World Class Wood Based Panel Furniture Edgebander Automatic Scraping Edge Banding Machine outdoor cabinet production line
- Section : Machinery
- Category : Woodworking Machinery
- SKU : 1601082724686
PRODUCT INFORMATION
ZICAR Wood Door/Cabinet Or Other Furniture Production Line
Sliding Table Saw→Auto Edge Banding Machine→Single Row Drill machine→Single Head Hinge Drill Machine
（If you need more automated and efficient production line, please contact us）
Characteristics
●This production line is suitable for some new furniture factories.
●Space requirement is about 5(Width)x 7(Length)square meters.
●Each machine is simple and easy to operate.
●This production line can reach up to 60-80 pieces standard size board(1220*1440 mm ) within 8 hours.
●Only 3-4 workers are needed, saving labor costs.
Description
This processing line is very suitable for some small manufacturers who are just starting to do business. We believe this simpleproduction line is your best choice if you are faced with the problems of limited space, limited budget and insufficient experience.
For this production line, you can process ordinary furniture, such as desks, cabinets, wardrobes, and office furniture. Each model from this line is very easy to operate and you just need 3 workers without rich experience, also with lowest cost of maintenance.
PARAMETER INFORMATION
1. Sliding table saw
It can cut the whole board according to the size of the furniture, for example, it can be cut into side boards, top boards, bottom boards, back boards, etc.
*Model：MJ6132YE
*Length of cut：3100mm
*Height of cut：80mm (45°Max 55mm)
*Main saw blade speed：4000/6000rpm
*Main saw blade
titling angle：45-90° *Main motor：4.0kw or 5.5kw
2. Edge banding machine
After the board is cutted, the wooden material on the side and the glue used for bonding will be exposed. It is necessary to give protective treatment to the side of the plate.
*Model：MF60G
*Panel Length：Min.140mm
*Panel Thickness：10-60mm
*Edge Thickness：0.4-3mm
*Feeding Speed：16m/min
*Total Power：7.5kw
3. Single Row Drill Machine
With multiple drill bits, without grooving.Before processing, you can adjust the drilling position according to the size of the plate.
*Model：MZ1
*Manimum drilling diameter：35mm
*Manimum drilling depth：60mm
*Number of auger shaft：21
*Rotation speed：2800r/min
*Motor power：1.5kw
4. Single Head Hinge Drill Machine
Simple drilling machine is only used for drilling hinge holes, the drilling position can be adjusted longitudinally and
horizontally.
*Model：MZ73031
*Manimum drilling diameter：50mm
*Manimum drilling depth：60mm
*Vertical spindle heads：220-815mm
*Number of Spindle：3pcs
*Spindle speed：2840r/min
