CNC Lathe Machine CK6163 by SANJI
The CNC Lathe Machine CK6163 by SANJI is a medium-duty machining solution designed for precision and versatility. Ideal for various metalworking applications, this machine excels in turning, milling, drilling, and threading tasks.
Key Features
Robust Machining Capacity: Designed for medium-duty applications, this machine can handle workpieces weighing up to 3000 kg.
Powerful Spindle Motor: Equipped with an 11 kW spindle motor, providing the necessary power for efficient operation.
Single Spindle Design: The single spindle configuration ensures reliable performance and straightforward operation.
2-Axis Movement: Features two axes of movement (X and Z), with a travel distance of 370 mm on the X-axis and 2000 mm on the Z-axis for flexibility in machining various workpieces.
High Precision: Offers positioning accuracy of 0.01 mm and repeatability of 0.015 mm, ensuring precise results every time.
Customizable Voltage: Voltage specifications can be tailored to meet customer requirements, enhancing adaptability in various environments.
Multiple Tool Post Stations: Comes with options for 8, 6, or 4 tool post stations, allowing for quick tool changes and increased productivity.
Sturdy Construction: Weighing 2420 kg, the machine provides stability during operation, minimizing vibrations for improved accuracy.
User-Friendly Dimensions: With a bed width of 550 mm and overall dimensions of 3300 x 1800 x 1850 mm, it fits well in most workshops.
Control System Options: Compatible with various CNC control systems, including SIEMENS, GSK, FANUC, and Mitsubishi, offering flexibility based on user preferences.
High Safety Level: Designed with safety in mind, ensuring a secure working environment for operators.
Comprehensive After-Sales Service: Supported by a 1-year warranty and available after-sales service, ensuring reliable support for your machine.
In conclusion, the CNC Lathe Machine CK6163 by SANJI is an excellent choice for businesses looking for a versatile and precise machining solution. Its robust features, high safety standards, and adaptability make it suitable for a wide range of metalworking applications. Whether you need turning, milling, or drilling capabilities, this machine will help you achieve outstanding results.
Product Info Gallery
| Maximum swing diameter on the bed | mm | 630 |
| Maximum cutting length | mm | 850/1350/1850 |
| Maximum cutting diameter | mm | 630 |
| Maximum swing diameter on skateboard | mm | 400 |
| Width of guide surface | mm | 550 |
| Spindle end type and code | A11 | |
| Spindle hole diameter | mm | 105/130 |
| Maximum diameter of passing bar stock | mm | 91/116 |
| Spindle rotation speed range | r/min | 30-84；300-835；53-150； |
| Maximum spindle output torque | Nm | 125-350 |
| Main motor power | kW | 11 |
| Chuck diameter | mm | 400 Manually |
| X-axis fast moving speed | m/min | 4 |
| Z-axis fast moving speed | m/min | 8 |
| X axis stroke | mm | 370 |
| Z axis stroke | mm | 1000/1500/2000 |
| Tailstock sleeve diameter/stroke | mm | 100/250 |
| Taper of tailstock spindle taper hole | MOSHI | 6# |
| Total weight of machine | kg | 4800/5300/5800 |
| Machine shape L×W×H | mm | 3300/3800/4300×1800×1850 |
| X-axis positioning accuracy | mm | 0.01 |
| Z-axis positioning accuracy | mm | 0.015 |
Applicable fields
Details Display
- Shipping Timeframes: All orders are processed within 2-5 business days (excluding weekends and holidays). After your order has been processed, the estimated delivery time is before 03 Feb, 2026, depending on customs, Please note that due to high demand, some items may experience longer shipping times, which will be communicated at order confirmation email.
- Order Processing Time: Please allow 2-5 business days for us to process your order before it is shipped . Orders placed after 16:00 on Fridays, or during weekends and public holidays, will begin processing on the next business day. Processing times may be extended during peak seasons or sales events.
- Manufacturing Time: Some products needs manufacturing time, the manufacturing process will take approximately 10-30 business days depending on the product. This timeframe may vary depending on the complexity of the product and current demand. but this will be communicated with you during order confirmation.
