General Industry Wood Turning Tools GT46L CNC Lathe – Slant Bed Horizontal Electric Spindle CNC Turning Lathe With Turret
- Section : Machinery
- Category : Lathe
- SKU : 1600886202468
General Industry Wood Turning Tools GT46L CNC Lathe – Slant Bed Horizontal Electric Spindle CNC Turning Lathe With Turret
The GT46L CNC Turning Lathe from STS is a high-precision, medium-duty lathe designed for wood and metal turning applications. This lathe is engineered for efficiency and accuracy, providing excellent performance in a wide range of industrial settings. With its automatic functions and powerful spindle motor, it's an ideal solution for both wood and metal machining.
Key Features:
- Machining Capacity: Designed for medium-duty tasks, the GT46L can handle a wide variety of materials, including wood and metal, making it versatile for different applications.
- Spindle Motor Power: 5.5kW spindle motor ensures strong cutting capabilities and smooth operation, providing the necessary power for a variety of turning tasks.
- Axes and Travel Distance: The lathe operates with 3 axes and offers 1200mm of travel on the X-axis and 350mm on the Z-axis, allowing for large workpieces and complex machining operations.
- Precision: The lathe offers positioning accuracy of ±0.0025mm, ensuring tight tolerances and precise results for every job.
- Tool Post Stations: Equipped with 8 tool post stations, this CNC lathe can switch between tools with ease, reducing downtime and increasing productivity.
- CNC Control System: The SYNTEC control system provides a user-friendly interface and precise control over the lathe's operations, making it easier to program and operate for both beginners and experts.
- Automatic Features: With automatic functions, the GT46L simplifies operations, reducing manual intervention and increasing overall efficiency.
- Bed Width: The 35mm bed width ensures strong support and stability during operations, maintaining precision even with larger workpieces.
- After-Sales Support: Machinery test reports and video outgoing inspection ensure that you are receiving a fully functional and tested product ready for use.
Specifications:
- Machining Capacity: Medium Duty
- Spindle Motor Power: 5.5kW
- Number of Spindles: Single
- Number of Axes: 3
- X-axis Travel: 1200mm
- Z-axis Travel: 350mm
- Positioning Accuracy: ±0.0025mm
- Tool Post Stations: 8
- Weight: 3400kg
- Control System: SYNTEC
- Voltage: 380VAC 50Hz
- Width of Bed: 35mm
- Dimensions (L x W x H): 2350mm x 1650mm x 2000mm
The GT46L CNC Lathe is engineered for high efficiency, precision, and long-lasting performance. Whether you're machining wood or metal, its robust design and advanced features make it an excellent choice for industrial operations requiring accurate and reliable turning capabilities.
Product Info Gallery
Product Specifications
| CAPACITY | |
| Swing Over Cross Bed | Φ580mm |
| Swing Over Carriage | Φ100mm |
| Max. Length of Workpiece | 350mm |
| Turning Diameter | Bar Materials up to Φ45mm Single Workpiece up to Φ480mm |
| Bed Type | 45° Slant Bed |
| SPINDLE | |
| Spindle Nose Taper | A2-5 |
| Speed | 4000 RPM |
| Spindle Motor Power | 5.5 kW Servo Motor 7.5 kW Servo Drive |
| Collet Type | Hydraulic Collet |
| Spindle bore | Φ56mm |
| TRAVELS | |
| Z-Axis | 350mm |
| X-Axis | 1200mm |
| Guideway Type | 32mm THK/NSK ball screw rod 35mm THK/INA linear guideway |
| Z/X Axis | Up to 25m/min |
| Machining Accuracy | ±0.0025mm |
| Surface roughness | ≤Ra 1.6μm |
| TOOLS | |
| Tool type | Gang type |
| Tool holder | Parting tool holder (2 sets) Single tool holder (2 sets) Dual tool holder (1 sets) Drilling tool holder (3 sets) |
| Motor & Servo | |
| Z&X Axis | 1.3kW Servo Motor 1.5kW Servo Drive |
| CNC CONTROL | |
| Controller | SYNTEC |
| POWER SUPPLY | |
| Total Power | 10KW |
| Voltage | 380VAC 50Hz |
| DIMENSIONS | |
| Dimensions (L/W/H) | 2350mm*1650mm*2000 mm |
| Weight | 3400 kg |
Standard Configuration
| Fully enclosed splash guard with top roof | 5.5KW spindle servo motor | Telescopic guards for X/Z axes |
| Spindle speed 4000 rpm, A2-5 | Automatic lubrication system | Coolant system Coolant tank |
| Hydraulic Collet | Hydraulic system | Positioning C-axis |
| CNC Simulation | LED working lamp | Electronic handwheel (MPG) |
| Toolbox and user manuals |
