH-1
GSH-2
GSH-3
GSH-5
Nominal Capacity (L)
0.5
1
2
3
5
Working Pressure (MPa)
10
10
10
10
10
Working Temperature (℃)
350
350
350
350
350
Stirring Speed (r/min)
0-1500
0-1500
0-1500
0-1500
0-1500
Motor power (kW)
0.15
0.2
0.2
0.2
0.6
Heating Power (kW)
1
2
2
3
4
Material
SS304 or SS316
Heating Method
General electric heating
Cooling Method
Internal spiral coils
Charging Method
Charging from above
Stirring type
Propeller, paddle type, anchor type or customized
Control panel
Temperature, time and heating voltage display
Temperature adjustment control, accuracy±1 ℃
Stirring speed display and control
Standard fittings
Pressure Gage; Thermocouple; Internal Stirring System
Liquid inlet and gas inlet with needle valve;Gas Release Valve
Dip Tube; Safety Rupture Disc; Cooling Coil
Note:Customer is advised to select best suited options for most optimized price & delivery.
Customization of volume, material, pressure, temperature etc. may be possible on request.
Product Drawings
Product drawings
Internal drawings
Control details
