DDX14 GPS Tracker for Real-Time Tracking with Geo-Fence and Remote Control
The DDX14 GPS Tracker is designed for reliable, real-time tracking applications. Ideal for handheld use, this compact device offers advanced features like geo-fencing, GPS, WiFi, and LBS tracking, making it perfect for a variety of tracking needs, including security and monitoring.
Key Features
Real-Time Tracking: Monitor locations with real-time updates using GPS, WiFi, and LBS tracking.
Geo-Fence Alerts: Set up virtual boundaries for alerts whenever the device crosses them.
Remote Control: Control the device remotely for enhanced flexibility.
Long Battery Life: Equipped with a 2500mAh battery for extended use.
IP68 Waterproof: Built to withstand water, making it perfect for outdoor applications.
Wide Network Compatibility: Supports Wifi, 3G, and 4G networks for broad connectivity.
Certified for Safety: FCC, CE, and RoHS certified for safe use.
Efficient Performance: Powered by a 52832 CPU and Free RTOS system for smooth operation.
Portable Design: Lightweight and compact, ideal for handheld use.
GPS Ankle Functions
NO.
Name
Description
1
Real Time Tracking
Indoor and outdoor high-precision real-time tracking. The real-time position of the tracked object can be viewed on the map at any time.
2
Blind Area Supplementary Report
It can store the location and alarm information of mobile network interruption state, and automatically resend after network signal recovery.
3
Historical Route
You can view the historical route of the terminal in any time period on the map.
4
Virtual Fence
Some key areas can be set as virtual fences. Once the terminal enters or exits the fence, the system will alarm immediately.
5
Route Planning
The administrator can set the daily travel route and time period of the terminal in advance. Once deviated from the designated route, the system will alarm immediately.
6
Wifi Monitoring
The system can automatically collect the specified WiFi hotspots regularly to detect whether the terminal is in the designated area. Once the terminal leaves the designated area, the system will alarm immediately.
When the terminal power is less than 20%, it will automatically generate low power alarm, vibration will remind the wearer and send the low power alarm information to the management system.
9
Message
The terminal can receive the setting instructions and messages pushed by the system.
10
Pedometer
The built-in motion sensor can realize the step counting function, and the system can automatically count the steps every day.
11
Remote Settings
Support online settings through the network to facilitate remote management.
12
Remote Upgrade
Support online upgrade through the network, convenient remote maintenance.
13
Two Way Ranging
It can monitor the distance between the GPS ankle and the designated ranging base station in real time.
14
Over Distance Alarm
Once the distance between the GPS ankle and the designated ranging base station exceeds the set threshold, the system will alarm immediately.
GPS Ankle Parameters
NO.
Name
Description
1
Model
DDX14
2
Tracking Mode
It supports GPS / Beidou / WiFi / lbs hybrid tracking, and the terminal can automatically switch the most suitable tracking mode according to the change of environment, and supports Gaode and Google maps.
3
Tracking Accuracy
Without occlusion, the maximum tracking accuracy can reach 5 meters.
4
Tracking Frequency
By default, it tracks once every 30 seconds, which can be set.
5
Ranging Method
TOF bidirectional ranging technology based on UWB.
6
Ranging Frequency
3.75-4.25GHzγ
7
Ranging Distance
In the open environment, the maximum distance can reach 300 meters.
8
Ranging Accuracy
In the open environment, the highest accuracy can reach 0.3m.
9
Ranging Interval
Once every 30 seconds, can be set.
10
Antenna Type
Built in omnidirectional antenna.
11
Network Type
4Gγ
12
Sim Card
Nano SIM card.
13
System
We provide supporting management system, also can push data to the third-party management system.
14
Data Security
Built in encryption transmission and security authentication to ensure data security.
15
Switch On / Off
GPS ankle power on automatically, unable to manually turn off. In special circumstances, the system can be shut down remotely by the administrator.
16
Vibration Alert
yes.
