Product Description
Specifications :
1)Tube sterilizing equipment set is a disposal sterilizing equipment designed for dairy products, juice, beverage or similar flow and material and also is an ideal equipment for prolonging quality validity through sterilizing and cooling. According to different material heating, sterilizing and different technological demand of keeping temperature and cooling carry out the flow chart assembly design; possess various complete protective measurements, with high automatic degree and accurate control.
2) Pasteurizing for various fluid, such as fresh milk, fruit juice, drinks, popsicles, ice cream paste, soy sauce, soy milk, wine and etc.
3) Continuous working with short pasteurizing time span
4) Instant ultra high temperature, excellent pasteurizing effect
5) Cooperated with centrifugal pump or high pressure homogenizer, high viscosity fluid can be processed
6) Made by high quality full stainless steel, high efficiency and stable performance
Technical Parameter :
| Model | UHT-1 | UHT-2 | UHT-4 | UHT-6 |
| Capacity ( T/H ) | 0.5~1t/h | 1.5~2t/h | 3~4t/h | 5~6t/h |
| Sterilization temperature | 115~137°C | 115~137°C | 115~137°C | 115~137°C |
| steam pressure | <0.78MPa | <0.78MPa | <0.78MPa | <0.78MPa |
High-temperature sterilization time | 4~6s | 4~6s | 4~6s | 4~6s |
| Discharge temperature | <65°C | <65°C | <65°C | <65°C |
| Feed temperature | <16°C | <16°C | <16°C | <16°C |
| Steam consumption | <0.12kg/L | <0.15kg/L | <0.15kg/L | <0.20kg/L |
| Power | 1.5kw | 2.2kw | 3kw | 4kw |
| Dimensions(mm) | 1200×920×1650 | 1300×1100×1700 | 1600×1200×1800 | 1940×1400×2000 |
