mitsubishi Control System High Speed Drilling Cum Milling Machine

0 Customer Reviews

  • Shipping Timeframes: All orders are processed within 2-5 business days (excluding weekends and holidays). After your order has been processed, the estimated delivery time is before 03 Feb, 2026, depending on customs, Please note that due to high demand, some items may experience longer shipping times, which will be communicated at order confirmation email.
  • Order Processing Time: Please allow 2-5 business days for us to process your order before it is shipped . Orders placed after 16:00 on Fridays, or during weekends and public holidays, will begin processing on the next business day. Processing times may be extended during peak seasons or sales events.
  • Manufacturing Time: Some products needs manufacturing time, the manufacturing process will take approximately 10-30 business days depending on the product. This timeframe may vary depending on the complexity of the product and current demand. but this will be communicated with you during order confirmation.
  • Returns and Exchanges: We offer a 30-day return policy for most items. If you are not completely satisfied with your purchase, you may return it within 30 days of receipt for a refund or exchange. Items must be unused, in their original packaging, and accompanied by proof of purchase. Return shipping costs are the responsibility of the customer, unless the item was damaged or defective upon arrival.
1. What are the main features of the Mitsubishi Control System High Speed Drilling Cum Milling Machine?

The main features include high-precision and high-rigidity spindle, servo motor drive, a belt-type spindle for strong rigidity and reliability, and a direct-connected spindle with low noise and low vibration.

2. What is the maximum spindle speed of this machine?

The maximum spindle speed is 8000 RPM, with an optional upgrade to 10000 RPM.

3. What is the travel range for the X, Y, and Z axes?

The X-axis travel is 800 mm, Y-axis travel is 500 mm, and Z-axis travel is 500 mm.

4. What is the maximum load capacity of the worktable?

The maximum worktable load capacity is 500 kg.

5. Can this machine perform multiple machining functions?

Yes, it can perform milling, boring, drilling, tapping, and cutting threads, making it a versatile CNC machine.

6. What type of materials can this machine process?

This CNC machining center is suitable for precision machining of various materials, enhancing production efficiency and product quality.

7. What are the rapid traverse speeds for the X, Y, and Z axes?

The rapid traverse speeds are 24 m/min for both X and Y axes and 20 m/min for the Z axis. There is an optional upgrade to 48 m/min for X and Y, and 36 m/min for Z.

8. What is the positioning accuracy of the machine?

The positioning accuracy is ±0.0075 mm, and the repeat positioning accuracy is ±0.005 mm.

9. What is the weight of the machine?

The machine weight is 5600 kg.

10. What is the size of the table?

The table size is 1000 mm x 500 mm.

11. How many tools can the tool magazine hold?

The tool magazine can hold a maximum of 24 tools.

12. What is the maximum tool diameter that can be used?

The maximum tool diameter is φ78 mm when adjacent and φ120 mm when apart.

13. What is the type of guide rail used in this machine?

The machine uses linear rails for smooth and precise movement.

14. What is the distance from the spindle axis to the column surface?

The distance from the spindle axis to the column surface is 525 mm.

15. What are the overall dimensions of the machine?

The overall dimensions of the machine are 2600 mm x 2300 mm x 2800 mm.
