The primary function of this machine is to cut and punch stainless steel pipes at a 45-degree angle, making it ideal for fabricating high-security doors.
The machine operates on a voltage of 380V or 220V, with additional options available for 415V and 440V, as well as customized voltage requirements.
The machine has a maximum capacity of producing 50 pieces per minute.
The machine offers a cutting accuracy of 0.05 mm.
The machine is powered mechanically and driven by a hydraulic system for enhanced efficiency.
The machine dimensions are 900 x 850 x 1550 mm, and it weighs 500 kg.
Yes, the machine is CE certified, ensuring it meets safety and reliability standards.
Yes, the machine includes one set of notching molds for versatile applications.
The machine is packaged in a standard export free-fumigation wooden case to ensure safe delivery.
We have a supply ability of up to 100 sets per month.
No, this machine does not utilize CNC control; it operates as a normal machine.
The machine is equipped with a 5 KW motor for efficient operation.
While the machine is designed primarily for stainless steel, it may also work with other metals, but performance may vary based on material properties.
Yes, a machinery test report is provided to ensure quality and performance standards.
The single package size for shipping is 105 x 95 x 165 cm.
