The maximum processing size is X: 800 mm, Y: 2440 mm, and Z: 200 mm.
The machine operates at 220V 50Hz with a power of 12KW.
It has a production capacity of 1 meter per minute.
Key features include fully automatic operation, high-quality components, fast processing speed, advanced PLC control system, and pneumatic positioning for accurate glass handling.
It can perform milling, drilling, and polishing for glass.
The machine weighs 2000 kg.
The brand name is ALLRAISE.
The overall size of the machine is 3720 mm x 2100 mm x 2000 mm.
It uses an advanced PLC control system for precision and efficiency.
Please check with the manufacturer or retailer for warranty details.
Yes, installation support may be provided; please confirm with the supplier.
Core components include PLC, engine, bearing, gear, and pump.
The machine uses long glass special suction cups for handling glass.
The drive motor is a 1kw Hanwoo pure servo drive.
The machine is packaged in a wooden case for safe shipping.
