Underground Hydraulic Crawler Water Well Drilling Rig
The ZDY3200S Underground Hydraulic Crawler Water Well Drilling Rig is a high-performance, versatile mine drilling machine designed for a range of applications in water exploration, geological surveys, and mining. This rig is ideal for drilling various engineering holes, gas drainage, dust-proof water injection, and more. With a drilling depth of up to 300 meters, it provides outstanding capabilities for both underground and surface drilling projects.
Key Features:
Brand Name: ZDY3200S
Model: Underground Hydraulic Crawler Water Well Drilling Rig
Application: Mine exploration, water well drilling, core taking, dust-proof water injection, and geological hole drilling.
Power Source: Hydraulic, with double pump system for superior performance.
Technical Parameters:
Specification
ZDY660
ZDY1250S
ZDY1900S
ZDY3200S
ZDY4000S
Rated Torque (N.m)
660
1250
1900
3200
4000
Drilling Depth (m)
150/100
300/200/100
300/200/100
300/200/100
350/200/100
Drill Pipe Diameter (mm)
42/50
42/50/63.5
63.5/73
63.5/73
63.5/73
Drilling Angle (°)
±90
0～±90
0～±90
0～±90
0～±90
Rated Rotating Speed (r/min)
50-300
50-250
50~270
50~210
50~280
Pushing Ability (KN)
27
36
77
77
100
Pulling Ability (KN)
40
52
112
112
150
Push/Pull Stroke (mm)
650
600
600
800
800
Min. Working Height (mm)
1000
1000
1000
1000
1100
Max. Working Height (mm)
2100
2100
2100
2100
2100
Power (KW)
15
22
37
37
45
Weight (kg)
1100
1350
2100
2200
2500
Drill Machine Weight (kg)
600
800
1250
1200
1500
Advantages:
High Drilling Capacity: With depths ranging from 100m to 350m, the ZDY3200S is suitable for a wide range of mining and exploration tasks.
Durable Design: Built with high-quality components, including Eaton hydraulic system, this machine ensures long-lasting reliability and efficiency in harsh environments.
Versatile Functionality: Capable of performing both rotary drilling and core-taking, the machine adapts to various drilling techniques, depending on project needs.
Efficient Power: The double pump hydraulic system ensures smooth, continuous operations, improving efficiency and reducing downtime.
Compact and Portable: Despite its powerful performance, the rig’s crawler-mounted design ensures ease of mobility in confined spaces.
Applications:
Water Well Drilling: Ideal for exploration and installation of water wells in mines and other underground environments.
Geological Surveys: Used for core sampling and geological hole drilling in mineral exploration.
Mine Exploration: Perfect for underground mining operations requiring detailed geological studies and sample extraction.
The ZDY3200S Hydraulic Crawler Drilling Rig is a robust and flexible solution for your deep drilling needs, offering high performance, durability, and a range of features designed to handle complex and challenging drilling environments.
