The maximum drilling depth of the Portable Hydraulic Core Drill Rig Machine is between 100 to 300 meters.
This drilling rig is suitable for geological exploration for mineral resources, soil testing, environmental assessments, construction site investigations, and mining operations requiring core sampling.
The advanced hydraulic system provides efficient power and reliability, allowing the drill rig to handle various drilling tasks effectively and ensuring excellent performance in the field.
Yes, the Portable Hydraulic Core Drill Rig Machine offers both manual and remote control operation options for flexibility.
The machine weighs between 2.2 to 4.3 tons, depending on the configuration.
The engine model Yuchai Turbocharging has a rated power of either 58 or 70 kW.
The drill rig can accommodate calibers of 100-200-300 mm and 200-400-500 mm.
Yes, the Portable Hydraulic Core Drill Rig Machine is designed for easy transportation, making it suitable for various field applications.
The torque range of the machine is between 300-500 N.m and 350-700 N.m, depending on the configuration.
The drill rig features both water cooling and air cooling hydraulic systems to ensure optimal performance.
The walking speed of the machine is between 2.5 to 3.5 km/h.
The feed stroke length of the Portable Hydraulic Core Drill Rig Machine is 1300 mm.
The drilling tower angle can be adjusted between 45 to 90 degrees.
While the product does not specify training, it is recommended that new users consult the manual and seek guidance from experienced professionals to ensure safe and effective operation.
The transport dimensions vary based on configuration: 3000*1300*1800 mm or 4200*2050*2300 mm.
