Product Description

Key Components:

---Still Pot:

1. Volume: 1000L.
2. Inner Pot: TP2 red copper, thickness 3mm.
3. Dished Head: TP2 red copper, thickness 3mm.
4. Outer Shell: SUS304 stainless steel, fish scale plate, thickness 2mm.
5. Jacketed: 50mm insulation.
6. Heating Method: 1KW, (415V/50hz/3ph electric heating rods).
7. Accessories: φ250 manhole, level gauge, pressure relief valve, thermometer, sight light, etc.

---Copper Head:
1. Material: TP2 red copper, thickness 3mm

---Material Separator:
1. Material: TP2 red copper

---Distillation Column:
1. Material: TP2 red copper, thickness 3mm

2. Size: Φ152

3. Features: 4 bubble trays, 5 sight glasses, attached reflux device, thermometer.

---Dephlegmator:
1. Material: TP2 red copper, thickness 3mm
2. Size: Φ152
3. Features: Cooling water inlet and outlet, thermometer.

---Condenser:
1. Material: SUS304 stainless steel, thickness 3mm
2. Size: Φ152
3. Features: Cooling water inlet and outlet, thermometer.

---Stainless Steel Bracket:
1. Includes: 1*30L collection bucket

---CIP Cleaning Pump:
For convenient cleaning of the equipment.

---Alcohol Pipeline:
1. Material: TP2 red copper, thickness 1.5mm.

---Wine Mouth:
1. Material: TP2 red copper with glass

Technical Features

1. High-quality Materials: TP2 red copper and SUS304 stainless steel ensure corrosion resistance and stability.

2. Efficient Heating: Interlayer steam heating ensures uniform heat distribution and improved distillation efficiency.

3. Multiple Bubble Trays: Ensures effective separation of impurities during distillation, enhancing the quality of the distilled
spirits.

4. Insulated Jacket: 50mm insulation layer reduces heat loss and improves energy efficiency.

5. Safety Accessories: Includes pressure relief valve, thermometer, and other safety components to ensure safe operation.