17
Indicator Light
Power / charge / work / alarm indicator.
18
External Interface
Magnetic charging and data interface.
19
Battery
2500 MAH rechargeable battery.
20
Standby Time
Tracking once every 30 seconds, standby for 36 hours.
21
Charging Time
Two hours.
22
Charging Voltage
5Vγ
23
Charging Mode
First, fully charge the snap on mobile power supply, and then buckle the mobile power supply on the GPS ankle to charge the GPS ankle. When charging, there is no need to connect the power cord, and the wearer can walk freely.
24
Shell Material
Environmental friendly plastic.
25
Waterproof
IP68.
26
Size / Weight
The product is 100 * 120 * 50mm / 100g. The color box is 140 * 140 * 60MM / 150g. The carton is 450 * 450 * 350mm / 7kg (45 pieces).
Includes GPS ankle, snap on charger, magnetic data cable, user manual and warranty card.
The DDX14 GPS Tracker is an excellent choice for real-time tracking applications that require portability, durability, and advanced features like geo-fencing and remote control.
Product Info Gallery
Home Curfew Base Station Functions
NO.
Name
Description
1
Two Way Ranging
The distance between the ranging base station and the designated GPS ankle can be monitored in real time.
2
Over Distance Alarm
Once the distance between GPS ankle and ranging base station exceeds the set threshold, the system will alarm immediately.
3
Voice Broadcasting
The high decibel horn is built in the ranging base station, and the alarm content can be played automatically when the alarm is given.
4
Phone Call
The administrator can dial the built-in telephone number of ranging base station, and the terminal will answer automatically.
5
Monitor
The administrator can dial the built-in number of ranging base station, and the terminal will answer silently.
6
Fingerprint Identification
yes
7
Nfc
yes
8
Mobile Alarm
The base station has a built-in motion sensor. Once the illegal movement, the system will alarm immediately.
9
Low Power Alarm
When the power supply of the base station is disconnected and the power of the built-in battery is less than 20%, the low power alarm will be automatically generated.
10
Remote Settings
Support online settings through the network to facilitate remote management.
11
Remote Upgrade
Support online upgrade through the network, convenient remote maintenance.
Home Curfew Base Station Parameters
NO.
Name
Description
1
Model
DDX15
2
Ranging Method
TOF bidirectional ranging technology based on UWB.
3
Ranging Frequency
3.75-4.25GHzγ
4
Ranging Distance
In the open environment, the maximum distance can reach 300 meters.
5
Ranging Accuracy
In the open environment, the highest accuracy can reach 0.3m.
6
Ranging Interval
Once every 10 seconds, can be set.
7
Ranging Antenna
Built in omnidirectional antenna.
8
Network Type
4Gγ
9
Sim Card
Nano SIM card.
10
System
We provide supporting management system, also can push data to the third-party management system.
11
Data Security
Built in encryption transmission and security authentication to ensure data security.
12
Switch On / Off
It can only be turned on, not turned off.
13
Indicator Light
Power / charge / work / alarm indicator.
14
Reminders
Indicator light and horn
15
External Interface
Magnetic charging and data interface.
16
Battery
2000 MAH rechargeable battery.
17
Standby Time
In case of power failure, it can stand by for 36 hours.
18
Power Waste
3Wγ
19
Charging Time
Two hours.
20
Charging Voltage
5Vγ
21
Installation Mode
Desktop type.
22
Shell Material
Environmentally friendly plastics.
23
Waterproof
IP67.
24
Size/Weight
The product is 155 * 155 * 40MM / 100g. The color box is 180 * 180 * 60MM / 250g. The carton is 400 * 400 * 350mm / 5kg (20 pieces).
Including ranging base station, magnetic data cable, user manual and warranty card.
System
NO.
Name
Description
1
System Architecture
The system adopts BS structure and is easy to install.
2
Installation Environment
Linuxγ
3
System Capacity
There is no limit to the number of tags and login clients.
