Paperless Recorder Temperature Data Logger with 4-Channel RS485
- Section : Consumer Electronics
- Category : Test Instruments
- SKU : 60429735264
Paperless Recorder Temperature Data Logger with 4-Channel RS485
The Paperless Recorder Temperature Data Logger with 4-channel RS485 is an advanced, versatile solution for precise temperature and environmental monitoring. This device is ideal for applications in industrial settings, laboratories, and environmental management, offering reliable data recording with easy data access and transfer capabilities.
Key Features
- Multi-Channel Inputs: Supports 1 to 4 channels for flexible measurement options.
- Wide Range of Inputs: Compatible with voltage, current, thermocouple, and RTD inputs to monitor a variety of environmental conditions.
- High Accuracy: Provides ±0.2% FS accuracy for precise data collection.
- RS-485 Communication: Equipped with RS-485 or RS-232 communication ports for reliable data transfer and integration with monitoring systems.
- Sampling Period Options: Adjustable recording intervals from 1 second to 4 minutes, providing flexibility for different monitoring needs.
- Large Display: Features a 3-inch LCD screen for clear visualization of real-time data.
- Internal Storage: 48M bytes of flash memory for storing data over extended periods.
- External Storage Support: U disk support via standard USB2.0 interface for easy data transfer and backup.
- Compact and Durable: Dimensions of 96mm×96mm×96mm with an opening size of 92mm×92mm. Constructed to withstand operational environments with humidity levels from 10% to 85% RH.
- Energy Efficient: Operating on AC 176-240V, with a maximum power consumption of only 20VA.
- Operating Conditions: Reliable performance in temperatures from 0°C to 50°C with an external storage temperature range of -20°C to 60°C.
Conclusion
The Paperless Recorder Temperature Data Logger is the ideal tool for monitoring critical temperature and environmental data. With its flexible input options, high accuracy, and efficient data storage and transfer, it is perfect for a wide range of industrial, research, and environmental applications.
Product Info Gallery
| Shape dimension | Shape dimension:96mm×96mm×96mm Opening Size:92mm×92mm |
| Thickness of mounted panel | 1.5mm~6.0mm |
| Weight | 0.37kg |
| Electricity supply | (176~264)VAC,47~63Hz |
| Internal storage | 48M bytes Flash |
| External storage | U disk support (standard USB2.0 communication interface) |
| The maximum power consumption | 20VA |
| Relative humidity | (10~85)%RH(No condensation) |
| Operating temperature | (0~50)℃ |
| Transport and storage conditions | temperature (-20~60)℃,Relative humidity (5~95)%RH(No condensation) Altitude:<2000m,Except for special specifications |
Input signal
| Type | The maximum permissible error(%FS) |
| (1~5)V | ±0.1 |
| (4~20)mA | ±0.2 |
| Type | Measure range(℃) |
| B | 600 ~ 1800 |
| E | -200 ~ 1000 |
| J | -200 ~ 1200 |
| K | -200 ~ -100 |
| -100 ~ 1300 | |
| S | -50 ~ 100 |
| 100 ~ 300 | |
| 300 ~ 1600 | |
| T | -200 ~ -100 |
| -100 ~ 380 | |
| R | -50 ~ 100 |
| 100 ~ 300 | |
| 300 ~ 1600 | |
| N | -200 ~ 1300 |
| Type | Measure range (℃) |
| Cu50 | -50 ~ 140 |
| Pt100 | -200 ~ 800 |
| NOTE:special RTD can be customized,like Pt1000 etc |
- Shipping Timeframes: All orders are processed within 2-5 business days (excluding weekends and holidays). After your order has been processed, the estimated delivery time is before 03 Feb, 2026, depending on customs, Please note that due to high demand, some items may experience longer shipping times, which will be communicated at order confirmation email.
- Order Processing Time: Please allow 2-5 business days for us to process your order before it is shipped . Orders placed after 16:00 on Fridays, or during weekends and public holidays, will begin processing on the next business day. Processing times may be extended during peak seasons or sales events.
- Manufacturing Time: Some products needs manufacturing time, the manufacturing process will take approximately 10-30 business days depending on the product. This timeframe may vary depending on the complexity of the product and current demand. but this will be communicated with you during order confirmation.
- Returns and Exchanges: We offer a 30-day return policy for most items. If you are not completely satisfied with your purchase, you may return it within 30 days of receipt for a refund or exchange. Items must be unused, in their original packaging, and accompanied by proof of purchase. Return shipping costs are the responsibility of the customer, unless the item was damaged or defective upon arrival.
1. What types of inputs does the Paperless Recorder support?
The Paperless Recorder supports voltage, current, thermocouple, and RTD inputs, allowing for versatile monitoring of various environmental conditions.
2. What is the accuracy of the temperature data logger?
The device provides a high accuracy of ±0.2% FS, ensuring precise data collection for your monitoring needs.
3. How many channels does this data logger support?
The Paperless Recorder supports 1 to 4 channels, offering flexibility for multi-channel temperature monitoring.
4. What is the maximum power consumption of the device?
The maximum power consumption of the Paperless Recorder is only 20VA, making it energy efficient.
5. Can I transfer data from the device to my computer?
Yes, the Paperless Recorder supports external storage via a USB2.0 interface, allowing for easy data transfer and backup.
6. What are the operating conditions for this temperature data logger?
The device operates reliably in temperatures from 0°C to 50°C and can be safely stored in temperatures ranging from -20°C to 60°C.
7. How large is the internal storage of the device?
The internal storage capacity of the Paperless Recorder is 48M bytes of flash memory, allowing for extended data storage.
8. What is the size and weight of the device?
The dimensions of the Paperless Recorder are 96mm×96mm×96mm, and it weighs 0.37kg.
9. What is the sampling period for data recording?
The device offers adjustable recording intervals from 1 second to 4 minutes, allowing flexibility for different monitoring needs.
10. Is the device suitable for industrial environments?
Yes, the Paperless Recorder is designed to withstand operational environments with humidity levels from 10% to 85% RH and is compact and durable.
11. What types of thermocouples are compatible with this device?
The Paperless Recorder is compatible with various thermocouples including B, E, J, K, S, T, R, and N types, covering a wide measurement range.
12. Does the device have a display for real-time data visualization?
Yes, the Paperless Recorder features a 3-inch LCD screen for clear visualization of real-time data.
13. What is the relative humidity range for operation?
The operating relative humidity for the device ranges from 10% to 85% RH without condensation.
14. Can I customize the input types for specific applications?
Yes, special RTD types, like Pt1000, can be customized to meet specific application requirements.
15. What communication protocols does the device support?
The Paperless Recorder is equipped with RS-485 or RS-232 communication ports for reliable data transfer and integration with other monitoring systems.