- Returns and Exchanges: We offer a 30-day return policy for most items. If you are not completely satisfied with your purchase, you may return it within 30 days of receipt for a refund or exchange. Items must be unused, in their original packaging, and accompanied by proof of purchase. Return shipping costs are the responsibility of the customer, unless the item was damaged or defective upon arrival.
1. What is the CNC Lathe Machine CK6163 by SANJI?
The CK6163 is a medium-duty CNC lathe designed for precision turning, milling, drilling and threading. It features a single spindle, 2-axis (X/Z) control, multiple tool post options and is built for versatile metalworking applications.
2. What are the main technical specifications?
Key specs include an 11 kW spindle motor, X-axis travel 370 mm, Z-axis travel options 1000/1500/2000 mm, X positioning accuracy 0.01 mm, Z repeatability 0.015 mm, maximum swing on bed 630 mm, max cutting diameter 630 mm and multiple spindle speed ranges depending on gearing.
3. What workpiece sizes and weights can it handle?
Maximum swing on the bed is 630 mm (400 mm on the carriage). Maximum cutting lengths available are 850, 1350 or 1850 mm. The machine is designed to handle heavy workpieces; actual workable weight depends on configuration—machine gross weights are listed approximately 4800, 5300 or 5800 kg depending on length. (Please confirm allowable workpiece weight with SANJI for your specific setup.)
4. What is the bar stock capacity and spindle bore size?
Spindle bore diameter options are 105 mm or 130 mm. Maximum diameter of passing bar stock is 91 mm or 116 mm depending on spindle/bore selection.
5. What accuracy and repeatability does the CK6163 offer?
X-axis positioning accuracy is 0.01 mm and Z-axis positioning accuracy (repeatability) is 0.015 mm, providing high precision for most medium-duty machining tasks.
6. Which CNC control systems are supported?
The CK6163 is compatible with multiple control systems including SIEMENS, GSK, FANUC and Mitsubishi to match user preference and existing shop standards.
7. How many tool stations does the machine support?
The lathe offers tool post station options of 8, 6 or 4 stations to suit different production needs and tooling strategies.
8. What are the spindle speed ranges and torque?
Spindle speed is provided in multiple ranges depending on gearbox selection (low to high ranges covering roughly 30–835 rpm across stages). Maximum spindle output torque ranges around 125–350 Nm. Exact speed ranges depend on the selected gearing/options—please confirm specific configuration with SANJI.
9. What are the tailstock specifications?
Tailstock sleeve diameter and stroke are listed as 100 mm / 250 mm, and the tailstock spindle taper is Morse No. 6 (MOSHI 6#).
10. What power and electrical options are available?
The main spindle motor is 11 kW. Voltage specifications can be customized to meet customer requirements and local electrical standards—contact sales to specify your required supply.
11. Which metalworking applications is this lathe suitable for?
The CK6163 is suitable for turning, facing, threading, drilling, milling and general metal removal on materials such as steel, stainless steel, aluminum, non-ferrous alloys and other machinable metals used in automotive, oil & gas, general engineering and tooling.
12. What safety features does the CK6163 include?
The machine is designed with a high safety level and typically includes protective guards, emergency stop, safety interlocks and other standard protections. Final safety feature set may vary by configuration—verify exact safety items with your supplier and ensure compliance with local regulations.
13. What warranty and after-sales support are provided?
SANJI provides a 1-year warranty and comprehensive after-sales service, which typically includes technical support, spare parts availability and assistance with installation and commissioning. Extended service contracts may be available—contact SANJI for details.
14. What optional accessories and customizations are available?
Available options commonly include different chucks, steady/rest supports, custom tool holders, coolant systems, part catchers, different CNC controls (SIEMENS/FANUC/Mitsubishi/GSK), and electrical voltage customization. Ask your SANJI representative for a full options list.
15. How are installation, training and maintenance handled?
SANJI offers installation and on-site commissioning along with operator and maintenance training as part of after-sales support. Routine maintenance includes regular lubrication, way-cover and guideway inspection, spindle and chuck checks, and CNC backup—follow the operator manual and SANJI recommendations for intervals.
